Summary of Contents for Truper CEPEL-3-1/4A4
- Page 1 Manual Electric planer 6.7 A Motor Applies for: Code Item 100502 CEPEL-3-1/4A4 CEPEL-3-1/4A4 Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Contents CAUTION Technical data Power requirements To gain the best performance of the tool, prolong the duty life, General safety warnings make the Warranty valid if for electric tools necessary, and to avoid hazards of fatal injuries please read and Safety warnings for the understand this manual before use of electric planers... -
Page 3: Technical Data
The thermal insulation class of the motor windings: Class E WARNING If the power cable is damaged, it must be replaced by the manufacturer or a TRUPER Service Center to prevent any risk of electric shock or significant accident. The electrical insulation of this tool is compromised by splashes or spillage of liquids during its operation. -
Page 4: General Safety Warnings For Electric Tools
Service risk of personal injury. Repair the tool in a TRUPER Authorized Service Center using only identical spare parts. This will ensure that the safety of the power tool is maintained. -
Page 5: Safety Warnings
Safety warnings for the use of electric planers Before operating the tool While operating the tool • Fully unwind the extension cord to prevent potential • Whenever possible, use a dust extraction system. CAUTION overheating. • When operating the tool, hold it only •... -
Page 6: Parts
Parts Auxiliary Switch handle lock Handle Safety Power cord lock protector Switch Depth adjustment knob Adjustable base Power cord 2.5 mm Parallel guide Belt hex key locking knob cover Fixed base Foot support 8 mm wrench Blades Blade Block support Height control screws Fixed... -
Page 7: Preparation
• Handle the blades with extreme care. Wear gloves or cloths to protect your fingers or hands when removing or installing them. • Only the TRUPER wrench is used to install or remove the blades. Otherwise, you might over-tighten or under-tighten the mounting bolts, causing injury. - Page 8 Preparation Blade leveling The blades should be adjusted to the height of the base (D). If not, follow these instructions: • Slightly loosen the adjustment screws (A) with the 8 mm wrench. • Using the included 2.5 mm hex key, turn the height control screws (E) clockwise to raise and counterclockwise to lower, as needed for your planer.
-
Page 9: Installation Of The Dust Collection Bag
Preparation Installation of the parallel guide • Place the parallel guide (A) on the opposite side of the depth guide. • Secure the parallel guide in place with a locking knob (B). Installation of the depth guide • Place the depth guide (C) on the opposite side of the parallel guide (A). -
Page 10: Start Up
Preparation Vacuum cleaner installation (Ejector port not compatible with TRUPER vacuum cleaners) • You can connect a vacuum cleaner to the chip ejector port instead of using the dust collection bag for more effective performance and cleaner operation. • Connect a vacuum hose to the nozzle, as shown in the image. - Page 11 Start up Planing operation instructions • Firmly grasp the depth adjustment knob with one hand and place your other hand on the handle. • Place the adjustable base on the workpiece's surface without letting the blades contact it (1). • Turn on the tool and wait for the blades to reach maximum speed.
-
Page 12: Support Foot
• When changing carbon brushes, always replace both • Periodically check the power cord for any damage. If it is brushes. damaged, have the cord replaced at a TRUPER Authorized Service Center. Service • Tool servicing should only be carried out at an Authorized TRUPER Service Center. -
Page 13: Replacement Parts
Maintenance Replacement parts Part Code Item Tungsten carbide 100649 CU-CE-3-1/4 blades Steel 26126 CU-CE-3-1/4P bledes Holders 101224 SUJ-CE-3-1/4A4 Support 101225 JGO-CE-3-1/4A4 block 101222 INT-CE-3-1/4A4 Switch Parallel 101226 GUIA-CE-3-1/4A4 guide Dust 101227 BOL-CE-3-1/4A4 collection Belt 101223 BAN-CE-3-1/4A4 Replacement 101830 CB--CE-3-1/4A4 carbon brushes ENGLISH... -
Page 14: Notes
Notes ENGLISH... -
Page 15: Authorized Service Centers
Authorized service centers In the event of any problem contacting a TRUPER Authorized Service Center, please see our webpage WWW.TRUPER.COM to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center. -
Page 16: Warranty Policy
It includes the costs of transportation of the product that derive from its fulfillment of its service network. . Phone number 800-018-7873. Made in China. Imported by TRUPER, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
