Sealey SA825 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
Familiarise yourself with the application and limitations of the hose reel, as well as the specific hazards.
9
Maintain the hose reel in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
DO NOT place inside a spray booth/oven.
8
Ensure there is adequate lighting.
9
WARNING! Ensure maximum air pressure is not exceeded (300psi).
‰
Keep extended air hose away from heat, oil and sharp edges.
9
Check hose for wear before each use and ensure all connections are secure.
9
Keep the unwound hose away from wet, damp, oily surfaces to avoid debris accumulation in between the hose reel.
9
WARNING! Always wear approved eye protection when operating the air hose reel.
‰
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip footwear.
9
Keep children and unauthorised persons away from the working area.
9
DO NOT operate the hose reel if any parts are damaged or missing as this may cause failure and/or personal injury.
8
DO NOT use the hose reel for any purpose other than that for which it is designed.
8
DO NOT pull the hose from the supply.
8
DO NOT operate the hose reel when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
DO NOT direct air from the air hose at yourself or others.
8
WARNING! Ensure the hose is disconnected from the supply when not in use or carrying out any maintenance or assembly.
‰
DO NOT position the hose in direct sunlight or in areas of extreme heat or cold.
8
2. INTRODUCTION
i
Lightweight, floor standing hose reel with built in carry handle for easy transportation. Features high grade TPR (Thermoplastic Rubber)
inner tube and a reinforced PVC outer coating, which remains flexible in low temperatures. Silicone-free for use in the bodyshop. Fitted
with quick connectors and supplied with a 1.9m inlet hose to connect the hose reel to a compressor. Drum is manufactured from impact
resistant plastic.
3. SPECIFICATION
s
Model No: ............................................................ SA825
Hose Size (ID/OD): .........................................Ø6/11mm
Hose Type: .............................. Reinforced Braided PVC
Inlet Size: .............................................Quick Connector
Length: .................................................................... 20m
Maximum Pressure: ............................................ 300psi
Nett Weight: .......................................................... 4.2kg
Outlet Size: ..........................................Quick Connector
4. ASSEMBLY
4.1. REMOVE ALL ITEMS FROM THE PACKAGING.
4.1.1. Connect quick connector to side of hose reel (fig.1).
5. OPERATION
5.1. CONNECT TO AN AIR LINE
DO NOT connect directly to an air tool, connect a leader hose to the tool
8
first and then connect the leader hose to the air hose reel.
5.2. EXTENDING THE HOSE
5.2.1. Pull the hose out slowly to the length required and stop.
5.3. RETRACTING THE HOSE
5.3.1. Rewind the hose manually.
© Jack Sealey Limited
PORTABLE MANUAL AIR HOSE REEL, 20M,
Ø6MM ID, 300PSI
SA825
MODEL NO:
Original Language Version
fig.1
SA825 Issue:2 (2) 12/03/24
