- Page 1 AH2500D ALL-IN-ONE AUDIO SOLUTION...
- Page 2 Laney endorsees that includes some of the world’s most famous and respected musicians. At the same time we believe we have not lost sight of the reason Laney was founded in the first place - a dedication to building great sounding amplification for working musicians.
- Page 3 SN:ABC1234567890 The Audiohub Venue – Clarity & Convenience. This manual contains important information regarding correct and safe operation of your active system. Please read it thoroughly in order to get the best performance and reliability from your new Laney product.
-
Page 4: Power And Speaker Connections
SETTING UP ACCESS TO THE MIXER AND ACCESSORY BOX: POWER AND SPEAKER CONNECTIONS Slide the catch to the left as indicated. FUSE The mains inlet, power switch and fuse are located to the right of the mixer. SUPPLY VOLTAGE AND FUSE RATING: PLEASE NOTE: 220-240V~ 50/60Hz T3.15A L 250V MAXIMUM POWER CONSUMPTION - 300 WATTS... - Page 5 APPLICATIONS CH5/6 MIX OUT LINE LINE LINE LINE PHANTOM POWER RH SPEAKER LEVEL CH5/6 + MEDIA PLAYER TREBLE TREBLE TREBLE TREBLE TREBLE EFFECT BASS BASS BASS BASS BASS LIMITER SIGNAL LH SPEAKER EFFECT EFFECT EFFECT EFFECT DOWN SELECT POWER PEAK PEAK PEAK PEAK...
- Page 6 CH5/6 MIX OUT RH SPEAKER LINE LINE LINE LINE PHANTOM POWER LEVEL CH5/6 + MEDIA PLAYER TREBLE TREBLE TREBLE TREBLE TREBLE EFFECT BASS BASS BASS BASS BASS LH SPEAKER LIMITER SIGNAL EFFECT EFFECT EFFECT EFFECT DOWN SELECT POWER PEAK PEAK LEVEL LEVEL LEVEL...
-
Page 7: Control Panel
CONTROL PANEL 1-4: MONO INPUT CHANNELS. 5. COMBI INPUT: For use with both low level/low impedance devices eg. - mic (200- 600ohms), electro-acoustic guitar or line level devices. This input will accept a balanced/ unbalanced signal via XLR, or 6.35mm jack plug. CH5/6 MIX OUT 6. -
Page 8: Media Player
CONNECT TO AN EXTERNAL BLUETOOTH DEVICE: a. Select Bluetooth via the MODE button (4). b. On your Bluetooth capable device, make sure Bluetooth is enabled. Scan down the list of available devices - search for: ‘Laney Audiohub’ and select. No password required. -
Page 9: Block Diagram
BLOCK DIAGRAM PEAK LINE INPUT INDICATOR LEVEL BASS TREBLE LEVEL MIC INPUT DSP MODULE PEAK LINE INPUT INDICATOR LEVEL BASS TREBLE LEVEL MASTER FX LEVEL MIC INPUT PEAK PEAK LINE INPUT INDICATOR INDICATOR LEVEL BASS TREBLE LEVEL MONITOR - L MIC INPUT PEAK LINE INPUT... - Page 10 MOUNTING All cabinets should be balanced and steady. Don't over-extend poles/tripods; ensure at least 4 x the pole diameter is still inside the outer pole. Make sure the legs have a good splay on tripods, but do not obstruct doorways or other access-ways.
-
Page 11: Specifications And Features
Carton dimensions (HWD) : 55.5 x 63.5 x 36.5 CM 21.9" x 25" x 14.4" , 0.129 M3 Packed weight : 19.7Kg, 43.4 lbs In the interest of continued development, Laney reserves the right to amend product specification without prior notification. -
Page 12: Safety Information
SAFETY INFORMATION... - Page 17 MODEL NUMBER: SERIAL NUMBER: PLACE OF PURCHASE: DATE OF PURCHASE: PLEASE COMPLETE FOR FUTURE REFERENCE revision 1.00...
