- Page 1 87380/87381 LI-ION CORDLESS PRUNING SHEAR INSTRUCTION MANUAL LITHIUM-ION LITHIUM-ION SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. WARNING: This appliance is not intended for use by persons (including children) with reduced, physical or mental capabilities or lack of experience or knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 3: Personal Safety
SAFETY Personal safety 1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. - Page 4 SAFETY Battery Tool Use and Care 1. Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. 2. Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
-
Page 5: Battery Charger Safety
SAFETY Battery Safety WARNING This battery can only be used in the machines included in the TOLSEN MP20V lithium-ion power platform system. This battery can only be used cooperatively with the designated battery charger. Li-lon batteries, if incorrectly used, stored or charged will cause a fire, burn and explosion hazard. Failure to follow these instructions may cause overheating or fire. - Page 6 SAFETY Note: Symbology Class II Double insulated for additional protection CE conformity Read the instruction manual before using Wear hearing protection while operating the tool Wear hand protection Always use breathing apparatus when machining materials which generate dust. Wear ear protection. Operating environmental temperature Max 45 º...
-
Page 7: Specifications
SETUP SPECIFICATIONS Stock No. 87380 87381 (battery and charger sold separately) Rated Voltage Shear capacity Ø20/30mm(3/4"/1-3/16") Ø20/30mm(3/4"/1-3/16") Net weight 2.4kg(5.3lbs) 0.7kg(1.5lbs) Battery pack Voltage 20VDC Battery capacity 2.0Ah Charger 220-240VAC 50/60Hz Input Voltage Output Voltage 21VDC Rated output current 2.0A Charging Time 1hr fast charging(2.0Ah battery) Protection class... -
Page 8: Product Operation
SETUP PRODUCT OPERATION Setting up 1. Open the package, insert the the battery into the power connector of the pruning shear with designated direction, see figure1. 2. Press the power button till the LED display indicator change to green. A er the sound “Di Di-” indicate that is activated. - Page 9 SETUP Battery Charging The battery connected to the charger see figure2, the charger plug Insert a connected to the power socket, the LED indicator on the battery will turn Battery RED during charging and turn GREEN when the battery is fully charged. Cautions 1.
-
Page 10: Maintenance
MAINTENANCE MAINTENANCE CAUTION: Do not let brake fluids, gasoline, petroleum-based materials touch the plastic parts. Chemicals can cause damage to the plastic, and make the plastic unserviceable. CAUTION: Do not use strong solvents or detergents on the plastic housing or components. CAUTION: Remove the battery pack from the machine before maintenance. -
Page 11: Transportation And Storage
TRANSPORTATION AND STORAGE TRANSPORTATION AND STORAGE CAUTION: Remove the battery pack from the machine before tranportation and storage. STORE THE MACHINE • Clean the machine before storage. • Make sure that the motor is not hot when you store the machine. •... -
Page 12: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING problem possible causes Likely Solutions Tool will not 1. Battery Pack not properly 1. Remove Battery Pack, make sure there are no start. connected. obstructions, clean battery contacts on tool, 2. Battery Pack not properly charged. reinsert the Battery Pack according to its shape 3. -
Page 13: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 87380/87381 LI-ION CORDLESS PRUNING SHEAR Complies with the essential health and safety requirements of the following Directices: council directive 2006/42/EC Standards and technical specifications referred to:... - Page 14 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK PRODUCT LINK 87381 87380...
