UNVENTED WATER HEATER
ASSEMBLY AND OPERATION INSTRUCTIONS
ANDRIS ELITE Wi-Fi

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANDRIS ELITE Wi-Fi 10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ariston ANDRIS ELITE Wi-Fi 10

  • Page 1 The home of sustainable comfort UNVENTED WATER HEATER ASSEMBLY AND OPERATION INSTRUCTIONS ANDRIS ELITE Wi-Fi...
  • Page 2: General Safety Instructions

    GENERAL SAFETY INSTRUCTIONS 1. Read the instructions and warning in this manual carefully, they contain important information regarding safe installation, use and maintenance. This manual is an integral part of the product. Hand it on to the next user/owner in case of change of property. 2.
  • Page 3 8 Before using the device and after routine or extraordinary main- tenance, we recommend filling the appliance’s tank with water and draining it completely to remove any residual impurities. 9. If the appliance is equipped with a power cord, the latter may only be replaced by If the appliance is equipped with a power cord, the latter may only be replaced by a qualified engineer.
  • Page 4 Enactment of Directive 2012/19/EU governing electrical and electronic waste (WEEE) The barred wheeled bin symbol appearing on the appliance or on its packaging indicates that the product must be collected separately from other waste at the end of its useful life. The user must therefore deliver the decommissioned product to an appropriate local facility for separate collection of electro-technical and electronic waste.
  • Page 5 LEGIONELLA BACTERIA FUNCTION Legionella are small rod shaped bacteria which are a natural constituent of all fresh waters. Legionaries’ disease is a pneumonia infection caused by inhaling of Legionella species. Long periods of water stagnation should be avoided; it means the water heater should be used or flushed at least weekly.
  • Page 6: Technical Specifications

    TECHNICAL SPECIFICATIONS For the technical specifications, refer to the nameplate (the nameplate is located next to the water in- take/outlet pipes). TABLE 1 - PRODUCT INFORMATION Product range Weight 12,8 Installation Oversink Undersink Oversink Undersink Oversink Model Refer to the nameplate 2,442 2,691 2,462...
  • Page 7: Building Regulations

    The LED light shows when the heating element is working, under control of the thermostat. If in doubt ring Ariston UK Ltd. Technical department 03332407777 Customer service department 03332408777. Note: In the event of a power failure, or if the product is turned off using the ON/OFF “ ” button.
  • Page 8: Anti-Freeze Function

    “OFF”; or if the “SET” button is pressed to change the setpoint. WI-FI FUNCTION For further information about Wi-Fi configuration and the product registration procedure, refer to the enclosed quick start guide dedicated to connectivity, or visit the website: https://discover.ariston-net.remotethermo.com 8 / EN...
  • Page 9: Weekly Program Function

    Connection status description Slow flashing The Wi-Fi module is ON Wi-Fi Rapid flashing The Wi-Fi module is in Access Point mode Button Double flashing The WI-Fi module is connecting to the home network The Wi-Fi is ON and connected to the home network The Wi-Fi module is OFF Wi-Fi RESET: to carry out a reset, press the“...
  • Page 10: Installation Instructions

    INSTALLATION INSTRUCTIONS Before installing the heater read these instructions in full. If you are unsure please contact our qual- ified technician service department (03332407777). Note: For further information please refer to the flow chart on page 19 which gives guidance on choosing controls.
  • Page 11 1) Using the feed pipe to accommodate expansion (Schedule 2, Section 6: Paragraph 15 of the Water Supply (Water Fittings) Regulations 1999 and the Water Byelaws 2000, Scotland) (Fig. 1). Do not fit any stop cocks or isolating valves within the distance required for expansion. If a pressure reducing valve is needed, due to a mains pressure of over 3.5 bar, an expansion control kit must be fitted regardless of expansion pipework installed.
  • Page 12 The model 30L is covered under the Building Regulations and therefore it is not possible to accommo- date the expansion water within the system pipe work and consequently a set of expansion controls must be installed. Note: The discharge from relief valves must be made in a safe and conspicuous man- ner;...
  • Page 13: Worked Example

    Fig. 4 Suggest ways of terminating discharge pipes safety Metal discharge pipe (D1) from temperature & pressure relief valve Temperature to tundish. & pressure relief valve Tundish 600 mm Max. 300 mm Min. Discharge below fixed grating. (see page 6 for alternative points of discharge).
  • Page 14: Electrical Warning

    d) ELECTRICAL WARNING: The appliance must be earthed The electrical installation must be in line with the current IEE wiring regulations. A mains supply of 240 VAC 3 kW, is required (Fig. 5) Heat resisting cable, minimum round 3 core 1.5 mm (to BS 6141 table 8) should be used to connect to the electrical supply through 20 amp double pole switch (conforming to BS EN 60669-1).
  • Page 15: Emptying The Appliance

    COMMISSIONING - Check that all the necessary components are supplied and for those not factory fitted, that they are the type recommended by the manufacturer for the particular water heater. - Check that the water heater/components are undamaged. - Check that the discharge pipe is plumbed so that it falls continuously and that no taps, valves or other shut-off devices are installed in the pipe.
  • Page 16: Periodical Maintenance

    In order to work on the heating element and the anode, the appliance must first be emptied. Undo the 4 bolts (A Fig. 4) and remove the flange. The heating element and anode are attached to the flange. During reassembly, make sure that the flange gasket, the thermostat and the heating element are put back in their original positions.
  • Page 17 17 / EN...
  • Page 18 40° 65° ECO HOLD THE BUTTON TO SELECT THE DESIRED TEMPERATURE PROLONGED PRESSURE TO FLOW WATER TEMPERATURE 18 / EN...
  • Page 19 To enter into the terminal compartment unscrew the 2 screws on the cover. (To access the screws, remove the decorative caps on the control access panel). 19 / EN...
  • Page 20: Installation Scheme

    INSTALLATION SCHEME OVERSINK 1/2" G MOD. 1/2" G UNDERSINK 1/2" G MOD. 1/2" G 20 / EN...
  • Page 21: Bench Mark Commissioning Ch Ecklist

    BENCh MARK COMMISSIONING Ch ECKLIST 21 / EN...
  • Page 22: Bench Mark Service Record

    BENCh MARK SERVICE RECORd 22 / EN...
  • Page 23 NOTE...
  • Page 24 Manufactured by: Commercial subsidiary: Ariston S.p.A. Ariston U.K. Ltd Viale Aristide Merloni, 45 Ariston U.K. Ltd - Kings House, 60044 Fabriano (AN) - ITALY 101 – 135 Kings Road, ariston.com Brentwood, Essex, CM14 4DR - UK ariston.com 420011377800 - 1124...
