- Page 1 Manual Electric hand planer 0.9 Hp Power Applies for: Code Model 102800 CEPEL-3-1/4N2 CEPEL-3-1/4N2 Read the user’s manual thoroughly CAUTION before operating this tool.
-
Page 2: Table Of Contents
Contents CAUTION Technical data Power requirements To gain the best performance of the tool, prolong the duty life, General power tool safety warnings make the Warranty valid if necessary, and to avoid hazards Safety warnings for electric planers of fatal injuries please read and understand this Manual before Parts using the tool. -
Page 3: Technical Data
Avoid the risk of electric shock or severe injury. When the power cable gets damaged it should only be replaced by the manufacturer or at a Truper Authorized Service Center. The build quality of the electric insulation is altered if spills or liquid gets into the tool while in use. -
Page 4: General Power Tool Safety Warnings
Service Repair the tool in a TRUPER Authorized Service Center using Prevent unintentional starting up. Ensure the switch is in the only identical spare parts. “OFF” position before connecting into the power source and / This will ensure that the safety of the power tool is maintained. -
Page 5: Safety Warnings For Electric Planers
Safety warnings for electric planers Before operating the tool While operating the tool • Unroll completely the extension cord to prevent potential • When possible, use a dust extraction system. overheating. CAUTION • When operating the tool, hold it only •... -
Page 6: Parts
Parts Lock-off switch Shavings outlet selector Shavings Handle exhaust Power cord Switch protector Cutting depth adjusting knob Adjustable base Power cord Rest support Parallel guide Transmission Fixed base Spanner holder fastening knob band guard Spanner Blades Blade Supporting block Fixed base Blades adjusting... -
Page 7: Preparation
Preparation Blades set up The blades must be adjusted so that the cutting edge is level with the fixed base. (See “Blade leveling” below). ATTENTION • Always make sure the tool is turned off and unplugged before making any adjustments to it. •... - Page 8 Preparation Replacement of jaws 1: The blades must be adjusted so that the cutting edge is level with the fixed base see “Blade leveling”. 2: Remove the blade holder displacing it to the right (G). 3: Assemble the fastener to the blade holder to ensure the doble pines have a coincidence (H).
- Page 9 • Connect the vacuum hose to the nozzle as shown in lightly tap it to remove particles stuck inside. the image. • Connecting a vacuum to this tool may result in more • The port is not compatible with Truper line vacuum efficient performance and cleaner operation. cleaners. vacuum installation...
-
Page 10: Start Up
Start up Start and operation control • Connect the plug into the power outlet. • Keep the lock-off switch (B) pressed to unlock the switch (A). The lock-off switch prevents from accidentally starting up the tool. • Press the switch (A) to start the cutter head in motion. •... -
Page 11: Maintenance
• Carbon Brushes should be periodically checked and Cleaning and care when worn, replaced always in a TRUPER Authorized Service Center. • Keep the tool dust-free. Never use water or chemical • After replacing the carbon brushes request to inspect if substances to clean the tool. - Page 12 Maintenance Replacements Replacement Code Item 100649 CU-CE-3-1/4 Tungsten carbide blades (2 pieces) 101264 INT-CE-N Switch 101290 GUIA-CE-3-1/4N Parallel guide 101291 BOL-CE-3-1/4N Dust collecting pouch 101266 BAN-CE-3-1/4N Replacement belt 101267 JGO-CE-3-1/4N Blade holder set ENGLISH...
-
Page 13: Authorized Service Centers
Authorized service centers In the event of any problem contacting a TRUPER Authorized Service Center, please see our webpage WWW.TRUPER.COM to get an updated list, or call our toll-free numbers 800 690-6990 or 800-018-7873 to get information about the nearest Service Center. -
Page 14: Warranty Policy
06060, where you can also purchase parts, components, consumables and accessories. The costs of transportation of the product that derive from its fulfillment of its service network are included. TRUPER will not require any proof of purchase to make the warranty effective. Phone number 800-018-7873. Made in China.
