Summary of Contents for Laney AudioHub AH110
- Page 1 AH115 AH112 AH110 ACTIVE LOUDSPEAKER...
- Page 3 At the same time we believe we have not lost sight of the reason Laney was founded in the first place - a dedication to building great sounding amplification for working musicians.
-
Page 4: Important Safety Instructions
Important Safety Instructions WARNING: When using electrical products, basic cautions should always be followed, including the following: 1. Read these instructions. 2. Keep these instructions safe. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. - Page 5 Please retain your original carton and packaging so in the unlikely event that some time in the future your amplifier should require servicing you will be able to return it to your dealer securely packed. Care of your Laney amplifier will prolong it's life..and yours!
- Page 6 Introduction AH110 The Laney Audiohub Venue range of enclosures is designed for high performance in a wide variety of demanding audio applications. The Audiohub Venue range is ideally suited for uses in classrooms, business seminars and presentations, worship meets, parties, bars, BBQ's and musical performances.
- Page 7 Applications Music from the Media player. USB/SD PLAYER HOLD ON USB/SD/BT OFF MODE Connection and control of a CH 1 CH 2 CH 3 MASTER CH 1 CH 2 CH 3 MASTER Bluetooth device using the Media ® player. LEVEL LEVEL LEVEL VOLUME...
-
Page 8: Daisy Chaining
CH 1 CH 2 CH 3 MASTER Daisy chaining. Any number of AudioHubs can be LEVEL LEVEL LEVEL VOLUME connected in this way. Initially set CH1 LEVEL control for AH1to zero. AUX IN TREBLE LINE LINE Set the CH1 LEVEL for AH2 and AH3 to Slowly turn up the CH1 LEVEL control BASS on the AH1 to achieve the desired level. -
Page 9: Media Player Controls
® b. On your Bluetooth capable device, make sure bluetooth is enabled. Scan down the list of available devices - search for: Laney Audiohub and select. c. Your AudioHub is now connected to your bluetooth device & controlled using the PLAY/PAUSE, PREVIOUS & NEXT BUTTONS ®... -
Page 10: Rear Panel Controls
Rear Panel Controls 1/2. CH1 & CH2: Mono Input channels. CH 1 CH 2 CH 3 MASTER 3. LEVEL: Use the Level control to set the channel volume.. 4. LINE INPUT: an unbalanced input - for higher output line level devices eg. - keyboard, processor, LEVEL LEVEL LEVEL... -
Page 11: Block Diagram
Block Diagram 110-120V - Operation 220-240V - Operation 220-240 Fuse type: Fuse type: 110-120 220-240 F2.5A L 250V F3.15A L 250V Slide out fuse Alignment of triangles indicates selected voltage. holder. Always switch off and disconnect the power cord when not in use. -
Page 12: Dimensions And Mounting
Dimensions and mounting (Stand not included) All cabinets should be balanced and steady. Thumb screw Don't over-extend poles/tripods; ensure at least 4 x the pole diameter is still inside the outer pole. Make sure the legs have a good splay on tripods, but do not obstruct doorways or other access-ways. -
Page 13: Specifications
Specifications Maximum output: 200W 400W 400W Frequency range: 20Hz-20kHz 20Hz-20kHz 20Hz-20kHz Woofer 10" 12" 15" Tweeter 1" compression driver 1" compression driver 1" compression driver Power Consumption: 160Watts (maximum) 320Watts (maximum) 320Watts (maximum) Operating Voltage Range: ~100V - (Factory option) ~100V - (Factory option) ~100V - (Factory option) ~120V or 220V/230V/240V... - Page 14 This device may not cause harmful interference This device must accept any interference received, that may cause undesired operation. Warning: Changes or modification to the equipment not approved by Laney can void the user's authority to use the equipment. Note: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 15 Notes...
- Page 16 Model number: Serial number: Place of purchase: Date of purchase: Please complete for future reference...
