- Page 1 Manual Electric hand planer 1.3 Hp Power Applies for: Code Model 13089 CEPEL-4-1/2NX CEPEL-4-1/2NX Read the user’s manual thoroughly CAUTION before operating this tool.
-
Page 2: Table Of Contents
Manual before Parts using the tool. Assembly Keep this manual for future references. Start Up The illustrations in this manual are for reference Maintenance only. They might be different from the real tool. Notes Authorized Service Centers Warranty Policy CEPEL-4-1/2NX ENGLISH... -
Page 3: Technical Data
Technical Data CEPEL-4-1/2NX Code 13089 Description Electric Planer Voltage 127 V Frequency 60 Hz Current 7.5 A Power 1.3 Hp Speed 16 000 RPM Dust Collecting System Left-Right Planing Depth: 0” – 0.11” | Width: 4 1/2” Depth levels 12 levels, 0.009” each one Duty Cycle 50 minutes’... -
Page 4: General Power Tool Safety Warnings
General power tool safety warnings WARNING! Read carefully all safety warnings and instruction listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For Electric Planers
Safety Warnings for Electric Planers Before Operating the Tool While Operating the Tool • Unroll completely the extension cable to prevent • When possible, use a dust extraction system. potential overheating. CAUTION • When operating the tool, hold it only •... -
Page 6: Parts
Parts Auxiliary Shaving Outlet Switch Handle Selector Lock Handle Shavings Switch Exhaust Cutting Depth Adjusting Knob Adjustable Power cord Base protector Power Cord Parallel Guide Cutter Head Fixed Fastening Knob Guard Base Rest stand Spanner Parallel Guide Blade Supporting Block Fixed Base Blades... -
Page 7: Assembly
Before installing the blades turn off and disconnect the tool, clean chips or any foreign matter from the cutting head. Use Truper® replacement blades with the same dimensions and weight, or the cutting head will oscillate and vibrate, causing por cutting or machine breakage. -
Page 8: Start Up
Start Up Start and Operation Control • Connect the plug into the power outlet. • Keep the switch lock (B) pressed to unblock the switch (A). The switch lock prevents from accidentally starting up the tool. • Press the switch (A) to start the cutter head in motion. •... -
Page 9: Maintenance
Start up Bevel Cuts • For bevel cuts or chamfers, match the work piece edge with one of the two slots in "V" in the adjustable base. • Make passes with the planner aligning the notch on the edge. Maintenance WARNING Disconnect the cable from the power Service... -
Page 10: Notes
Notes ENGLISH... -
Page 11: Authorized Service Centers
Authorized service centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 0187-873 to get information about the nearest Service Center. -
Page 12: Warranty Policy
06060, where you can also purchase parts, components, consumables and accessories. The costs of transportation of the product that derive from its fulfillment of its service network are included. Truper will not require any proof of purchase to make the warranty effective. Phone number 800-018-7873. Made in China.
