Asus TUF-AX6000 Quick Start Manual

Quick
Start Guide
TUF-AX6000
TUF Gaming AX6000 Dual
Band WiFi Router
Router Setup Steps
01
Prepare your Modem
Unplug the power of cable / DSL modem.
1
Unplug
If you are using DSL for internet, you will
need your username / password from
your Internet service provider (ISP) to
properly configure your router.
02 Install your Router
Plug the adapter into the DCIN port, and press the Power button.
1
– via App
[App] On your iOS or Android mobile device, go to the app
3
store, search for ASUS Router, and download the app.
– or via Web Browser
[Wired] Connect your PC to a LAN port at the back
3
side of the router using an additional network cable.
[Wireless] Connect to the network with default SSID shown on the product label on the back side of your
router "ASUS_XX".
E21894_TUF-AX6000_one-page_QSG_v2.indd 1 E21894_TUF-AX6000_one-page_QSG_v2.indd 1
Connect your modem to WAN port at the back side of the router with the
2
network cable provided.
Power on the modem. Plug modem to the power outlet and power on.
3
Modem back
Modem back
[App] On your iOS or Android mobile device, tap Settings > Wi-Fi, connect
4
to the default network SSID shown on the product label on the bottom
side of the router. Or scan the QR code on the product label to connect the
default network SSID.
Hardware Explanations
I/O Ports Overview
Power button 2.5G/1G LAN port 2.5G/1G WAN (Internet) port
WPS button USB 3.2 Gen 1 port
Power (DCIN) port LAN 1~4 ports Reset button
Specifications:
DC Power adapter DC Output: +12V with 2.5A current
Operating Temperature 0~40 o C
Operating Humidity 50~90%
Check the modem LED lights to ensure the connection is active.
4
The power LED will light up when the hardware is ready.
2
[App] Launch ASUS Router App and follow
5
the instructions to complete the setup.
_
* XX refers to the last two
digits of MAC address.
You can find it on the
label on the back of
your router.
[Wired / Wireless] Open a web browser.
4
You will be redirected to the ASUS Setup Wizard. If not, navigate to http://www.asusrouter.com/.
Follow the instructions to complete the setup.
http://www.asusrouter.com/
LED Lights Overview
2.5G WAN (Internet) LED 2.5G LAN LED
LAN 1~4 LEDs WiFi LED
Storage 0~70 o C
Storage 20~90%
E21894
Power LED
Modem front
