MARTINDALE EZ150: EZ650 Instruction Manual

EZ150 / EZ650
SOCKET TESTER
Thank you for buying one of our products. For safety and full
understanding of its benefits please read this manual before use.
Technical support is available from 01923 441717 and
support@martindale-electric.co.uk.
CONTENTS
1 Introduction
1.1 Inspection
1.2 Description
1.3 Earth Loop Impedance
1.4 Variants
2 Product Specific Safety Information
2.1 Precautions
3 Operation
3.1 Description of Indicators
3.2 Self-Test
3.3 Using the E-Ze Check™ Xtra
3.3.1 Loop Test
3.3.2 Wiring and Voltage Check
3.3.3 RCD's in the Circuit Under Test
3.3.4 Possible Errors when Measuring Earth Loop Impedance
4 Maintenance
4.1 Calibration
4.2 Cleaning
4.3 Repair & Service
4.4 Storage Conditions
5 Warranty
Specifications
I
NSTRUCTION
M
ANUAL
1
1
1
1
3
4
4
6
6
6
7
7
8
11
11
12
12
12
12
12
13
GENERAL SAFETY INFORMATION: Always read before proceeding.
Warning
These instructions contain both information and warnings that are
necessary for the safe operation and maintenance of this product. It is
recommended that you read the instructions carefully and ensure that
the contents are fully understood. Failure to understand and to comply
with the warnings and instructions can result in serious injury, damage
or even death.
In order to avoid the danger of electrical shock, it is important that
proper safety measures are taken when working with voltages
exceeding 30V AC RMS, 42V AC peak or 60V DC.
This product must only be used by a competent person capable of
interpreting the results under the conditions and for the purposes for
which it has been constructed. Particular attention should be paid to the
Warnings, Precautions and Technical Specifications. Always check the
unit is in good working order before use and that there are no signs of
damage to it. Do not use if damaged.
Where applicable other safety measures such as use of protective
gloves, goggles etc. should be employed.
Please keep these instructions for future reference. Updated
instructions and product information are available at:
www.martindale-electric.co.uk/instruct
REMEMBER: SAFETY IS NO ACCIDENT
MEANING OF SYMBOLS:
equipment complies with relevant EU Directives
alternating current (ac)
caution - risk of danger & refer to instructions
end of life disposal of this equipment should be
in accordance with relevant EU Directives
1. INTRODUCTION
1.1 Inspection
Examine the shipping carton for any sign of damage. Inspect the
unit and any accessories for damage. If there is any damage then
consult your distributor immediately.
1.2 Description
The E-Ze Check™ Xtra is a socket tester that additionally checks
the earth loop impedance of the wiring under test, and indicates the
range that the measured earth loop impedance falls within. If the
wiring is faulty the earth loop impedance test is not performed.
The E-Ze Check™ Xtra will also indicate if the mains voltage is below
195V or above 270V.
The 'T Safe' technology employed by the E-Ze Check™ Xtra allows
the earth loop impedance to be measured with a 30mA or higher
RCD in circuit without it tripping.
The E-Ze Check™ Xtra Professional Kit is supplied with both a 13A
3 pin adaptor and a flying lead with croc clips which can be used at
junction boxes and terminals where there is only access to bare wires.
1.3 Earth Loop Impedance
Health and Safety regulations require that electrical installations be
periodically checked for satisfactory operation, and for electricians to
work to the British Standard BS7671, which lays down a schedule
for such testing.
1
