LogTag SRIL-16U Quick Start Manual

TRIL/SRIL-16U USB PDF TEMPERATURE RECORDER
Introduction
LogTag's TRIL/SRIL-16U is a fully configurable, multi-use USB
temperature recorder that can create temperature reports
without the need to install proprietary software or hardware at
the destination. It can be plugged straight into a computer's
USB port and generates a PDF file, which can be accessed
using PDF software such as Acrobat Reader.
Hardware Requirements
®
• LogTag TRIL or SRIL-16U USB PDF temperature recorder.
It is recommended you connect all TRIL/SRIL-16U devices via a
permanently plugged in USB extension cable or a USB hub to
protect your computer's USB socket.
• A computer with a USB port.
• For configuration - a PC running Windows 8.1 or later.
ALERT LED
OK LED
STOP BUTTON
Metal USB Plug
Software Requirements
Software requirements vary depending on the type of file you
want the TRIL/SRIL-16U to generate when plugged into USB at
the destination.
• If you wish to configure TRIL/SRIL-16U products you will need to
download the LogTag® Analyzer software from LogTag's web site at
https://logtagrecorders.com/lta3/. Follow the instruction to install and
start the software.
Document Revision A, 20250304 - © Copyright 2025, LogTag North America Inc., All Rights Reserved.
Quick Start Guide
• If you only plan on
computer's USB socket. A PDF file will be generated
can open by accessing the recorder's USB memory storage with
PDF reader software such as Acrobat Reader.
• At the same time an LTD file will be created
with LogTag Analyzer. Here you can analyze data in detail,
generate report files and create charts from multiple recorders for
comparison.
• You can also choose to create a CSV file, which can be opened
directly with MS Excel
• You can also
Configuring the TRIL/SRIL-16U
TRIL/SRIL-16U products can be ordered ready to start, or
configured using LogTag Analyzer:
• Start the LogTag Analyzer software, remove the protective cap and
insert the TRIL/SRIL-16U into a USB port. You will receive a message
MOUNTING LUG
that a new USB device has been found
installed.
• Once the driver is installed and the TRIL/SRIL-16U is ready
(indicated by the green LED on the recorder blinking every second),
it can receive configuration data. If the TRIL/SRIL-16U does not
appear in the list of devices simply click Rescan.
Standard Configuration Options
SENSOR
The standard configuration options include settings such as
START/MARK BUTTON
Protective USB Cap
User ID, start
duration, start delay
Alarm Settings
1 Depending on the con guration, the TRIL/SRIL-16U may produce a combination of di erent le
types, or none at all if le generation is disabled when con guring the unit.
2 Depending on the factory con guration additional drivers may be installed at this time.
®
LogTag is a registered trademark of LogTag North America Inc..
®®
evaluating data, plug the TRIL/SRIL-16U into a
1 , which you
1 that can be
TM .
download data directly into LogTag Analyzer.
2
, and a generic driver will be
method, pre-start recording, logging interval
and password.
LogTag North America Inc.ecorders reserves the right to change this speci cation without notice.
LogTag
opened
In this tab you define the conditions in which the TRIL/SRIL-
16U will display an alert. You can set up to 6 alarm trigger
conditions.
and
®
