- Page 1 Cover Page LF212 LF212 LF212 LF212 & & & & LF412 LF412 LF412 LF412 USER MANUAL USER MANUAL USER MANUAL USER MANUAL...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ..............................2 LF212 ................................2 LF412 ................................3 REAR PANEL ............................... 4 CONNECTIONS ............................4 SPECIFICATIONS ............................... 5 LF212 ................................5 INTERNAL CONNECTIONS ......................... 5 DIMENSIONS (in mm) ........................... 6 LF412 ................................7 INTERNAL CONNECTIONS ......................... 7 DIMENSIONS (in mm) ........................... 8 SAFETY AND WARNINGS .......................... -
Page 3: Introduction
INTRODUCTION Everything you need. Nothing you don’t. Introducing the LF212 and LF412 matching Lionheart cabinets. LF212 The open backed LF212, delivers uncompromising performance and robust durability in a 2x12 configuration. The LF212 produces a lovely warm low-end, a creamy rich vocal mid-range and a sparkling, beautifully detailed top-end and can be used whatever the style of music you choose to play. -
Page 4: Lf412
960W, providing impact and clarity for demanding players. ROAD READY As with all Laney cabinets, the LF412 features robust construction with a hard-wearing vinyl finish and stainless-steel metal corners, the LF412 combines muscular durability with exceptional sound reproduction. -
Page 5: Rear Panel
REAR PANEL INPUT SOCKET - Use a good quality speaker cable to make the connection between the amplifier and LF212 or LF412 cabinet. NOTE: the speaker's impedance should match or slightly exceed the amplifier's recommended output impedance range. For example, if an amplifier output is rated for 4 speakers, using 4 or 8 higher speaker cabinet is recommended. -
Page 6: Specifications
SPECIFICATIONS LF212 Model LF212 Woofer Size 2x12" HH Designed High Performance driver - H1260 Nominal Cabinet Impedance 4 Ohm Power Rating1 120W RMS, 240W Continuous, 480W Peak Input Connector 6.3mm Jack Socket Main Construction Material Robust composite wood construction (15mm MDF) Finish Hard wearing Vinyl finish with stainless steel metal corners Unit dimensions (HWD) -
Page 7: Dimensions (In Mm)
DIMENSIONS (in mm) Page 6... -
Page 8: Lf412
LF412 Model LF412 Woofer Size 4x12" HH Designed High Performance driver - H1260 Nominal Cabinet Impedance 4 Ohm Power Rating1 240W RMS, 480W Continuous, 960W Peak Input Connector 6.3mm Jack Socket Main Construction Material Robust composite wood construction (15mm MDF) Finish Hard wearing Vinyl finish with stainless steel metal corners Unit dimensions (HWD) -
Page 9: Dimensions (In Mm)
DIMENSIONS (in mm) Page 8... -
Page 10: Safety And Warnings
1) Unpacking: On unpacking your product, please check carefully for any signs of damage that may have occurred whilst in transit from the Laney factory to your dealer. In the unlikely event that there has been damage, please re-pack your unit in its original carton and consult your dealer. - Page 11 1) This device may not cause harmful interference. 2) This device must accept any interference received, that may cause undesired operation. Warning: Changes or modification to the equipment not approved by Laney can void the user's authority to use the equipment.
- Page 12 LANEY ELECTRONICS LTD. STEELPARK ROAD, COOMBSWOOD BUSINESS PARK WEST, HALESOWEN, B62 8HD. UK FOR THE LATEST INFORMATION PLEASE VISIT WWW.LANEY.CO.UK IN THE INTEREST OF CONTINUED DEVELOPMENT, LANEY RESERVES THE RIGHT TO AMEND PRODUCT SPECIFICATION WITHOUT PRIOR NOTIFICATION. V1.0 Page 11...
