Quick Guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.whirlpool.eu/register
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
CONTROL PANEL
1. ON-OFF/Reset button with indicator light
2. PREVIOUS program button
3. NEXT program button
4. Power Clean® option button with indicator light
5. Salt reservoir empty indicator light
6. Rinse Aid reservoir empty indicator light
7. DESCALE indicator light
8. Closed Water Tap indicator light
9. Display
10. Program number and remaining time indicator
11. Keylock indicator light
12. Prewash phase indicator light (lights up when
the phase is active)
FIRST TIME USE
SETTING MENU
1. Switch on the appliance by pressing the ON-OFF
2. Hold the Settings
(Half Load
a beep and the display shows „SEt".
3. After one second the first available setting (letter „
4. Press PREVIOUS /NEXT to scroll through the list of available settings
(see table below), then press START/Pause
value of the currently selected setting.
5. Press PREVIOUS /NEXT to change the value, then press START/Pause
to save the new value and return to the main menu.
6. To change another setting, repeat points 4 and 5.
7. Press ON-OFF
or wait 30 seconds to exit the menu.
LETTER
SETTING
Cycle Counter - number of washing cycles
carried out by the dishwasher.
Water Hardness Level (see "SETTING THE WA-
TER HARDNESS" and "WATER HARDNESS TABLE")
Rinse Aid Level
(see "ADJUSTING THE DOSAGE OF RINSE AID")
NaturalDry (see "OPTIONS AND FUNCTIONS")
"1" = On
"1" = On
Factory Settings - press START/Pause to re-
store to the factory default all the values of the
settings included in the settings menu.
*) The default value does not apply to the Cycle Counter.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine's functional components.
The salt reservoir is located in the lower part of the dishwasher (under the
lower rack on the left side).
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
• Salt must be filled when the SALT REFILL indicator light
panel is lit.
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Position the funnel (see figure) and fill the salt reservoir
right up to its edge (approximately 0,5 kg); it is not un-
usual for a little water to leak out.
3. Only the first time you do this: fill the salt reservoir
with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly so that no detergent can get into
the container during the wash program (this could damage the water sof-
tener beyond repair).
Run a program every time as soon as you completed refilling the salt
reservoir to avoid corrosion.
W20007525 Console 2024-09-11
W20008380 Console cover 2024-10-03
button.
W20009222 Button RH 2024-08-29
) button for 3 seconds, until you hear
W20008433 Buttons LH 2024-08-29
W20008462 Display 2024-10-09
") will be displayed.
to view and change the
, "0" = Off
Sound
, "0" = Off
1
2
3
1
2
3
13. Natural Dry indicator light (lights up when not active or not available in the program)
14. Sound indicator light
15. Half Load option button with indicator light / Settings - 3 sec. press
16. Extra Dry option button with indicator light / Keylock - 3 sec. press
17. Delay option button with indicator light
18. START/Pause button with indicator light
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on the heater, contributing also to better cleaning ef-
ficiency. This system regenerates itself with salt, therefore it is required
to refill the salt container when empty.
The frequency of regeneration depends on the water hardness level setting
- regeneration takes place once per 4-6 Eco cycles with the water hardness
level set to 3. The regeneration process occurs at the beginning of the cycle
with additional fresh water.
• Single regeneration consumes ~3 L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
VALUES
(Default - in bold)*
Eg. 25 cycles: 25;
Eg. 13.947 cycles:
13_947 (scrolling
for 3 times)
1 | 2 | 3 | 4 | 5
0 | 1 | 2 | 3 | 4 | 5
1 | 0
FILLING THE DETERGENT DISPENSER
1 | 0
-
D
C
2. Remove detergent residues from the edges of the dispenser and close
the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until the closing
device is secured in place.
The detergent dispenser automatically opens up at the right time accord-
ing to the program.
on the control
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
4
5 6 7 8 9
10
11 121314
4
5 6 7 8 9
10
11 121314
More information in the Daily Reference Guide on website.
FILLING THE RINSE AID DISPENSER
B
Rinse aid makes dish DRYING easier. The rinse aid dis-
penser A should be filled when the RINSE AID REFILL
indicator light
in the control panel is lit.
1. Open the dispenser B by pressing and pulling up
the tab on the lid.
2. Pour in the rinse aid (max. 110 ml), making sure it
does not overflow from the dispenser. If this hap-
pens, clean the spill immediately with a dry cloth.
3. Press the lid down until you hear a click to close it.
NEVER pour the rinse aid directly into the appli-
A
ance tub.
To open the detergent dispenser use the opening
device C. Introduce the detergent into the dry dis-
penser D only. Place the amount of detergent for
pre-washing directly inside the tub.
1. When measuring out the detergent refer to the
mentioned earlier information to add the proper
quantity. Inside the dispenser D, there are indica-
tions to help the detergent dosing.
EN
15
16
17
18
15
16
17
18
