Asus TUF-BE6500 Quick Start Manual

Quick
Start Guide
TUF-BE6500
TUF Gaming BE6500 Dual Band WiFi 7 Router
One Router Setup Steps
01
Prepare your Modem
Unplug the power of cable / DSL modem. If it
1
has a battery backup, remove the battery.
Unplug
02
Install your Router
Plug the adapter into the DCIN port, and press the Power switch.
1
– Via app
[App] On your iOS or Android mobile device, go
3
to the app store, search for ASUS Router, and
download the app.
– Or via web browser
[Wired] Connect your PC to LAN port at the back side
3
of the router using an additional network cable.
FAQ
FREQUENTLY ASKED QUESTIONS
Q1: Where can I find more information about the wireless router?
Technical support site: https://www.asus.com/support
WE SUGGEST...
Connect your modem to WAN port at the back side of the router with the
2
network cable provided.
Power on the modem. Plug modem to the power outlet and power on.
3
Modem back
Modem back
[App] On your iOS or Android mobile device, tap Settings > Wi-Fi, connect
4
to the default network SSID shown on the product label on the back side
of the router. Or scan the code on the product label to connect the default
network SSID.
[Wireless] Connect to the network with default SSID shown on
the product label on the back side of your router "ASUS_XX".
Hardware Explanations
I/O Ports Overview
2.5G WAN
Power button (Internet) port
2.5G LAN 1-3 ports
DCIN port
Specifications:
DC Power adapter
Operating Temperature
Operating Humidity
The power LED will light up when the hardware is ready.
2
* XX refers to the last two digits
of MAC address. You can find
_
it on the label on the back of
your router.
[Wired / Wireless] Open a web browser.
4
You will be redirected to the ASUS Setup Wizard. If not, navigate to http://www.asusrouter.com.
Follow the instructions to complete the setup.
http://www.asusrouter.com/
Service and Support
https://www.asus.com/support
LED Lights Overview
USB 3.2 Gen 1 port
5GHz LED WAN (Internet) LED
(USB 3.0)
WPS button 2.4GHz LED
Reset button
DC Output: +12V with 2.5A current
0~40 o C Storage 0~70 o C
50~90% Storage 20~90%
Check the modem LED lights to ensure the connection is active.
4
Modem front
[App] Launch ASUS Router App and follow the
5
instructions to complete the setup.
Video Tutorials
https://qr.asus.com/wl_videotutorials
E24386
Power LED
LAN LED
If you are using DSL for internet,
you will need your username
/ password from your Internet
service provider (ISP) to properly
configure your router.
