Sealey MW24 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instruction protection
manual
1. SAFETY
Keep the manual for the safety warnings and precautions, assembly instructions, operating and maintenance procedures, parts list and
9
diagram. Keep the manual in a safe and dry place for future reference.
Keep work area clean. Cluttered areas invite injuries. Observe work area conditions.
9
DO NOT use machines in damp or wet locations. DO NOT expose to rain. Keep work area well lit.
8
Keep children away. Children must never be allowed in the work area. DO NOT let them handle machines or tools.
9
Store idle equipment. When not in use, tools must be stored in a dry location to inhibit rust. Always lock up tools and keep out of reach of
9
children.
DO NOT force tool. It will do the job better and more safely at the rate for which it was intended. DO NOT use inappropriate attachments
8
in an attempt to exceed the tool capacity.
Use the right tool for the job. DO NOT attempt to force a small tool or attachment to do the work of a larger industrial tool.
9
DO NOT modify this tool and do not use this tool for a purpose for which it was not intended.
8
Dress properly. DO NOT wear loose clothing or jewellery as they can be caught in moving parts.
9
Protective clothes and non-skid footwear are recommended when working.
9
Wear restrictive hair covering to contain long hair.
9
Use eye protection. Always wear approved impact safety goggles.
9
DO NOT overreach.
8
Maintain tools with care. Keep tools sharp and clean for better and safer performance. Follow instructions for lubricating and changing
9
accessories.
Keep must be kept clean, dry, and free from oil and grease at all times.
9
Stay alert. Watch what you are doing, use common sense. DO NOT operate any tool when you are tired.
9
Check for damaged parts. Before using any tool, any part that appears damaged should be carefully checked to determine that it will
9
operate properly and perform its intended function.
Check for alignment and binding of moving parts; any broken parts or mounting fixtures; and any other condition that may affect proper
9
operation. Any part that is damaged should be properly repaired or replaced by a qualified technician.
Replacement parts and accessories. When servicing, use only identical replacement parts. Use of any other parts will void the warranty.
9
DO NOT operate tool if under the influence of alcohol or drugs. Read warning labels if taking prescription medicine to determine if your
8
judgment or reflexes are impaired while taking drugs. If there is any doubt, do not operate the tool.
For your safety, service and maintenance should be performed regularly by a qualified technician.
9
Use heavy duty gloves when handling the workpiece.
9
WARNING! The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions and
‰
situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into
this product, but must be supplied by the operator.
2. INTRODUCTION
Curve template for transferring exact curves for precise duplication in metal, wood, leather, and fabric applications. Ideal for replicating both
simple and complex curves on various body shop materials, including auto body panels. Adjustable locking mechanisms for exact curve
reproduction, providing maximum accuracy. Constructed with durable materials, including metal to ensure maximum durability and longevity in
workshop environments. Featuring a highly flexible spring steel face, it allows for easy, quick, and precise shape transfer across a wide range of
projects.
3. SPECIFICATION
Model No: ....................................................................MW24
Reach: ...........................................................2072mm (107")
Weight: ........................................................................ 1.68kg
© Jack Sealey Limited
PROFESSIONAL CURVE BODY PANEL PROFILE
TEMPLATE, 2720MM, 107"
MODEL NO:
Wear protective
gloves
Original Language Version
MW24
MW24 Issue:2 23/09/24
