Sealey SA9302.V2 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
1. SAFETY
Disconnect the gauge from the air supply before changing accessories, servicing or performing any maintenance.
9
Maintain the gauge in good condition (use an authorised service agent), and keep the gauge clean for best and safest performance.
9
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Locate gauge in a suitable work area, keep area clean and tidy and free from unrelated materials and ensure there is adequate lighting.
9
Keep children and unauthorised persons away from the work area.
9
DO NOT direct gauge outlet at yourself or at other persons or animals.
8
DO NOT carry by the hose, or yank the hose from the air supply.
8
DO NOT use the gauge for a task which it is not designed to perform.
8
DO NOT operate the gauge when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
DO NOT operate gauge if parts are missing or the gauge is damaged, as this may cause failure and/or personal injury.
8
2. INTRODUCTION
Durable body tyre inflators with large Ø80mm gauge with rubber protectors. Calibrated in bar/psi. Fitted with 750mm and 400mm
rubber hoses with respective push-on and clip-on connectors. Includes 1/4"BSP connection. Model No's SA9304 and SA9314 feature
anti-shock, high accuracy oil filled gauges. Model No's SA9302 and SA9312 feature rotating gauge for ease of use and visibility.
3. SPECIFICATION
Model No:
Inlet Size:
Maximum Air Supply:
Range:
Gauge
SA9302.V2 SA9304
© Jack Sealey Limited
TYRE INFLATORS WITH PUSH-ON AND CLIP-ON
CONNECTORS
MODEL NO'S:
SA9302.V2 SA9304
1/4"BSP 1/4"BSP
8bar (117psi) 8bar (117psi)
0-12bar (0-174psi) 0-12 bar (0-174psi)
Clip-on Connector
1/4" BSP Male
Original Language Version
SA9302.V2, SA9304, SA9314, SA9312.V2
SA9314
1/4"BSP
8bar (117psi)
0-12bar (0-174psi)
Operating Lever
SA9314 SA9312.V2
SA9302.V2 SA9304 SA9314 SA9312.V2
SA9312.V2
1/4"BSP
8bar (117psi)
0-12bar (0-174psi)
Push-on
Connector
Issue 3 25/02/25
