Summary of Contents for TOLSEN TOOLS 87320
- Page 1 87320 LI-ION CORDLESS INFLATOR INSTRUCTION MANUAL LITHIUM-ION LITHIUM-ION SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. WARNING: This appliance is not intended for use by persons (including children) with reduced, physical or mental capabilities or lack of experience or knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 3 SAFETY Use And Maintenance Of Inflator 1. Before each use, check whether the hose is fragile or worn to ensure that all connections are secure. Do not use if defects are found. Purchase new hoses or notify an authorized service center for inspection or repair. 2.
-
Page 4: Battery Charger Safety
SAFETY 11. Do not attempt to pull or carry the inflator through the hose. 12. In addition to all safety rules of the inflator, all safety regulations recommended by the inflator manufacturer must be observed. Following this rule will reduce the risk of serious personal injury. 13. - Page 5 SAFETY Note: Symbology Class II Double insulated for additional protection CE conformity Read the instruction manual before using Wear hearing protection while operating the tool Wear hand protection Always use breathing apparatus when machining materials which generate dust. Wear ear protection. Waste electrical products should not be disposed of with household waste.
-
Page 6: Functional Description And Specifications
SETUP FUNCTIONAL DESCRIPTION AND SPECIFICATIONS WARNING Disconnect battery pack from tool before making any assembly, adjustments or changing accessories. Such preventive safety measures reduce the risk of starting the tool accidentally. 1 2 3 4 5 1. Digital display 2. Set button 3. - Page 7 SETUP OPERATING INSTRUCTIONS Install battery pack or 12V car power adapter Install or remove the battery pack • (Fig.1) To install: Slide the battery pack into the bottom until you hear a click. Make sure that the latch in place and battery is secure before operation. To remove: Pull out the battery pack while pressing the battery release latch.
- Page 8 SETUP Note: 1.Since the pressure gauge is not calibrated and not binding for exact values, tire pressure must be checked by using a reliable measuring device a er inflating tires with this pump. Driving a vehicle with improperly inflated tires could result in serious injury. 2.
-
Page 9: Maintenance
MAINTENANCE WARNING: ALWAYS disconnect from the mains power supply, before carrying out any maintenance/ cleaning of the charger. Remove the battery before carrying out any maintenance/ cleaning of the tool. Note: Both the tool and the charger contain no user-serviceable parts. If the device does not perform as outlined in this manual, return it to an authorised service centre for repair General inspection - Regularly check that all the fixing screws are tight... -
Page 10: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING problem possible causes Likely Solutions Tool will not 1. Battery Pack not properly 1. Remove Battery Pack, make sure there are no obstructions, clean battery contacts on tool, start. connected. reinsert the Battery Pack according to its shape 2. -
Page 11: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 87320 LI-ION CORDLESS INFLATOR Complies with the essential health and safety requirements of the following Directices: council directive 2006/42/EC Standards and technical specifications referred to:... - Page 12 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. TolsenWorld SCAN TO VISIT MADE IN CHINA PRODUCT LINK...
