Summary of Contents for Monessen Hearth KSTDV Series
- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Monessen Hearth KSTDV500NTSC Owner's Manual Shop genuine replacement parts for Monessen Hearth KSTDV500NTSC Find Your Monessen Hearth Fireplace Parts - Select From 701 Models -------- Manual continues below part list --------...
- Page 2 Available Replacement Parts for Monessen Hearth KSTDV500NTSC SCSACM SCS AC Module (Optional Blower, Light & SRV4602-302 LAMP, HALOGEN 130V 90W SRV80D0001 Valve NG SCS...
- Page 3 KSTDV Series Direct Vent Gas Fireplace Model: KSTDV500 Installation and operating Instructions warnInG IF The InForMaTIon In TheSe InSTrucTIonS IS noT FolloweD exacTly, a FIre or exploSIon May reSulT cauSInG properTy DaMaGe, perSonal Injury or loSS oF lIFe. – Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 4: Table Of Contents
KSTDV Series Gas Fireplace Thank you and congratulations on your purchase of a Monessen Fireplace. pleaSe reaD The InSTallaTIon anD operaTIon InSTrucTIonS BeFore uSInG The applIance! IMporTanT: read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 5: Important Safety Information
IMporTanT SaFeTy InForMaTIon KSTDV Series Gas Fireplace InSTaller owner Please leave these instructions with the appliance. Please retain these instructions for future reference. • read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. -
Page 6: Code Approval
IMporTanT SaFeTy InForMaTIon & coDe approVal KSTDV Series Gas Fireplace 15. This appliance, when installed, must be electrically IMporTanT: grounded in accordance with local codes or in the pleaSe reaD The FollowInG absence of local codes, with the National Electrical... -
Page 7: Product Features
FeaTureS KSTDV Series Gas Fireplace proDucT SpecIFIcaTIonS • This appliance has been certified for use with either natural or propane gas. See appropriate data plates. • This appliance is not for use with solid fuels. • The appliance is approved for bedroom or bedsitting room installations. -
Page 8: Fireplace & Framing Dimensions
FIreplace & FraMInG DIMenSIonS KSTDV Series Gas Fireplace 25” Rough (635 mm) Opening Depth 11 ” (292 mm) 23” (584 mm) 1/2” or 5/8” Recessed Nailing Flange 50” (1270 mm) Rough Opening Width Rough Opening Height 4 ” (108 mm) 44 ” 44 ” (1137 mm) (1130 mm) 36” (914 mm) 30" 38 ” (981 mm) (762 mm) -
Page 9: Pre-Installation Information
InForMaTIon KSTDV Series Gas Fireplace BeFore you STarT FIreBox FraMInG Read this homeowner manual thoroughly and follow all Firebox framing can be built before or after the appliance instructions carefully. Inspect all contents for shipping is set in place. Construct firebox framing following Figure damage and immediately inform your dealer if any damage 2 for your specific installation requirements. -
Page 10: Fireplace Location
InForMaTIon KSTDV Series Gas Fireplace FIreplace locaTIon Plan for the installation of your appliance. This includes determining where the unit is to be installed, the vent configuration to be used, framing and finishing details, and whether any optional accessories (i.e. -
Page 11: Clearances
KSTDV Series Gas Fireplace clearanceS To coMBuSTIBleS Follow these instructions carefully to ensure safe installation. Failure to follow instructions exactly can create a fire hazard. The appliance cannot be installed on a carpet, tile or other combustible material other than wood flooring. If installed on carpet or vinyl flooring, the appliance shall be installed on a metal, wood or noncombustible material panel extending full width and depth of the appliance. -
Page 12: Secure Fireplace To Floor Or Framing
Secure FIreplace To Floor or FraMInG KSTDV Series Gas Fireplace The fireplace must be secured to the floor and/or to framing studs as shown in Figure 6 . Use four (4) wood screws or masonry/ concrete screws to secure fireplace to the floor. Use four (4) screws to attach fireplace to framing. -
Page 13: Venting Installation
KSTDV Series Gas Fireplace VenTInG InSTallaTIon read all instructions completely and thoroughly before attempting installation. Failure to do so could result in serious injury, property damage or loss of life. operation of improperly installed and maintained venting system could result in serious injury, property damage or loss of life. -
Page 14: Installation Planning
VenTInG InSTallaTIon KSTDV Series Gas Fireplace InSTallaTIon plannInG never run the vent pipe down. This may There are two basic types of direct-vent installation: cause excessive temperatures which could • Horizontal Termination cause a fire. • Vertical Termination It is important to select the proper length of vent pipe for the type of termination you choose. -
Page 15: Vertical/Horizontal Termination Locations
VenTInG InSTallaTIon KSTDV Series Gas Fireplace General VenTInG InForMaTIon - TerMInaTIon locaTIon INSIDE CORNER DETAIL G V H A D E L C B B V Fixed B V Closed V Fixed Operable Closed F V B M V B J ... -
Page 16: How To Use The Vent Graph
VenTInG InSTallaTIon KSTDV Series Gas Fireplace TerMInaTIon clearanceS For BuIlDInGS wITh coMBuSTIBle anD noncoMBuSTIBle exTerIorS G=6" (152mm) F=6" (152mm) Combustible – 6" (152 mm) Noncombustible – 2" (51mm) Inside Corner Outside Corner C = Maximum depth of 48" (1219mm) for alcove location D = Minimum width for back wall of alcove location Combustible - 38" (965mm) Noncombustible - 24" (610mm) E = Clearance from corner in alcove ... -
Page 17: Vertical/Horizontal Termination Configurations
VenTInG InSTallaTIon KSTDV Series Gas Fireplace VerTIcal/horIZonTal TerMInaTIon 36" (914 mm) conFIGuraTIonS 24” Max. Since it is very important that the venting system main- (610 mm) tain its balance between the combustion air intake and the flue gas exhaust, certain limitations as to vent con- figurations apply and must be strictly adhered to. -
Page 18: Below Grade Installation
KSTDV Series Gas Fireplace VenTInG InSTallaTIon Below GraDe InSTallaTIonS 90° When it is not possible to meet the required vent terminal clearances of 12" above grade level, a snorkel kit is recom- mended. It allows installation depth down to 7" (178 mm) below grade level. -
Page 19: Vertical Through-The-Roof Applications
KSTDV Series Gas Fireplace VenTInG InSTallaTIon noTe: Horizontal sections of this vent system require a If the foun- minimum of 3" clearances to combustibles at the top of the d a t i o n i s flue and 1" clearance at the sides and bottom until the flue... -
Page 20: Installation For Vertical Termination
VenTInG InSTallaTIon KSTDV Series Gas Fireplace InSTallaTIon For VerTIcal TerMIna- Drop a plumb line from the inside of the roof to the ceiling locating hole in the ceiling. Mark the center point where TIon the vent will penetrate the roof. Drill a small locating hole 1. - Page 21 VenTInG InSTallaTIon KSTDV Series Gas Fireplace Horizontal Overhang 2. Assemble the desired lengths of pipe and elbows nec- essary to reach from the burner system flue up through the firestop. Be sure pipe and elbow connections are fully twist-locked. 2 ft.
-
Page 22: Fireplace Installation
FIreplace InSTallaTIon KSTDV Series Gas Fireplace checK GaS Type Use proper gas type for the fireplace you are installing. If you have conflicting gas type, do not install fireplace. See dealer where you purchased the fireplace for proper fireplace according to your gas type. -
Page 23: Install Gas Supply Line
FIreplace InSTallaTIon KSTDV Series Gas Fireplace InSTall GaS Supply lIne a manual shutoff valve must be installed only persons licensed to work with gas upstream of the appliance. union tee piping may make the necessary gas and plugged 1/8" npT pressure tapping connections to this appliance. -
Page 24: Check Gas Pressure
SIGnaTure coMManD - checK GaS preSSure and elecTrIcal InSTallaTIon KSTDV Series Gas Fireplace Pressure Inlet 1. Check gas type. The gas supply must be the same as stated on the appliance’s rating decal. If the gas supply is different from the fireplace, STop! Do not install the appliance. -
Page 25: Command Center Wall Installation
SIGnaTure coMManD - checK GaS preSSure and elecTrIcal InSTallaTIon KSTDV Series Gas Fireplace AC BOX TO JUNCTION BOX IN FIREPLACE PILOT BACK LIGHT WHITE BLACK OPTIONAL WHITE BLOWER BLACK BLACK WHITE GREEN CONNECTOR REAR BURNER PIN TO CONTROL BOX SOLENOID INPUT 300 WATT MAX EACH RF RECEIVER ON/OFF BUTTON CONTROL BOX BLACK/THERMOPILE RED/THERMOPILE Figure 26 -... -
Page 26: Optional Fan/Blower Systems
SIGnaTure coMManD - opTIonal Fan Blower SySTeM KSTDV Series Gas Fireplace opTIonal Fan/Blower SySTeM (BloTKSTSc) IMporTanT: always check local building codes. This installation must comply with local regulations as well as the national electric code. wIrInG 120V AC 1. Before installing the blower, wire the receptacle into an 60Hz electrical circuit. -
Page 27: Operating Instructions - Signature Command
InSTrucTIonS - SIGnaTure coMManD KSTDV Series Gas Fireplace For your SaFeTy reaD BeFore lIGhTInG If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of lie. a. This appliance is equipped with an ignition device which automatically lights the pilot. Refer to the instructions for match lighting. -
Page 28: Operating Instructions
SIGnaTure coMManD - operaTInG InSTrucTIonS KSTDV Series Gas Fireplace operaTInG InSTrucTIonS 1. STop! Read the safety information above. 2. This appliance is equipped with an ignition device which automatically lights the burner. Do not try to light the burner by hand. -
Page 29: Signature Command System Operation Instructions
SIGnaTure coMManD SySTeM operaTIon InSTrucTIonS KSTDV Series Gas Fireplace FeaTureS To Thermopile RF Receiver ON/OFF command center To Sensor • Easy Access Function Operation and System Configura- To Sparker tion NG/LP • Operation Confirmation/Fault Diagnostic Indications (LED/ Conversion Buzzer) •... -
Page 30: System Configuration/Setup
SIGnaTure coMManD SySTeM operaTIon InSTrucTIonS KSTDV Series Gas Fireplace SySTeM conFIGuraTIon/SeTup System configuration/setup is done on the Command Center. Intermittent/Standing pilot Setup (Default intermittent) 1. Holding the ON button on the Command Center while turning on the master switch will toggle between standing pilot and intermittent pilot. -
Page 31: Functions/Operation
SIGnaTure coMManD SySTeM operaTIon InSTrucTIonS KSTDV Series Gas Fireplace FuncTIonS/operaTIon Turning on the fireplace 1. Turn on the master switch and wait for a beep. (Green LED when A/C power is present.) 2. Press the ON button on the Command Center. Pilot will light and burner will come on High setting. -
Page 32: Remote Control Operation
KSTDV Series Gas Fireplace reMoTe conTrol operaTIon reMoTe TranSMITTer operaTIonS °F General Figure 30 ▲ON ▲OFF The RFSC Remote Control has two (2) operating modes: Manual and Thermostatic. The control AUTO system can be set to a temperature range between 45° F and 90° F. The blower speed, light,... - Page 33 KSTDV Series Gas Fireplace Flame height Setting for Thermostatic Mode Figure 34 1. Hold AUTO button for five (5) seconds and one number and flame icon will appear in LCD screen. 2. Use the ON / ▲ or OFF / ▼ button to set the desired flame height to 1 (min.) 2 (medium) or 3 (max.).
- Page 34 KSTDV Series Gas Fireplace °F aux control (rear Burner Shut Down) Figure 38 1. Press AUX button once to turn rear burner off. AUX shows on the LCD. 2. Press AUX button again to turn on rear burner. AUX icon disappears.
-
Page 35: Glass Removal
GlaSS reMoVal KSTDV Series Gas Fireplace GlaSS FraMe reMoVal 1. Remove the plate located in front of the glass at the bottom. 2. Remove rod provided for screen assembly located Bulb Socket beneath the cover plate. 3. Rotate the access doors on the right and left side of the glass toward the glass. -
Page 36: Final Installation
FInal InSTallaTIon KSTDV Series Gas Fireplace Wall Brick Light Box Cover Figure 45 - Install Brick Floor Brick FP2592 Hearth Brick rocK wool placeMenT Place rock wool evenly in dime-sized pieces over front and rear burner both in front and behind rear grate. -
Page 37: Log Placement
KSTDV Series Gas Fireplace Log #1 loG placeMenT 1. From the back side of the unit (with the controls on your left) and holding log #1 in your left hand with the widest end of the log away from you, place the log over the... - Page 38 KSTDV Series Gas Fireplace 4. Holding log #4 in your left hand with the beveled end down, place the log on the key of log #1 closest to you. Make sure to locate the notch at the beveled end of the log over the third tine from the left.
- Page 39 KSTDV Series Gas Fireplace loG placeMenT 7. Hold log #6 in your left hand with the narrow cut end of the “Y” toward you and pointing up. Place the log on the key on the top of log #2 with the bottom of the log rest- ing securely on top of the second tine from the left creating a “V”...
-
Page 40: Cleaning And Maintenance
MaInTenance KSTDV Series Gas Fireplace Turn off gas before servicing fireplace. It is recommended that a qualified service Sensor technician perform these check-ups at the beginning of each heating season Thermopile Burner, pIloT anD conTrol coMparT- MenT Keep the control compartment, logs, and burner areas surrounding the logs clean by vacuuming or brushing at least twice a year. -
Page 41: Vent System
KSTDV Series Gas Fireplace cleanInG anD MaInTenance VenT SySTeM The fireplace and venting system should be inspected before initial use and at least annually by a qualified field service person. Inspect the external vent cap on a regular basis to make sure that no debris is interfering with the airflow. -
Page 42: Troubleshooting
TrouBleShooTInG KSTDV Series Gas Fireplace SIGnaTure coMManD SySTeM OPERATION ACTION FAULT DIAGNOSIS Using Battery polarity wrong? Re-install batteries battery? Make sure Command Install batteries and/or Battery voltage low? Change batteries Center and plug in the AC board No beep in about... -
Page 43: Replacement Parts
KSTDV Series Gas Fireplace FIreBox coMponenTS anD acceSSorIeS Item Description qty. KSTDV500 Bulb 73D0020 Bulb Socket 73D4521 Glass Frame Assembly 73D0159 Junction Box Assembly (not shown) 26D2128 Light Lens 73D0022 Access Doors 73D3258 Front Cover 73D4524 Screens 73D0017... -
Page 44: Signature Command System
KSTDV Series Gas Fireplace SIGnaTure coMManD SySTeM 29, 30 730024 KHLDV SG parts 12/08 73D4125... - Page 45 KSTDV Series Gas Fireplace SIGnaTure coMManD SySTeM Item Description qty. KSTDV500nTSc KSTDV500pTSc Gas Valve Assembly 80D0001 80D0002 Pilot Assembly 80D0039 80D0040 Control Box 80D0037 80D0038 AC Module SCSACM SCSACM Command Center 80D0005 80D0005 Tube, Tee to Front Burner...
-
Page 46: Logs
KSTDV Series Gas Fireplace loGS Item Description qty. KSTDV500 Log #1 73D4080 Log #2 73D4081 734126 Log #3 73D4082 DVKST log parts Log #4 73D4083 Log #5 73D4084 Log #6 73D4085 Log #7 73D4086 Log #8 73D4087 73D4125... - Page 47 KSTDV Series Gas Fireplace acceSSorIeS Standard Herringbone Item Description qty. part no. Brick, Wall Eng. Side - Cottage Clay 73D4127 Brick, Wall Air Side - Cottage Clay 73D4128 Brick, Floor - Cottage Clay 73D4129 Brick, Front, Left - Cottage Clay...
-
Page 48: Vent Components
KSTDV Series Gas Fireplace VenT coMponenTS 730024 KHLDV vent parts 73D4125... -
Page 49: Vent Components For 5" X 8"
KSTDV Series Gas Fireplace VenT coMponenTS For 5" 8" current Simpson Simpson Duravent Duravent qty./ or MhSc or MhSc Selkirk Item Box Description part no. part no. part no. Horizontal High Wind Termination Cap 58DVA-HC 1285 5DT-HC Horizontal Termination Cap w/Built-In Vinyl Siding Standoff, BHR8TK Heat Deflector, Firestop and Adjustable Pipe 7"... - Page 50 KSTDV Series Gas Fireplace 73D4125...
- Page 51 KSTDV Series Gas Fireplace 73D4125...
-
Page 52: Requirements For The Commonwealth Of Massachusetts
KSTDV Series Gas Fireplace requirements for the commonwealth of of eight (8) feet above grade directly in line with the exhaust Massachusetts vent terminal for the horizontally vented gas fueled heating This product must be installed by a licensed plumber or appliance or equipment. -
Page 53: Limited Lifetime Warranty Policy
KSTDV Series Gas Fireplace lIMITeD lIFeTIMe warranTy polIcy lIFeTIMe warranTy The following components are warranted for life to the original owner, subject to proof of purchase: Firebox, Com- bustion Chamber, Heat Exchanger, Grate and Stainless Steel Burners. FIVe year warranTy The following components are warranted five (5) years to the original owner, subject of proof of purchase: Ceramic Fiber Logs. -
Page 54: Efficiency Ratings
KSTDV Series Gas Fireplace efficiency ratings Model enerGuide ratings D.o.e. Fireplace efficiency (%) (aFue%) KSTDV500NTSC 77.30 67.40 KSTDV500PTSC 74.30 66.35 MhSc 149 Cleveland Drive • Paris, Kentucky 40361 www.mhsc.com 73D4125...
