- Page 1 TRED30-16U Quick Start Guide Version A www.logtagrecorders.com Page 1...
-
Page 2: Table Of Contents
Quickstart Guide Contents Downloading LogTag Analyzer Configuring your TRED30-16U Starting your TRED30-16U During Recording Downloading Results Compatible Accessories Page 2... -
Page 3: Downloading Logtag Analyzer
Downloading LogTag Analyzer To download the latest LogTag Analyzer, open your browser and navigate to: https://logtagrecorders.com/software/LTA3/ 1. Click ‘Go to downloads page’ to take you to the download page. 2. Click ‘Download Now’ to start the download. 3. Click ‘Run’ or ‘Save File’ then double-click the downloaded file to open the LogTag Analyzer Setup Wizard. - Page 4 Downloading LogTag Analyzer continued... 1. Follow the on-screen prompts to install LogTag Analyzer. 2. Click ‘Finish’ to exit the LogTag Analyzer Setup Wizard. Note: If you already have LogTag Analyzer installed, please see whether you need to update to the latest version by clicking ‘Check Internet for updates’...
-
Page 5: Configuring Your Tred30-16U
LogTag interface cradle with the provided USB cable. 1. Open LogTag Analyzer. 2. Click ‘Configure’ from the ‘LogTag’ menu or select the ‘Wizard’ icon. 3. Adjust your logger settings as needed. For detailed configuration options, refer to the Product User Guide or press ‘F1’... -
Page 6: Starting Your Tred30-16U
Please ensure the sensor is connected before starting your TRED30-16U. Press and hold the START/ CLEAR/STOP button. Continue to hold the START/ CLEAR/STOP button until “REC” appears on the display. Then release the button. The TRED30-16U is now recording temperature data. Page 6... -
Page 7: During Recording
During Recording Reset Trip Min/Max Temperatures: The currently stored Min/Max temperature values can be reset at any time while the unit is recording, but not once the unit has been stopped. To reset the values, please refer to the Product User Guide. To view other information about clearing alarms and reviewing Min/Max trip temperatures, please also refer to the... -
Page 8: Downloading Results
Micro USB. 1. Open LogTag Analyzer. 2. Click ‘Download’ from the ‘LogTag’ menu or press F4. After a few seconds, the downloaded data will appear. After a few seconds, the downloaded data will appear. -
Page 9: Compatible Accessories
LTI-HID Interface USB-C Cable (Optional) (Recommended) The TRED30-16U features a new USB-C connection, eliminating the need for the LTI interface while the logger retains it’s three-pin for LTI compatibility. Other Accessories: The TRED30-16U is compatible with the following accessories. Buffer Bottle...
