Quick Guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.whirlpool.eu/register
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
CONTROL PANEL
1. On-Off / Reset button with indicator light
2. Program selection button with indicator light
3. Multizone button with indicator light / Keylock
4. Eco program indicator light
5. Keylock indicator light
6. Display
7. Program number and remaining time indicator
8. Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid refill indicator light
11. Salt refill indicator light
FIRST TIME USE
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine's functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
filled when the SALT REFILL indicator light
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Only the first time you do this: fill the salt reservoir
with water.
3. Position the funnel (see figure) and fill the salt reservoir
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into
the container during the wash program (this could damage the water sof-
tener beyond repair).
Whenever you need to add salt, it is mandatory to complete the pro-
cedure before the beginning of the washing cycle to avoid corrosion.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently prevent-
ing scale buildup on heater, contributing also to better cleaning efficiency.
PROGRAMS TABLE
Eco 50°- Program is suitable to clean normally soiled tableware, that for
this use, it is the most efficient programme in terms of its combined en-
1.
ergy and water consumption, and that it is used to assess compliance
with the EU Ecodesign legislation.
Intensive 65° - Program recommended for heavily soiled crockery, es-
2.
pecially suitable for pans and saucepans.
6th Sense® 50-60°- For normally soiled dishes with dried food residues.
3. Senses the level of soiling on the dishes and adjusts the program ac-
cordingly.
Fast Wash&Dry 50° - Normally soiled crockery. Everyday cycle, that ensu-
4.
res optimal cleaning and drying performance in shorter time.
Crystals 45° - Program for delicate items, which are more sensitive to
5.
high temperatures, for example glasses and cups.
Rapid 30' 45° - Program to be used for half load of lightly-soiled dishes
6.
with no dried food residues. Without drying.
Silent 50° - Suitable for night-time operation of the appliance. With the
7.
lowest noise.
Sanitizing 65° - Normally or heavily soiled crockery, with additional anti-
8.
bacterial wash. Can be used to perform maintenance of the dishwasher.
Prewash - Use to refresh crockery planned to be washed later.
9.
No detergent to be used with this program.
1
12. Power Clean® button with indicator light / Tablet (Tab)
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
in the control panel is lit.
Programs description
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
2 3 4 5 6 7
More information in the Daily Reference Guide on website.
This system regenerates itself with salt, therefore it is required to refill
salt container when empty.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in final rinse and finishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid
dispenser A should be filled when the RINSE AID
D
REFILL indicator light
C
NEVER pour the rinse aid directly into the appli-
A ance tub.
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device C. Introduce the
detergent into the dry dispenser D only. Place the amount of detergent for
pre-washing directly inside the tub. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the program so
that the best washing and drying results are always achieved.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
Available options
-
-
- -
8 9 10 11 12 13
in the control panel is lit.
Duration
Water con-
of wash
sumption
*)
program
(litres/cycle)
(h:min)
**)
3:35 8.7
2:45 17.5
1:20 - 3:00 7.0 - 14.0
1.25 11.5
1:40 12.0
0:30 9.0
3:30 16.0
1.50 12.0
0:10 4.5
EN
14
Energy con-
sumption
(kWh/cycle)
0.63
1.60
0.70 - 1.10
1.10
1.20
0.50
1.15
1.30
0.01
