INSTALLATION AND OPERATION MANUAL
Underwater massage device
Manufacturer:
MEDEN - INMED, Spółka z o. o.
ul. WENEDÓW 2
75-847 KOSZALIN
POLSKA
TEL. +48 94 347 10 40
FAX. +48 94 347 10 41
AQUAMOBIL
Distribution and service in Poland:
MEDEN – INMED, Spółka z o. o.
ul. WENEDÓW 2
75-847 KOSZALIN
POLSKA
TEL. +48 94 347 10 40
FAX. +48 94 347 10 41
0197
Advertisement
Table of Contents
Related Manuals for Meden-Inmed AQUAMOBIL
Summary of Contents for Meden-Inmed AQUAMOBIL
- Page 1 INSTALLATION AND OPERATION MANUAL AQUAMOBIL Underwater massage device 0197 Distribution and service in Poland: Manufacturer: MEDEN – INMED, Spółka z o. o. MEDEN - INMED, Spółka z o. o. ul. WENEDÓW 2 ul. WENEDÓW 2 75-847 KOSZALIN 75-847 KOSZALIN POLSKA POLSKA TEL.
-
Page 2: Table Of Contents
9.2 R ..................... 18 ESPONSIBILITY OF THE MANUFACTURER 9.3 T ..........................18 ROUBLESHOOTING 9.4 C ......................18 ONTACT WITH SERVICE SUPPORT 10. ELECTROMAGNETIC COMPATIBILITY ..................... 19 11. WARRANTY ..........................22 2022-10-18 AQUAMOBIL - User Manual r06w2.doc5 Page 2 from 24... -
Page 3: Introduction
Failure to comply with this requirement will void the guarantee on the product. 6. Any serious portable underwater massage device AQUAMOBIL incident shall immediately be reported to the manufacturer and to the competent authority of the Member State where the user or patient is resident. -
Page 4: Intended Use
INTENDED USE The AQUAMOBIL underwater massage device is meant for bathtubs that are not equipped with installation dedicated for such treatment. In order to choose the right type of water stream during the treatment, it is required to select a nozzle with the appropriate diameter and set the pressure of the water jet by using the shut-off and pressure control valve. -
Page 5: Patient Target Group
The target group of patients receiving underwater massage therapy is between 18 and 80 years of age. Users The AQUAMOBIL underwater massage device can be used only by qualified personnel familiarized with the information contained in the user manual supplied with the device. CE mark... -
Page 6: Technical Characteristics
The AQUAMOBIL device is also equipped with a pressure gauge, thermometer (information on the water temperature is displayed on the control panel during the treatment), disinfection system and transportation handles (fig. -
Page 7: Technical Parameters
230 V~ 50 Hz Power consumption [A] Protection class Housing class IPX5 Dry-running protection of the pump Figure 1 – AQUAMOBIL underwater massage device view with dimensions [mm] Completion Standard equipment The AQUAMOBIL underwater massage device 1 pc. Interchangeable nozzles with diameter: Fi 4 –... -
Page 8: Transport And Storage
The manufacturer reserves the right to introduce such changes to the design of the device, that do not impair its functionality or safety of operation. Drawings provided in this manual are informative only. Figure 2 - AQUAMOBIL underwater massage device view with operating and adjustment elements 1 – control stand 6 – control panel 2 –... -
Page 9: Safety Means
Connecting to the 230 V~50 Hz mains electricity WARNING! Connection of the electrical system of the AQUAMOBIL device to the 230V/50Hz supply network should be performed by a licensed electrician. Confirmation of the proper electrical connection of the device by a licensed electrician is one of the warranty conditions. -
Page 10: First Start-Up
The manufacturer's product has been completely drained of water. After refilling the product with water, the user assumes responsibility if the water freezes. In the AQUAMOBIL device, the pump has been flooded with antifreeze (to -25°C) for the time of transport. The fluid is glycerol-based, environmentally friendly, non-freezing and certified by PZH. -
Page 11: Protection Against Dry-Running Of The Pump
Performing the above procedure prepares the device for safe storage or transport. Protection against dry-running of the pump The AQUAMOBIL device is equipped with a system protecting the pump against damage resulting from the dry-running. The system is activated within 5 seconds from the moment the pump is started. -
Page 12: Control Of The Device
It is forbidden to direct the water jet outside the basin (bathtub). WARNING! Pay attention to the way you hold the water whip to prevent it from slipping/falling out of your hands. 2022-10-18 AQUAMOBIL - User Manual r06w2.doc5 Page 12 from 24... - Page 13 WARNING! Do not place objects, e.g. towels or clothes on the bathtub, which could fall into the water and clog the suction hose with filter (fig.2, pos.3) of the AQUAMOBIL device. WARNING! Organs and areas of the body such as the female breasts, abdomen, external genitalia, protruding parts of bones and areas with varicose veins, bone growths or other disease conditions should be excluded from the procedure.
-
Page 14: Maintenance
The filter on the suction hose (fig. 2 pos.3) must be checked and cleaned each time after treatment. Failure to do so may result in clogging of the filter and improper activity of the AQUAMOBIL and damage to the pump. -
Page 15: Disinfection System
(bathtub) and fill it to 250 l of water for the specified disinfectant. To activate this mode, it is necessary to start AQUAMOBIL in advance (using the "START" button), and to place the suction hose with the filter (fig.2 pos.3) and the delivery hose (fig.2 pos.4) in a bathtub with clean water. -
Page 16: Conditions Of Maintenance
Periodic electrical safety test should be carried out by qualified service personnel. Check regularly correct functioning of the residual current device (RCD) in the device's power supply circuit and perform periodic electrical safety test of the AQUAMOBIL device as specified in the schedule of activities in section 8.1 above. - Page 17 100μA The electrode should be made of stainless steel (in aqueous environments other materials may form an electrochemical cell, which distorts the results of measurements). 2022-10-18 AQUAMOBIL - User Manual r06w2.doc5 Page 17 from 24...
-
Page 18: Responsibility Of The Manufacturer
If the device has been purchased with an intermediary, please kindly provide information about the serial number and location of the device. These data will be stored in our service database, which enables us to apply terms of guarantee and service efficiently. 2022-10-18 AQUAMOBIL - User Manual r06w2.doc5 Page 18 from 24... -
Page 19: 10. Electromagnetic Compatibility
Class A IEC 61000-3-2 domestic and those directly connected to the public low-voltage power supply network that supplies buildings used for domestic purposes. Voltage fluctuations/ flicker emissions Complies IEC 61000-3-3 2022-10-18 AQUAMOBIL - User Manual r06w2.doc5 Page 19 from 24... - Page 20 Table 9 (see below) situations. Electromagnetic propagation equipment is affected by absorption and reflection from IEC 61000-4-3 structures, objects and people. Professional Professional healthcare facility healthcare facility environment environment 2022-10-18 AQUAMOBIL - User Manual r06w2.doc5 Page 20 from 24...
- Page 21 The carrier shall be modulated using a 50 % duty cycle square wave signal. As an alternative to FM modulation, 50 % pulse modulation at 18 Hz may be used because while it does not represent actual modulation, it would be worst case. 2022-10-18 AQUAMOBIL - User Manual r06w2.doc5 Page 21 from 24...
-
Page 22: 11. Warranty
16. This warranty does not exclude, limit or suspend your consumer statutory rights. The underwater massage device’s serial number: Date, signature and seal of the manufacturer or its representative: The underwater massage device installed by: Date, signature and seal of the installer: 2022-10-18 AQUAMOBIL - User Manual r06w2.doc5 Page 22 from 24... - Page 23 Repair registry User’s notes Date and signature of a person Electrical safety check performing the check Report No. Result of the check: Next check to be performed within 12 months 2022-10-18 AQUAMOBIL - User Manual r06w2.doc5 Page 23 from 24...
- Page 24 2022-10-18 AQUAMOBIL - User Manual r06w2.doc5 Page 24 from 24...
