Meden-Inmed SOLMED UNO User Manual

Irradiation lamp
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model: UNO, DUO, TRIO
Manufacturer:
„Meden-Inmed", Sp. z o.o.
ul. Wenedów 2
75-847 Koszalin
tel. +48 94 347 10 40
fax. +48 94 347 10 41
USER MANUAL
SOLMED
Irradiation lamp
Distribution and service in Poland:
„Meden-Inmed", Sp. z o.o.
ul. Wenedów 2
75-847 Koszalin
tel. +48 94 347 10 40
fax. +48 94 347 10 41
0197

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOLMED UNO and is the answer not in the manual?

Questions and answers

Related Manuals for Meden-Inmed SOLMED UNO

Summary of Contents for Meden-Inmed SOLMED UNO

  • Page 1 USER MANUAL SOLMED Irradiation lamp Model: UNO, DUO, TRIO 0197 Manufacturer: Distribution and service in Poland: „Meden-Inmed”, Sp. z o.o. „Meden-Inmed”, Sp. z o.o. ul. Wenedów 2 ul. Wenedów 2 75-847 Koszalin 75-847 Koszalin tel. +48 94 347 10 40 tel.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION ..............................3 1.1. PURPOSE OF THE UNIT ........................4 1.2. INTENDED USERS ..........................4 1.3. FUNCTIONS ............................4 1.4. INDICATIONS ............................5 1.5. CONTRAINDICATIONS ........................5 1.5.1. SIDE EFFECTS ........................... 5 1.6. CLASSIFICATION ..........................5 2.

  • Page 3: Introduction

    SOLMED irradiation lamp. All comments and observations regarding making of the unit and contents of this manual should be sent to our address: Meden-Inmed Sp. z o.o. ul. Wenedów 2 75-847 KOSZALIN tel.

  • Page 4: Purpose Of The Unit

    1.1. PURPOSE OF THE UNIT The SOLMED lamp is intended for therapy consisting in the treatment of skin tissue warming by means of thermal energy of infrared radiation emitted by the source - one, two or three light bulbs. In addition, depending on the intended effect treatment effect, you can use a red or blue color filter that changes the radiation pattern.

  • Page 5: Indications

    1.4. INDICATIONS The lamp is used for: • preparing the patient's body before massage, manual therapy, iontophoresis, kinesitherapy, electrotherapy, • chronic inflammatory conditions and pain syndromes of the spine, • pain in the course of degenerative diseases of the cervical spine, •...

  • Page 6: Technical Characteristics

    Tube tilt angle range [°] horizontal Tube height adjustment range [mm] Meden-Inmed, sp. z o.o., ul. Wenedów 2, 75-847, Koszalin Manufacturer tel. +48 94 3471040, fax. +48 94 3471041, service: 94 3471048 2.1. DIMENSIONS Figure 1 - Dimensions of SOLMED model UNO 2024-06-07 SOLMED - User Manual r05.doc...

  • Page 7: Powering

    Figure 2 - Dimensions of SOLMED model DUO Figure 3 - Dimensions of SOLMED model TRIO 2.2. POWERING The device requires powering from an alternative current mains socket with a rated voltage of 220-230V ~ 50H/60 Hz, equipped with a protective earth point of contact 2.3.

  • Page 8: Additional Equipment

    2.3.1. Additional equipment − Orange (amber) filter - not part of standard equipment and not supplied with the lamp, − Green filter - not included in standard equipment and not supplied with the lamp. 2.4. CONDITIONS OF STORAGE, WORK AND TRANSPORT WARNING! The lamp during transport should be folded and packed so as to prevent accidental damage.

  • Page 9: Safety Of Use

    3. SAFETY OF USE 3.1. Symbols WARNING! In this way, activities that may not be carried out in accordance with the contents of these Operating Instructions may result in deterioration of conditions or safety risk for the user and / or personnel operating the SOLMED irradiation lamp. A similar marking has been used on the device where it is essential to read the Operation Manual and follow its instructions when using the device.

  • Page 10: Unit Design

    Protection level provided by the enclosure IP20 Device weight (model UNO) max. 23 kg Device weight (model DUO) max. 28 kg Device weight (model TRIO) max. 30 kg Manufacturer, YYYY – year of production YYYY Pursuant provisions waste electrical electronic equipment, it is forbidden to throw away used equipment with the symbol of a crossed out basket.

  • Page 11: Control Panel

    Support stand (A) - consists of a pipe to which the arm is attached with the tube. There is a gas spring in the pipe that allows you easily change the height of the lamp. A tube is attached to the arm by means of a joint, which allows adjusting the angular position of the tube.

  • Page 12: Power Socket With Fuses And Power Switch

    Light bulb power buttons C - Bulb power setting indicator (green). 10 bulb power levels are displayed B - Buttons for changing work parameters, placed under the indicator, change the power of the bulb. START/STOP button The START / STOP button is used to activate the treatment, turn off and stop it (PAUSE).

  • Page 13: The Classification Label

    Figure 6 - Position of the power switch, socket and fuses 4.5. THE CLASSIFICATION LABEL Figure 7 - View of the classification label 5. INSTALLATION OF THE DEVICE The lamp is delivered to the User in a cardboard box in a folded condition. 2024-06-07 SOLMED - User Manual r05.doc Page 13 from 32...

  • Page 14: General Warnings And Safety Features

    6. GENERAL WARNINGS AND SAFETY FEATURES WARNING! To avoid hazards caused by the electromagnetic radiation emission, avoid using the device near life support devices. WARNING! To avoid the electric shock risk, this device must only be connected to a mains socket with a protective earth pin.

  • Page 15: Filter Installation

    WARNING! In the SOLMED lamp IR radiation is emitted through the surface of the hole in the lower part of the tube. In order to start the device, it should be connected to the power network by means of a cable previously inserted in the 220-230 V ~ 50/60 Hz power socket.

  • Page 16: Work Parameters Setting

    After start-up, place the unit in the correct position for irradiation relative to the patient's body. The first step is to set the correct height with the help of a knob placed on the bottom of the lamp stand (fig. 9 item 1).

  • Page 17: Inclusion Of The Treatment And Lamp Operating Parameters Modification During The Operation

    Model DUO Model UNO Model TRIO Figure 10 - Temperature changes on the irradiated surface at a distance of 30 cm from the tube The operation parameters are set using the buttons on the control panel. The values of the work parameters depend on the purpose of the exposure - the treatment time is set, the power and the version with two tubes, the number (1 or 2) of working bulbs.

  • Page 18: User Program Editing

    • After selecting a program, the display shows the program number and its total duration alternately. The regulation of time and power level is blocked. • After starting the treatment, the display shows the program number alternately and the total time remaining until the end of the procedure.

  • Page 19: Settings Pre-Saved In User Programs

    6.5.3. Settings pre-saved in user programs Program Stages 15 min. level 10 15 min. level 7 15 min. level 4 10 min. level 10 2 min. 3 min. 10 min. level 5 level 7 level 10 5 min. 5 min. 5 min.

  • Page 20: Maintenance And Cleaning

    7. MAINTENANCE AND CLEANING WARNING! When performing the following operations, it is absolutely necessary to disconnect the device from the mains by removing the mains plug from the mains socket. 7.1. CLEANING WARNING! Before starting the following operations, the device must be disconnected from the power supply and allow the tubes to cool down.

  • Page 21: Bulb Exchange

    7.4. BULB EXCHANGE WARNING! Before replacing the bulb, the device must be disconnected from the power supply. WARNING! The device gets very hot during operation, therefore the replacement of bulbs should be made after the heating elements are cooled. WARNING! Replacement of bulbs should be done by service personnel WARNING! lamp...

  • Page 22: Required Light Sources

    The manufacturer is not liable for using incandescent light bulbs WARNING! Use only bulbs indicated by the manufacturer of SOLMED irradiation lamps. Sources of light for SOLMED lamps are available from Meden-Inmed. • Philips production, infrared heater R-125 IR375 CH, 230V-375W.

  • Page 23: Filter Parameters

    7.6. FILTER PARAMETERS • red filter • blue filter • orange (amber) filter (it is not included in the standard equipment and not supplied with the lamp) • green filter (it is not included in the standard equipment and not supplied with the lamp) Markings in the graphs above: P - transmission, λ...

  • Page 24: Technical Conditions For Using The Unit

    8. TECHNICAL CONDITIONS FOR USING THE UNIT WARNING! Under no circumstances can you open the desktop housing on the support stand. WARNING! Any mechanical or electrical damage to the SOLMED lamp should be strictly reported to the manufacturer's service. WARNING! The manufacturer will make available on request circuit diagrams, parts lists, descriptions helpful in the repairs of those parts that are allowed by the manufacturer to repair.

  • Page 25: Manufacturer's Responsibility

    8.3. CONTACT WITH THE SERVICE Meden-Inmed Sp. z o.o. ul. Wenedów 2 75-847 Koszalin tel. (94) 344 – 90 – 48 e-mail: service@meden.com.pl...

  • Page 26: Electromagnetic Compatibility

    9. ELECTROMAGNETIC COMPATIBILITY WARNING! Use of this equipment adjacent to or stacked with other equipment should be avoided because it could result in improper operation. If such use is necessary, this equipment and the other equipment should be observed to verify that they are operating normally.
  • Page 27 Guidance and manufacturer’s declaration – electromagnetic immunity The equipment is intended for use in the electromagnetic environment specified below. The customer or the user of the equipment should assure that it is used in such an environment. Electromagnetic environment – guidance IMMUNITY test IEC 60601 Compliance level...
  • Page 28 Proximity fields from RF wireless communications equipment Test Band Maximum Immunity Distance Service Modulation frequency power test level (MHz) (MHz) (V/m) Pulse modulation 380 –390 TETRA 400 18 Hz GMRS 460, 430 – 470 ± 5 kHz deviation FRS 460 1 kHz sine Pulse modulation 704 –...

  • Page 29: Warranty Card

    10. WARRANTY CARD The seller (authorised representative, distributor) offers a 24-month warranty, starting from the date of purchase of the equipment, as indicated in a proof of purchase. The seller (authorised representative, distributor) is responsible for any faults whether in quality or quantity occurring immediately after unpacking the product from its original shipment packaging only if they have been reported in a written form within 2 working days following the delivery.

  • Page 30: Card Of Periodic Technical Tests

    11. CARD OF PERIODIC TECHNICAL TESTS WARNING! Every 12 months and each time after a failure / repair of the lamp, it is necessary to perform or commission electrical safety tests in accordance with applicable regulations. The tables of measurements are presented below.
  • Page 31 Location of measurement points for a 1-tube Location of measurement points for a 2-tube Location of measurement points for a 3-tube lamp lamp lamp Earth leakage current Measurements acc: PN-EN 60601-1 (2011) – 8.7.4.5 Requirements acc: PN-EN 60601-1 (2011) – 8.7.3 2), 3), 4) Measurement Power...
  • Page 32 2024-06-07 SOLMED - User Manual r05.doc Page 32 from 32...
