- Page 1 OPERATION MANUAL FOR HANDI-LIFT ML9 Original Version...
-
Page 2: Table Of Contents
Handi-lift ML9 Table of contents 1 Introduction ............................4 1.1 Congratulations on your new CAMA Handi-Lift ................. 4 1.2 Diagram of Handi-Lift ML9 ........................ 4 1.3 General information about the lift ....................5 1.4 Before you use the Handi-Lift ........................6 2 Operating the Handi-Lift ML9 ...................... - Page 3 6 Warnings ...............................17 7 Service ..............................17 8 Cleaning ..............................17 9 DATA for Handi-Lift ML9 ........................18 9.1 Serial Number............................18 9.2 Measurements of Handi-Lift ML9 ....................18 9.3 Technical specifications........................18 9.4 Manufacturer ............................19 © 2023 Page 3 Version 1...
-
Page 4: Introduction
Thank you for choosing a CAMA Handi-Lift. Please read these operating instructions carefully before you start to use the lift. Your CAMA Handi-Lift has been constructed with careful attention to detail. For many years of trouble-free use of the lift, please follow the instructions paying special attention to the care and maintenance requirements. -
Page 5: General Information About The Lift
Handi-lift ML9 1.3 General information about the lift Type ML9 is a fully automatic lift, where the user does not need to carry out any manual operation, all the operations are electrically controlled. The Handi-Lift consists of a tower and a lift trolley with folding platform. The lift is equipped with safety arms and flaps on the front and rear of the platform. -
Page 6: Before You Use The Handi-Lift
Handi-lift ML9 1.4 Before you use the Handi-Lift The lift is equipped with various safety measures which must be tested before using the lift. If the safety measures do not work, the lift must not be used, and you should contact your service centre. -
Page 7: Operating The Handi-Lift Ml9
Handi-lift ML9 2 Operating the Handi-Lift ML9 2.1 Operation from the lift's control panel 1) Emergency stop 2) Joystick 3) *Connection for remote control with spiral wire 4) Emergency call 5) Light diode 6) *Key lock * Extra equipment (not standard on all lifts). -
Page 8: Joystick
Handi-lift ML9 2.1.2 Joystick You use the joystick (No. 2 on the drawing in section 2.1) on the Handi-Lift by pushing the joystick in the desired direction. The Handi-Lift stops automatically when it reaches the top or bottom stop. Note! If the joystick is released while travelling, the lift will stop, and it will take a few seconds before the joystick can start the lift again. -
Page 9: Operation From The Control Box On The Wall Or Column
Handi-lift ML9 2.2 Operation from the control box on the wall or column 1) Up 2) Down 3) Open 4) Close 5) Key Lock 6) Green LED The control boxes can vary in appearance, but the symbols for the functions are the same on all types of boxes. -
Page 10: Down
Handi-lift ML9 2.2.1 Up The Up button (No. 1 on the drawing in section 2.2) is used to move the lift up, the button must be pressed and held down to get the lift to move. If the button is released while travelling, you should wait a few seconds before the button will activate the lift again. -
Page 11: Key Lock
Handi-lift ML9 2.2.5 Key lock Operation w/battery supply The key lock (No. 5 in the drawing in section 2.2) is used to lock the control box and only this control box. By turning the key lock, you turn on the power supply to the control box. -
Page 12: Down
Handi-lift ML9 2.3.1 Up Press the Up button and hold it down (No. 1 on the drawing in section 2.3). This will make the lift go up. 2.3.2 Down Press the Down button and hold it down (No. 2 on the drawing in section 2.3). -
Page 13: Down
Handi-lift ML9 2.4.2 Down The Down button (No. 2 in the drawing in section 2.4) is used to move the lift down. The Down button works in the same way as the Up button, except that it moves the lift down. -
Page 14: Emergency Raise Of The Platform
Handi-lift ML9 parked at the bottom of the stairs. Contact your dealer if you have emergency raised the barrier arm. 3.2 Emergency raise of the platform Remove the rubber plug in the left side of the lifts front cover (pos. 12 on the drawing in section 1.2); Put the screwdriver in the hole and turn it clockwise to raise the platform (close the platform). -
Page 15: Emergency Opening Door
Handi-lift ML9 3.4 Emergency opening door EMERGENCY Losen the two indicated screws on the OPENING door column. After that the door will move freely. 4 Additional equipment 4.1 Folding seat Mobility-impaired persons may use a folding seat (No. 6 on the drawing in section 1.2). -
Page 16: What To Do If Your Lift Is Not Working
Handi-lift ML9 5 What to do if your lift is not working If the scheme below does not solve the problem, please contact your maintenance company. Problem Cause Solution The lift will not Turned off at the main Turn on the safety switch... -
Page 17: Warnings
7 Service The Handi-Lift is supplied fully installed and tested by specially trained personnel authorized by Cama. In Denmark the frequency of the mandatory inspections after installation will be determined by an independent person. However, Cama would recommend that the Handi-Lift is serviced at least once a year. Any faults found between the regular inspections must be immediately notified to the supplier or a person authorized by the supplier. -
Page 18: Data For Handi-Lift Ml9
Be aware that excess water can cause problems if it comes in contact with the lift's electrical components. 9 DATA for Handi-Lift ML9 9.1 Serial Number Your Handi-Lift has serial number: 9.2 Measurements of Handi-Lift ML9... -
Page 19: Manufacturer
Handi-lift ML9 Name plate. (No. 10 on the drawing in section 1.2) 9.4 Manufacturer CAMA Lift ApS Ellehammervej 6 9900 Frederikshavn Denmark Telephone: +45 98 43 01 22 Web: www.cama.dk E-mail: cama@cama.dk We reserve the right to make changes to the product.
