- Page 1 HPAT550 HPAT650 HANDYPAT TESTER Instruction Manual...
- Page 2 Do not use if damaged. Where applicable other safety measures such as use of protective gloves, goggles etc. should be employed. Please keep these instructions for future reference. Updated instructions and product information are available at: www.martindale-electric.co.uk/manuals REMEMBER: SAFETY IS NO ACCIDENT...
- Page 3 Meaning of Symbols and Markings Caution - risk of danger and refer to instructions Caution - risk of electric shock Equipment protected by double or reinforced insulation (Class II) AC (Alternating current) Equipment complies with relevant EU Directives Equipment complies with relevant UK Conformity Assessed marking End of life disposal of this equipment should be in accordance with relevant Directives.
-
Page 4: Table Of Contents
CONTENTS Introduction Unpacking and inspection Description & overview General operation & functions Precautions Power on / off Display indicators & battery level Connector descriptions Menu and button descriptions Default settings and pass levels User settable pass level range Null of test probe lead resistance Saving test records to memory &... -
Page 5: Introduction
1. INTRODUCTION 1.1 Inspection Examine the shipping carton for any sign of damage. Inspect the unit and any accessories for damage. If there is any damage, then consult your distributor immediately. Unpack the HPAT and check that you have the following accessories: •... - Page 6 This allows for alternative test probes to be used if desired. The HPAT650 will perform the following test types: The substitute leakage test is not available on the HPAT550 model. • IEC Lead test sequence • Class I test sequence •...
-
Page 7: General Operation & Functions
If this equipment or the supplied accessories are used in a manner not specified by Martindale Electric, the protection provided by the equipment may be impaired. WARNINGS Before use check the unit for cracks or any other damage. Make sure the unit is free from dust, grease and moisture. -
Page 8: Power On / Off
2.2 Power on / off Hold down the green power button for at least 2 seconds to power on the HPAT. The HPAT will power on with the following display. To power off the HPAT hold down the green power button for at least 3 seconds until ‘Release the POWER button to switch off’... -
Page 9: Display Indicators & Battery Level
2.3 Display Indicators and Battery Charge 0-25% >25 - 50% >50 - 75% >75 - 100% Fully charged Help screens and display diagrams... -
Page 10: Connector Descriptions
2.4 Connector descriptions Front panel three pin socket outlet – Used to connect the appliance under test Select / function buttons 4.0mm Probe connector – Used for earth continuity/class II insulation test probe. *Recessed reset button – Used to reset the internal processor. IEC Input socket –... -
Page 11: Menu And Button Descriptions
2.5 Menu & button descriptions The top row blue selection buttons can be used to select and scroll through the various settings and menu options. The bottom row buttons (HPAT650 only) are used for switching the insulating test voltage 250V / 500V, scroll left and right , and selecting the settings menu... -
Page 12: Default Settings And Pass Levels
2.6 Default settings, pass levels and editing (HPAT650 only) Editing pass levels DEFAULT SETTINGS Insulation Voltage 250V HPAT assist Enabled Fast mode Enabled DEFAULT PASS LEVELS Earth Continuity Class I 0.1Ω IEC Lead 0.1Ω Insulation Class I 1MΩ Class II 2MΩ... -
Page 13: User Settable Pass Level Range
2.7 User Settable Pass Level Range (HPAT650 model only) EARTH CONTINUITY Class I 0.1Ω to 0.9Ω in 0.1Ω increments IEC lead 0.1Ω to 0.9Ω in 0.1Ω increments INSULATION Class I 0.3MΩ to 0.9MΩ in 0.1MΩ increments 1MΩ to 10MΩ in 1MΩ increments Class II 0.3MΩ... -
Page 14: Null Of Test Probe Lead Resistance
2.8 Null of test probe lead resistance (Class I Earth Continuity only) The null function is used to compensate for the test probe lead resistance when used for class I earth continuity measurements. To null the test probe lead resistance select Device setup and scroll to Null Probe. -
Page 15: Saving Test Records To Memory & Recalling Records
2.9 Saving Test Records to Memory and Recalling Test Records (HPAT650 model only) Failed or Pass test results for any test type can be stored to memory using the save button. To recall test records from memory press Settings , Recall Test Records and then Select. The previous and next buttons can then be used to scroll... -
Page 16: Auto Power Down
2.10 Auto power down If the HPAT remains inactive for a period of 3 minutes, auto dimming of the LCD screen will start and the message ‘Auto power down’ will be displayed on the screen before auto power down after 5 minutes of inactivity. 2.11 Inadvertent Connection of Mains Supply Voltage If mains voltage is inadvertently applied to the HPAT, via the IEC socket (1) at the top end, an error message will be displayed... -
Page 17: Performing Appliance & Lead Tests
3.PERFORMING APPLIANCE & LEAD TESTS WARNING The HPATs and this instruction manual are intended for use by personnel who are adequately trained and familiar with the ‘IET Code of Practice for in-service Inspection and Testing of Electrical Equipment’. 3.1 Preliminary Checks and set up Ensure that the appliance is NOT plugged into the mains supply when removing fuses. -
Page 18: Iec Lead Test (Hpat Assist)
Set Up Check that the HPAT’s pass levels are correctly set for the appliance or IEC lead being tested. This can be done by entering the Set Pass Level section of the MENU. Reference should be made to the ‘IET Code of Practice for In-service Inspection and Testing of Electrical Equipment’... - Page 19 Test connections Refer to the IEC Lead connection diagram on page 16. • Plug the IEC lead plug into the HPAT’s front panel socket outlet (1). • Connect the other end of the IEC lead to the HPAT’s IEC input socket (2) •...
-
Page 20: Class I Test (Hpat Assist)
3.3 Class I Test (HPAT assist) Always refer to and perform 3.1 before proceeding The following are performed for a Class I appliance test: Fuse check - checks fuse continuity. • Class I earth continuity measurement - measures • resistance between earth and exposed metalwork. Class I insulation measurement - measures resistance •... - Page 21 Testing in HPAT assist mode (substitute leakage test enabled - HPAT650 model only) • Press Class I button from the sequence screen Press Pass for the HPAT to display the Visual Check screen. • If any visual or fuse checks fail, select Fail and abort the test and return to the sequence screen.
-
Page 22: Class Ii Test (Hpat Assist)
3.4 Class II Test (HPAT assist) Always refer to and perform 3.1 before proceeding The following are performed for a Class II appliance test: Insulation measurement - measures resistance between live • and exposed metalwork and between neutral and exposed metalwork. - Page 23 Testing in HPAT assist mode (substitute leakage test enabled - HPAT650 model only) • Press the Class II button from the Sequence screen for the HPAT to display the Visual check screen. • If any visual or fuse checks fail, select Fail and abort the test and return to the select test screen.
-
Page 24: Extension Lead Testing
Always refer to and perform 3.1 before proceeding To test extension leads the HPAT’s IEC Lead Test is used with connections as detailed below. A Martindale EX332 IEC mains lead (or similar) is required to perform extension lead tests. Test Connections •... -
Page 25: Earth Continuity/Insulation Failure
Test sequence for extension lead 3.6 Earth Continuity/Insulation Failure Possible reasons for failure other than a faulty appliance or lead: • Appliance or lead being tested not correctly connected to the HPAT. • Test probe is not making good contact with the appliance. •... -
Page 26: Testing Of 110V Appliances
3.7 Testing of 110V Appliances A TL157 PAT 110V Adaptor (available separately) is required for testing 110V appliances (yellow BS 4343 16A 110V plug). Refer to the connection diagram below. TL157 110V adaptor Ensure that the appliance is switched ON. Undertake a test sequence as appropriate for the appliance (See 3.1 to 3.4). - Page 27 For this reason, the test of a 110V appliance using the TL157 will always result in a FAIL at the Load check. Check that the appliance is switched ON. Begin the test again if necessary. The user should also have checked the fuse (if fitted). Assuming such checks above have been made, the Class I or Class II appliance test sequence can be continued beyond the simulated load check result by selecting Continue.
-
Page 28: 110V Extension Lead Testing
To test 110V extension leads, the HPAT’s lead test is used with connections as detailed on page 27. Also refer to 3.2 (IEC Lead Test). A Martindale EX331 IEC to 110V adaptor lead, plus TL157 PAT 110V adaptor is required to perform 110V extension lead tests. Test Connections •... - Page 29 For this reason, the lead test of a 110V lead using TL157 will always result in a FAIL on polarity. The lead test will have shown that the earth continuity is satisfactory, and will have tested that the Insulation is satisfactory between centre tapped earth and the two live 55V conductors.
-
Page 30: Maintenance
Martindale Electric recommends that it is returned at least once a year to an approved calibration laboratory for recalibration and certification. Martindale Electric is pleased to offer you this service. Please contact our Service Department for details. Email: service@martindale-electric.co.uk Tel: +44 (0)1923 650660 4.2 Cleaning... -
Page 31: Warranty
5. WARRANTY AND LIMITATION OF LIABILITY This Martindale product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is 2 years and begins on the date of receipt by the end user. This warranty extends only to the original buyer or end-user customer, and does not apply to fuses, disposable batteries, test leads or to any product which, in Martindale’s... -
Page 32: Specification
Specification HPAT550 Range: 0.1MΩ - 100MΩ Resolution: 0.01MΩ (10kΩ-2MΩ), 0.1MΩ (2MΩ-20MΩ), 1MΩ (20MΩ-100MΩ), Accuracy: 5% reading + 2 digits Pass level: Lead: ≥ 1.0 MΩ Class I: ≥ 1.0 MΩ Class II: ≥ 2.0 MΩ POWER 3.7V 5000mAh lithium Batteries:... - Page 33 Specification HPAT650 EARTH CONTINUITY MEMORY Test voltage: >4V DC (into open circuit) Test records: 100 tests stored for on Test current: >200mA DC (into short circuit) screen recall Range: 0 - 20Ω Resolution: 0.01Ω POWER Accuracy: ± (5% reading + 2 digits) 3.7V 5000mAh lithium Batteries: polymer battery (non-user replaceable)
- Page 34 No part of this document shall be deemed to be part of any contract for the equipment unless specifically referred to as an inclusion within such contract. © 2025 Martindale Electric Co. Ltd. Registered in England No. 3387451. LITHPAT-WEB...
