Whirl Massage Device
Manufacturer:
MEDEN - INMED, Spółka z o.o.
UL. WENEDÓW 2
75-847 KOSZALIN
POLSKA
TEL. +48 94 347 10 40
FAX. +48 94 347 10 41
USER MANUAL
WKG
for Upper Limbs
Distribution and service in Poland
MEDEN - INMED, Spółka z o.o.
UL. WENEDÓW 2
75-847 KOSZALIN
POLSKA
TEL. +48 94 347 10 40
FAX. +48 94 347 10 41
0197
Advertisement
Table of Contents
Related Manuals for Meden-Inmed WKG
Summary of Contents for Meden-Inmed WKG
- Page 1 USER MANUAL Whirl Massage Device for Upper Limbs 0197 Manufacturer: Distribution and service in Poland MEDEN - INMED, Spółka z o.o. MEDEN - INMED, Spółka z o.o. UL. WENEDÓW 2 UL. WENEDÓW 2 75-847 KOSZALIN 75-847 KOSZALIN POLSKA POLSKA TEL. +48 94 347 10 40 TEL.
-
Page 2: Table Of Contents
7.4 Disinfection of the water system 7.5 Descaling the water system 7.6 Electrical safety testing CONDITIONS OF MAINTENANCE 8.1 Manufacturer’s liability 8.2 Troubleshooting 8.3 Contact with the manufacturer’s service ELECTROMAGNETIC COMPATIBILITY 10. WARRANTY CARD 2025-02-27 WKG - User Manual r06.doc Page 2/28... -
Page 3: Dear Customer
Installation and User’s Manual are not followed. 7. A technical description of the WKG whirl massage device for upper limbs, a list of replacement parts and instructions on their replacement are available from the manufacturer upon request. -
Page 4: Symbols
Installation and User’s Manual may result in deterioration of the conditions or threat to the safety of the user and/or the personnel operating the WKG whirl massage device for upper limbs. A similar marking has been placed on the device where the Installation and User’s Manual must be read, and its instructions... -
Page 5: Intended Use Of The Device
18 years of age. 1.4 Users WKG whirl massage device for upper limbs can be used only by qualified personnel who have read the information contained in the user manual for this device. 2025-02-27 WKG - User Manual r06.doc... -
Page 6: Technical Specifications
2.1 Technical characteristics The WKG whirlpool basin is made of high-quality fiberglass-reinforced acrylic, and the housing is made of fiberglass-reinforced gelcoat. The use of such materials provides many years of trouble-free operation of the device. -
Page 7: Technical Parameters
[sec] − emptying [sec] 2.3 CE mark The WKG whirl massage device for upper limbs is manufactured in accordance with Medical Devices Regulation 2017/745 (class IIa, rule 9) and has CE marking, according to the manufacturer declaration. 0197 2025-02-27 WKG - User Manual r06.doc... -
Page 8: Device Set
1 pc. 2.5 Transport and storage Transport and storage of the WKG upper limb whirling massage device should be carried out in the manufacturer's transport packaging at a temperature above 0°C, in a dry and covered room. Storage and transport temperature [°C] positive (max. -
Page 9: Preparation For Use
A diagram of the WKG whirl massage device installation, available from the manufacturer, contains detailed instructions on how to install the device. The whirl massage device should be placed in a room of dimensions that ensure its proper operation. After the whirl massage device has been installed, a passage of a minimum width of 80 cm should be available on each side of the device. - Page 10 (e.g. on the wall) in the room to shut off the medium supply to the device, so that personnel can quickly access the shut-off valves in the event of installation failure or uncontrolled water leakage from the device installation. 2025-02-27 WKG - User Manual r06.doc Page 10/28...
-
Page 11: Connection To The Water Supply And Drainage Systems
Such defects will not be covered by the warranty. The WKG device is manufactured to meet the location and assembly conditions specified by the user. The assembly and the first activation of the device is carried out by the service of the contractor, or an entity authorized by the contractor. -
Page 12: Connection To The 230V ~ 50 Hz Mains Electricity
IPX5. The electrical installation to which the WKG device is connected must meet the requirements corresponding to current regulations (e. g. EN 60364-7-710). -
Page 13: Assembly Of The Device
6. After verifying the connections, fill the whirlpool massage device with water and check for any leaks. Once the device's operation has been confirmed, the installation is complete. Figure 5 – Junction box A – Cable connection point 2025-02-27 WKG - User Manual r06.doc Page 13/28... -
Page 14: Operating The Device
A description of the operation of this function is described in more detail in the maintenance in section 7 below. 2025-02-27 WKG - User Manual r06.doc Page 14/28... -
Page 15: Sequence Of Operations
Before filling the basin with water, check the position of the water discharge knob (fig. 7) - the knob should be in the “CLOSED” position. Figure 7 - Closed water discharge knob 2025-02-27 WKG - User Manual r06.doc Page 15/28... -
Page 16: Manual Filling
“LOWER” or “INCREASE” button will display the set treatment time, and repeated presses will change this value. During the ongoing “MASSAGE” mode, it is not possible to change the length of the treatment time. 2025-02-27 WKG - User Manual r06.doc Page 16/28... -
Page 17: Massage Intensity Adjustment
In order to rinse the whirlpool when washing after the treatment (section 7.2), open the “SHOWER” valve by unscrewing the knob located on the right side of the device. The temperature of the shower water is regulated by the “COLD WATER” and “HOT WATER” valves. 2025-02-27 WKG - User Manual r06.doc Page 17/28... -
Page 18: Maintenance
To rinse the basin, open the “SHOWER” valve. It is recommended to rinse the basin with water from the shower head not more than 1 minute. 2025-02-27 WKG - User Manual r06.doc Page 18/28... -
Page 19: Basin Disinfection After A Treatment
Its activation is possible only after the basin is filled with water to the appropriate level (see paragraph 6.1). Otherwise, when activating the mode, a single beep will be generated and the “LEVEL” LED will blink three times. 2025-02-27 WKG - User Manual r06.doc Page 19/28... -
Page 20: Electrical Safety Testing
60 minutes in the factory, or by briefly pressing the “ACTION” button. Use "KAMIX" for descaling (available at Meden-Inmed) and follow the instructions of its manufacturer. We recommend using 0.5%-1% concentration of the pre-made solution, which provides sufficient strength of the agent to carry out the decalcification process in our equipment (e.g. -
Page 21: Conditions Of Maintenance
2025-02-27 WKG - User Manual r06.doc Page 21/28... -
Page 22: Troubleshooting
If you purchased your device from an intermediary, please kindly provide us with your serial number and location of use. These data will be placed in our service database, which will allow us to smoothly fulfill warranty and service conditions. 2025-02-27 WKG - User Manual r06.doc Page 22/28... -
Page 23: Electromagnetic Compatibility
Essential performance and safety - there are no essential performance characteristics according to the risk assessment. WKG whirl massage device for upper limbs Guidance and manufacturer’s declaration – electromagnetic emissions The equipment is intended for use in the electromagnetic environment specified below. The customer or the user of the equipment should assure that it is used in such an environment. - Page 24 These guidelines apply communications (see below) situations. Electromagnetic propagation equipment affected by absorption and reflection from IEC 61000-4-3 structures, objects and people. Professional Professional healthcare facility healthcare facility environment environment 2025-02-27 WKG - User Manual r06.doc Page 24/28...
- Page 25 The carrier shall be modulated using a 50 % duty cycle square wave signal. As an alternative to FM modulation, 50 % pulse modulation at 18 Hz may be used because while it does not represent actual modulation, it would be worst case. 2025-02-27 WKG - User Manual r06.doc Page 25/28...
-
Page 26: Warranty Card
The warrantor shall not issue a duplicate of the Warranty Card. This warranty does not exclude, limit or suspend your consumer statutory rights. Whirl massage device for upper limbs: Serial number of device: Seal, date and signature of the Warrantor: 2025-02-27 WKG - User Manual r06.doc Page 26/28... - Page 27 User’s Comments Repairs Register Electrical safety testing Date and signature of the inspector Protocol no: Inspection result: The next inspection not later than in 12 months 2025-02-27 WKG - User Manual r06.doc Page 27/28...
- Page 28 2025-02-27 WKG - User Manual r06.doc Page 28/28...
