INSTALLATION AND OPERATION MANUAL
for automatic zone hydromassage
ORIONMED Balneo
Manufacturer:
MEDEN - INMED, Spółka z o.o.
UL. WENEDÓW 2
75-847 KOSZALIN
POLSKA
TEL. +48 94 347 10 40
FAX. +48 94 347 10 41
Therapeutic bathtub
ORIONMED
Distribution and service in Poland:
MEDEN - INMED, Spółka z o.o.
UL. WENEDÓW 2
75-847 KOSZALIN
POLSKA
TEL. +48 94 347 10 40
FAX. +48 94 347 10 41
0197
Advertisement
Table of Contents
Related Manuals for Meden-Inmed ORIONMED
Summary of Contents for Meden-Inmed ORIONMED
- Page 1 INSTALLATION AND OPERATION MANUAL Therapeutic bathtub for automatic zone hydromassage ORIONMED ORIONMED Balneo 0197 Manufacturer: Distribution and service in Poland: MEDEN - INMED, Spółka z o.o. MEDEN - INMED, Spółka z o.o. UL. WENEDÓW 2 UL. WENEDÓW 2 75-847 KOSZALIN...
-
Page 2: Table Of Contents
6.5. Bath duration settings screen .................... 16 6.6. Intensity of pearl bath settings scren ................. 16 6.7. Additional pearl bath settings screen (only for ORIONMED bathtub) ......... 17 6.8. Default program selection screen (only for ORIONMED bathtub) ........17 6.9. Temperature settings screen (only for ORIONMED bathtub) ..........18 6.10. - Page 3 9.1. Filling the basin with water ....................30 9.2. Bath with hydromassage ....................31 9.3. Pearl bath – applies to ORIONMED, ORIONMED Balneo (option) bathtub ......32 9.4. Brine bath – applies only to ORIONMED Balneo bathtub ........... 32 9.5. Carbonic acid bath – option only for ORIONMED Balneo bathtub ........33 9.6.
- Page 4 7. Technical description of the tub with a list of wear parts and the instructions on their replacement (including the non-detachable power cord) is available at manufacturer on request. 8. Any serious incident with an ORIONMED, ORIONMED Balneo bathtub must be reported immediately to the manufacturer and to the competent authority of the Member State.
-
Page 5: Device Purpose
1. DEVICE PURPOSE The ORIONMED bathtub is a therapeutic bathtub of advanced construction, specially designed for the automatic zone hydromassage treatments. The main functions of the ORIONMED bathtub allows full-body hydromassage from any chosen zone. Treatment possibilities ORIONMED ORIONMED Balneo 1. -
Page 6: Additional Performance Options
The ORIONMED Balneo bathtub offers additionally brine baths and carbonic acid baths. The ORIONMED Balneo bathtub is equipped with an additional quick filling system at the bottom of the basin. The bathtub is made of materials resistant to the influence of aggressive chemical factors, which allows for... -
Page 7: 2 . S T O R A G E A N D T R A N S P O R
The advantages of a pearl bath result from the interaction of water and air streams on the human body. Pearl bath in the ORIONMED tub is conducted by 126 nozzles with intensity regulation and the possibility of choice of intensity regulation course. -
Page 8: Technical Characteristics
- filling up to minimal bath level* < 4 < 2 - draining < 4 < 4 * depends on the pressure of the water in the connections, recommended flow ~70l/min Page 8/44 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6... -
Page 9: Completion
Illustrations included in the following manual are only indicative, and the variants of manufactured product follow the order specification. 4.1. ORIONMED bathtub Figure 1 - View of the ORIONMED bathtub basin with control and regulation elements Bath filler Whip switch (option) Cold water filling valve... -
Page 10: Orionmed Balneo Bathtub
4.2. ORIONMED Balneo bathtub Figure 2 – View of the ORIONMED Balneo bathtub basin with control and regulation elements Cold water filling valve Filling plug for disinfection tank Hot water filling valve Shower valve (option) Hydromassage water jets Shower valve... -
Page 11: Ce Mark
Disinfectant tank Water discharge open Water discharge closed control valve (marked blue) - option applies to ORIONMED Balneo only Cold brine control valve (marked blue) –for ORIONMED Balneo only Hot brine control valve (marked red) – for ORIONMED Balneo only... -
Page 12: Location Of Operation
Maximum nominal pressure of the water supply „CO2” saturated water supply - option applies to ORIONMED Balneo only According to the regulations on Amending the Waste Electrical and Electronic Equipment Act it is forbidden to discard with other waste the equipment marked with a crossed out trashcan. Electrical and electronic waste should be returned to a proper collection point. -
Page 13: Use Notes
Note: After 15 minutes. inactivity, the bathtub panel goes into sleep mode, the LCD display goes blank, the LED flashes blue in 5-second increments, signaling the presence of power. Return from sleep mode is done by pressing the START / STOP button. 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6 Page 13/44... -
Page 14: User Interface Elements
No symbol means that no default programs were chosen. If the program numer P4 is displayed in red, it indicates operation in user sequence recording mode. 8. Icon for disinfectant absence. 9. Icon signalling the need of the descalation. Page 14/44 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6... -
Page 15: Main Settings Screen
Turning the hydromassage on/off (only for ORIONMED Balneo). Opening/closing the water discharge valve (only for ORIONMED Balneo). Start/finish filling the bathtub. Automatic filling lasts untill next water level is reached, indicated by 2 (for the 1st level) or 3 (for treatment level) sounds of a buzzer. In case of filling up to the highest sensor, only filling up is possible, which can be done by holding the button. -
Page 16: Bath Duration Settings Screen
Return to the Main setting screen . Move to the next settings screen. START Start/stop the bath. If the water level is not sufficient to start th bath, a buzzer will STOP signal with a short sound. Page 16/44 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6... -
Page 17: Additional Pearl Bath Settings Screen (Only For Orionmed Bathtub)
6.7. Additional pearl bath settings screen (only for ORIONMED bathtub) LED diode glows continuously in blue. Button Description Rectangular procedure of massage intensity Sawtooth procedure of massage intensity. If none of the modes is chosen, the intensity of the pearl bath is constant. -
Page 18: Temperature Settings Screen (Only For Orionmed Bathtub)
6.9. Temperature settings screen (only for ORIONMED bathtub) LED diode glows continuously in blue. Button Description Selection of the requested bath temperature within a 30-40°C range. Return to the Main settings screen. Move to the next settings screen. START Start/stop the bath. If the water level is not sufficient to start th bath, a buzzer will STOP signal with a short sound. -
Page 19: Disinfection
Settings Main Screen. The LED diode lights up continuously blue. The remaining disinfection time is shown on the display. Additional information on the disinfection process is described in section 8.5 below. 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6 Page 19/44... -
Page 20: Flushing Of Hydromassage Drains (Only For Orionmed Balneo Bathtub)
6.13. Flushing of hydromassage drains (only for ORIONMED Balneo bathtub) The purpose of flushing the hydromassage channels is to clean them of residual water which that could block the hydromassage jets. Before starting the process of flushing the hydromassage channels, the bathtub should be emptied of water. -
Page 21: Default Programs (Only For Orionmed Bathtub)
The own sequence recording mode is signalled on the main screen by the display of the P4 symbol in red. 6.16. Water whip control (option only for ORIONMED bathtub) WARNING! It is forbidden to use the water whip while the hydromaassage pump is operating. -
Page 22: Error Display
E 03 Malfunction of water level sensors Fill in the basin with water and start the bath E04, etc. Control system error Necessary to contact the service Page 22/44 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6... -
Page 23: P R E Pa R At I O N F O R U S
Figure 3b – ORIONMED Balneo bathtub dimensions (in mm) Figure 4a – ORIONMED bathtub layout of media outlets in the floor (dimensions in mm) Figure 4b - ORIONMED Balneo bathtub layout of media outlets in the floor (dimensions in mm) 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6... - Page 24 WARNING! In the room where treatments are carried out in ORIONMED bathtub, ventilation should be provided with an air exchange rate of at least 2 times per hour. WARNING! The rooms in which balneological treatments are carried out in an ORIONMED Balneo bathtub should be equipped with bottom gas overflows and in mechanical supply and exhaust ventilation with bottom exhaust to ensure increased air exchange exceeding two times per hour.
-
Page 25: Connection To 230V ~ 50Hz Mains Electricity
One of the warranty conditions is a validation of the electricity supply connection of the bathtub by an authorised electrictian. The bathtub for automatic zone hydromassage ORIONMED, ORIONMED Balneo must be permanently connected to the electrical system. The bathtub's power supply circuit should have: −... -
Page 26: Marking Of Bathtub Connection Hoses
1 red strip – hot water supply, • hose with 2 blue strips – cold brine or sulfer water supply (for ORIONMED Balneo), • hose with 2 blue strips – hot brine or sulfer water supply (for ORIONMED Balneo), •... -
Page 27: M A I N T E N A N C E A N D C O N S E R Vat I O
Functionality check of the residual current device in the technical documentation of the disconnect (RCD) switch 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6 Page 27/44... -
Page 28: Cleaning And Disinfecting The Basin After Each Patient
(for example Septer, Incidin OxyFoam, San Clear Med, accessible in Meden-Inmed company store) or another cleaner that will not damage the acrylic coating and is allowed for use in the unit. During disinfection, the manual of the disinfectant maker. It is important to point out not to use cleaners or tools that could scratch or damage the basin coating. -
Page 29: Refill Of Disinfectant
Independently it is necessary to inspect the integrity of the residual-current switch, in a manner and in time set out in the technical documentation of a specific switch. The coontrol personnel should comply with the instructions provided in the following manual. 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6 Page 29/44... -
Page 30: S E Q U E N C E O F O P E R At I O
. Filling will be stopped automatically when the desired level is reached. The water is refilled in by continuously touching the field with the above mentioned icon. For the ORIONMED Balneo bathtub, the basin is additionally filled via manual valves for cold and warm brine (fig.2 pos.5 and 6) and a CO valve (fig.2 pos. -
Page 31: Bath With Hydromassage
5. After the treatment, the patient, assisted by the personnel, leaves the bathtub. 6. To empty the ORIONMED bathtub, open the lever (fig.1 pos.15). 7. To empty the ORIONMED Balneo bathtub, press the water discharge button 8. After emptying the bathtub, perform the following hygienic measures: −... -
Page 32: Pearl Bath - Applies To Orionmed, Orionmed Balneo (Option) Bathtub
WARNING! Do not start the pearl massage during the carbonic acid bath in the ORIONMED Balneo bathtub. Selecting the pearl bath program (see section 6.4) on the Main screen and pressing the STRAT/STOP button will start the pearl massage. -
Page 33: Carbonic Acid Bath - Option Only For Orionmed Balneo Bathtub
Carbonic acid bath – option only for ORIONMED Balneo bathtub 9.5. WARNING! Methods of preparation and performing of the carbonic acid bath treatments should be defined by the organization which uses the equipment, in the form of obligatory instructions. This manual contains only the minimum necessary information relating to this subject. -
Page 34: Bath With Water Illumination (Option)
To play music, search for the "POWER DYNAMICS BT10" sound source on the external device and establish a connection. If a password is required, enter the code "1234". Page 34/44 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6... - Page 35 10. AUXILIARY EMPTYING THE BATHTUB – MANUAL only for ORIONMED Balneo WARNING! In case of lack of possibility of automatic water discharge (e.g. power failure) in the ORIONMED Balneo bathtub, the bathtub basin can be emptied manually. To manually empty the basin, open the ball valve (fig.8 pos.1) located under the bathtub in the water discharge area.
-
Page 36: Manufacturer Liability
If you buy the device with an intermediary, please kindly provide information about the serial number and location of the device. These data will be placed in our service base, which will allow us to efficiently implement the terms of the warranty and service. Page 36/44 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6... - Page 37 Recommended conditions during transport: • Temperature in the range of +0C do +60C; • Relative humidity within the range from 20% to 95% without condensation; • Atmospheric pressure within the range of 700-1060 hPa. 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6 Page 37/44...
- Page 38 * Therapeutic bathtub for automatic zone hydromassage ORIONMED, ORIONMED Balneo Instructions and declaration of manufacturer – electromagnetic emissions ORIONMED, ORIONMED Balneo bathtub is intennded for use in the below specificated electromagnetical environment. The purchaser or user of the ORIONMED, ORIONMED Balneo bathtub must provide such environment. Emissions test Compatibility...
- Page 39 Instructions and declaration of manufacturer – electromagnetic resistance ORIONMED, ORIONMED Balneo bathtub is intennded for use in the below specificated electromagnetical environment. The purchaser or user of the ORIONMED, ORIONMED Balneo bathtub must provide such environment. Electromagnetical environment — Testing level...
- Page 40 15. The warrantor shall not issue a duplicate of the Warranty Card. 16. This warranty does not exclude, limit or suspend your consumer statutory rights. Therapeutic bathtub ORIONMED, ORIONMED Balneo serial number: Date, signature and stamp of the Warranter: Bathtub installed by:...
- Page 41 Repair record User notes Electrical safety inspection Date and signature of the inspector Protocol number: Inspection result: Next inspection after no longer than 12 months 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6 Page 41/44...
- Page 42 Page 42/44 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6...
- Page 43 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6 Page 43/44...
- Page 44 Page 44/44 2024-04-26 ORIONMED-ORIONMED BALNEO - User Manual r06.doc6...
