INSTRUCTION MANUAL
Gas Pasta Cookers
Item
49098
Model
CE-IT-0045PLUS
Before you begin using your appliance, PLEASE READ
AND UNDERSTAND THIS DOCUMENT CAREFULLY before
installing, operating, maintaining, or servicing.
There are many important safety messages in this
manual and on your appliance. Always read all safety
messages.
Failure to do so can result in appliance failure, property
damage, serious injury or death. Appliance failure, injury
or property damage due to improper installation is not
covered by warranty.
WARRANTY
PARTS & LABOUR
1-833-487-3686
49100
CE-IT-0090PLUS
Warning!
www.trentoequipment.com
DO NOT RETURN THIS PRODUCT TO THE STORE!
For questions or assistance with this product, call
TRENTO Toll free: 1-833-487-3686 or visit the support
section from our website, www.trentoequipment.com
trentoservice@trentoequipment.com
E L E V A T I N G C U L I N A R Y E X C E L L E N C E
Stop!
Version: Revised - 05/02/2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRENTO CE-IT-0045PLUS and is the answer not in the manual?

Questions and answers

Related Manuals for Omcan TRENTO CE-IT-0045PLUS

Summary of Contents for Omcan TRENTO CE-IT-0045PLUS

  • Page 1 E L E V A T I N G C U L I N A R Y E X C E L L E N C E INSTRUCTION MANUAL Gas Pasta Cookers Item 49098 49100 Model CE-IT-0045PLUS CE-IT-0090PLUS Warning! Stop! Before you begin using your appliance, PLEASE READ AND UNDERSTAND THIS DOCUMENT CAREFULLY before DO NOT RETURN THIS PRODUCT TO THE STORE!

  • Page 2: Table Of Contents

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E TABLE OF CONTENTS Section Page General Information --------------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------------- 4 - 7 Technical Specifications ------------------------------------------------------------------------------- 7...

  • Page 3: General Information

    If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents.

  • Page 4: Safety And Warranty

    Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
  • Page 5 E L E V A T I N G C U L I N A R Y E X C E L L E N C E SAFETY AND WARRANTY gas to propane. - An optional high-limit thermal protector kit. This kit is being provided only for the convenience of the customer in the event it is needed to comply with local safety ordinances.
  • Page 6 1 YEAR PARTS AND LABOR WARRANTY Within the warranty period, contact Omcan Inc. at 1-833-487-3686 to schedule an Omcan authorized service technician to repair the equipment locally.

  • Page 7: Technical Specifications

    SAFETY AND WARRANTY Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use. Please see https://omcan.com/disclaimer for complete info. WARNING: The packaging components are classified as normal solid urban waste and can therefore be disposed of without difficulty.

  • Page 8: Installation

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E INSTALLATION PRELIMINARY INSTRUCTIONS Installation must be carried out by following the instructions contained in this handbook and only by a licensed technician in accordance with local codes, or in absence of it, with the National Fuel Gas Code, ANSI Z 223.1 or with the Natural Gas Installation Code CSA-B149.1.
  • Page 9 E L E V A T I N G C U L I N A R Y E X C E L L E N C E INSTALLATION and possible clogging of the water tubing. The pipe used to discharge the water must be heat resistant and allow for the free flow of the discharge water.
  • Page 10 E L E V A T I N G C U L I N A R Y E X C E L L E N C E INSTALLATION Type of gas Supply pressure Inches Water Column Minimum maximum Optimum Natural gas (methane) G20 1.0”...

  • Page 11: Operation

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E INSTALLATION the regular thermocouple installed at the factory with the special thermocouple and wiring necessary for the functioning of the “high-limit”.
  • Page 12 E L E V A T I N G C U L I N A R Y E X C E L L E N C E OPERATION CAUTION: always fill the cooker basin with water before turning on the gas. •...

  • Page 13: Maintenance

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E OPERATION • Service the equipment at least once a year. DO NOT: • Operate the unit as a pasta cooker without sufficient water in the tank.

  • Page 14: Troubleshooting

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E MAINTENANCE REPLACING THE MAIN BURNER • Open the door. • Unscrew the nut from the gas collector (pos. 46 fig. 6 and pos. 51 fig. 7). •...
  • Page 15 E L E V A T I N G C U L I N A R Y E X C E L L E N C E TROUBLESHOOTING MALFUNCTIONING LIKELY CAUSE REMEDY Piezoelectric not working. Insufficient gas pressure. Check supply pressure. Dirty injector.
  • Page 16 E L E V A T I N G C U L I N A R Y E X C E L L E N C E FIGURE DRAWINGS A – Water supply connection Ø ½” S – Water outlet connection Ø 1” G –...
  • Page 17 E L E V A T I N G C U L I N A R Y E X C E L L E N C E FIGURE DRAWINGS DRAIN COVER FRONT DOOR TOP DRAINER GRILL EXHAUST GRATE PILOT SPY GLASS STAINLESS STEEL GRID FRONT PANEL SAFETY THERMOSTAT...
  • Page 18 E L E V A T I N G C U L I N A R Y E X C E L L E N C E FIGURE DRAWINGS DRAIN COVER DOOR HINGE TOP DRAINER GRILL FRONT DOOR PILOT SPY GLASS EXHAUST GRATE FRONT PANEL STAINLESS STEEL GRID...
  • Page 19 E L E V A T I N G C U L I N A R Y E X C E L L E N C E FIGURE DRAWINGS WATER INLET KNOB NIPPLE G1/2 CLAMP FOR PIPE 38-50 DRAIN HOSE G.1 EXTENSION WATER INLET CONNECTOR INOX FLEX PIPE...
  • Page 20 E L E V A T I N G C U L I N A R Y E X C E L L E N C E FIGURE DRAWINGS WATER INLET KNOB T JUNCTION T JUNCTION DRAIN HOSE G.1 M/F SLEEVE CLAMP FOR PIPE 38-50 INOX FLEX PIPE CLAMP FOR PIPE 32-44...
  • Page 21 E L E V A T I N G C U L I N A R Y E X C E L L E N C E FIGURE DRAWINGS PILOT METHANE ORIFICE GAS VALVE BICONE PILOT ORIFICE NUT FOR GAS VALVE PILOT BURNER BICONE FOR GAS VALVE PILOT LINE NUT...
  • Page 22 E L E V A T I N G C U L I N A R Y E X C E L L E N C E FIGURE DRAWINGS PILOT METHANE ORIFICE GAS COLLECTOR BICONE PILOT ORIFICE GAS VALVE PILOT BURNER NUT FOR GAS VALVE PILOT LINE NUT BICONE FOR GAS VALVE...
  • Page 23 E L E V A T I N G C U L I N A R Y E X C E L L E N C E FIGURE DRAWINGS 22/S 1 – Water inlet knob A – Minimum adjustment screw of 2 –...
  • Page 24 E L E V A T I N G C U L I N A R Y E X C E L L E N C E FIGURE DRAWINGS Figure 11 – Measuring gas pressure Page 24 / 40...
  • Page 25 E L E V A T I N G C U L I N A R Y E X C E L L E N C E FIGURE DRAWINGS Figure 12 – Temporary “bridge” to by-pass the optional safety thermostat Page 25 / 40...

  • Page 26: Parts Breakdown

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49098 CE-IT-0045PLUS Page 26 / 40...
  • Page 27 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49098 CE-IT-0045PLUS Page 27 / 40...
  • Page 28 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49098 CE-IT-0045PLUS 46.1 46.1 46.2 46.12 46.1 71.4 46.1 71.6 71.5 71.3...
  • Page 29 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49098 CE-IT-0045PLUS Item No. Description Position Item No. Description Position Item No.
  • Page 30 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49098 CE-IT-0045PLUS Item No. Description Position Item No. Description Position Item No.
  • Page 31 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49100 CE-IT-0090PLUS Page 31 / 40...
  • Page 32 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49100 CE-IT-0090PLUS Page 32 / 40...
  • Page 33 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49100 CE-IT-0090PLUS 80.4 79.4 79.5 80.6 80.5 79.8 79.1 80.1 79.2 79.3...
  • Page 34 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49100 CE-IT-0090PLUS Page 34 / 40...
  • Page 35 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49100 CE-IT-0090PLUS 46.1 47.1 46.10 47.12 46.11 46.1 47.12 46.12 46.1 47.4...
  • Page 36 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49100 CE-IT-0090PLUS Item No. Description Position Item No. Description Position Item No.
  • Page 37 E L E V A T I N G C U L I N A R Y E X C E L L E N C E PARTS BREAKDOWN ITEM MODEL 49100 CE-IT-0090PLUS Item No. Description Position Item No. Description Position Item No.

  • Page 38: Notes

    E L E V A T I N G C U L I N A R Y E X C E L L E N C E NOTES ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...

  • Page 39: Warranty Registration

    Gracias por comprar un producto Trento usted. Para registrar su garantía para este producto, complete la información a continuación, cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en: https://omcan.com/warranty-registration/ For mailing in Canada...
  • Page 40 E L E V A T I N G C U L I N A R Y E X C E L L E N C E TRENTO IS A SIGNATURE LINE OF PROFESSIONAL RESTAURANT EQUIPMENT FROM OMCAN OFFERING PREMIUM EUROPEAN BRANDS TO THE NORTH AMERICAN MARKET.
