79745
JIG SAW
INSTRUCTION MANUAL
SAVE THIS MANUAL !
You will need this manual for safety instructions, operating procedures and warranty.
Put it and the original sales receipt in a safe dry place for future reference.
120V~60Hz
6.5A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 79745 and is the answer not in the manual?

Questions and answers

Related Manuals for TOLSEN TOOLS 79745

Summary of Contents for TOLSEN TOOLS 79745

  • Page 1 79745 JIG SAW INSTRUCTION MANUAL 120V~60Hz 6.5A SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.

  • Page 2: Important Safety Information

    SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term ”power tool“...
  • Page 3 SAFETY turning the power tool on. A wrench or a key before making any adjustments, changing le attached to a rotating part of the power tool accessories, or storing power tools. Such may result in personal injury. preventive safety measures reduce the risk of 15.

  • Page 4: Jigsaw Safety Warnings

    These carry important safety information. If and birth defects or other reproductive harm. unreadable or missing, contact TOLSEN Tools Some examples of these chemicals are: • Lead for a replacement. from lead-based paints • Crystalline silica from 4.

  • Page 5: Safety And Specifications

    SAFETY AND SPECIFICATIONS Vibration Safety This tool vibrates during use. medical advice as soon as possible. Repeated or long-term exposure to vibration 2.Do not smoke during use. Nicotine reduces the may cause temporary or permanent physical blood supply to the hands and fingers, injury, particularly to the hands, arms and increasing the risk of vibration-related injury.

  • Page 6: Specifications

    SYMBOLOGY AND SETUP SPECIFICATIONS Electrical Rating 120V~60Hz Rated current 6.5A Cutting Power : 800-3200/min Stroke Length 3/4” Max. In Steel 3/8“ Max. In Wood 3” Footplate Tilt 0-45 , le or right Blade Type T-shank Note: Symbology Intertek testing services inc. Double Insulated WARNING mark concerning Risk of Eye Injury.

  • Page 7: Before Use

    SET UP SET UP Before Use Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn the Power Switch of the tool off...

  • Page 8: Blade Installation

    SET UP Blade Installation 1. Refer to the Chart below to select the proper Saw Blade for the material being cut. Blade release lever BLADE SELECTION AND SUITABLE SPEED Material SPEED Dust cover So wood Collet Hardwood Plastic Aluminum Steel Tile Glass Leather...
  • Page 9 SET UP Selecting Cutting Mode 1. The Jigsaw comes with four cutting modes (three 2. The settings are: cutting settings and 1 straight cutting mode). To a. o= Straight line cutting (for plastics and mild change cutting mode, adjust the Orbital Mode steel) Lever (16).
  • Page 10 SET UP Selecting Cutting Mode 1. The Jigsaw is supplied with a Dust Chute adapter for a vacuum. It is attached to the Dust Chute Connector located at the back end of the housing. 2. To fasten the Dust Chute (sold separately) in place, align the pins on Dust Chute with slots in Dust chute Connector.

  • Page 11: Maintenance And Servicing

    MAINTENANCE AND SERVICING MAINTENANCE AND SERVICING TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn the Power Switch of the tool off and unplug the tool from its electrical outlet before performing any inspection, maintenance, or cleaning procedures. TO PREVENT SERIOUS INJURY FROM TOOL FAILURE: Do not use damaged equipment. If abnormal noise or vibration occurs, have the problem corrected before further use.

  • Page 12: Troubleshooting

    TROUBLESHOOTING Troubleshooting Problem Possible Causes Likely Solutions Tool will not start. 1. Cord not connected. 1. Check that cord is plugged in. 2. Check power at outlet. If outlet is 2. No power at outlet. unpowered, turn off tool and check circuit 3.
  • Page 13 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
