KHLDV Series
Direct Vent Gas Fireplace
Installation and

Operating Instructions

Models: KHLDV400 & KHLDV500
warnInG
IF tHe InFOrMatIOn In tHeSe InStructIOnS IS nOt
FOLLOweD exactLy, a FIre Or expLOSIOn May
reSuLt cauSInG prOperty DaMaGe, perSOnaL
Injury Or LOSS OF LIFe.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
wHat tO DO IF yOu SMeLL GaS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
warnInG: Improper installation, adjustment, alteration,
services or maintenance can cause injury or property
damage. refer to this manual. For assistance or additional
information consult a qualified installer, service agency
or the gas supplier.
this appliance may be installed in an aftermarket*,
permanently located, manufactured home (uSa only) or
mobile home, where not prohibited by local codes.
this appliance is only for use with the type of gas
indicated on the rating plate. this appliance is not
convertible for use with other gases, unless a certified
kit is used.
* aftermarket: completion of sale, not for purpose of resale, from the
manufacturer.
730024
KHLDV cover
Due tO HIGH teMperatureS, tHe appLIance
SHOuLD Be LOcateD Out OF traFFIc anD
away FrOM FurnIture anD DraperIeS.
cHILDren anD aDuLtS SHOuLD Be aLerteD
tO t H e H a Z a r D S O F H I G H S u r Fa c e
teMperature anD SHOuLD Stay away tO
aVOID BurnS Or cLOtHInG IGnItIOn.
yOunG cHILDren SHOuLD Be SuperVISeD
wHen tHey are In tHe SaMe rOOM aS tHe
appLIance.
cLOtHInG Or OtHer FLaMMaBLe MaterIaL
SHOuLD nOt Be pLaceD On Or near tHe
appLIance.
Keep tHe rOOM area cLear anD Free FrOM
cOMBuStIBLe MaterIaLS, GaSOLIne, anD
OtHer FLaMMaBLe VapOrS anD LIquIDS.
InStaLLer: Leave this manual with the appliance.
cOnSuMer: retain this manual for future refer-
ence.
73D0024 8/09 Rev. 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KHLDV400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Monessen Hearth KHLDV400

  • Page 1: Operating Instructions

    KHLDV Series Direct Vent Gas Fireplace Installation and Operating Instructions Models: KHLDV400 & KHLDV500 warnInG IF tHe InFOrMatIOn In tHeSe InStructIOnS IS nOt FOLLOweD exactLy, a FIre Or expLOSIOn May reSuLt cauSInG prOperty DaMaGe, perSOnaL Injury Or LOSS OF LIFe.
  • Page 2: Table Of Contents

    KHLDV Series Gas Fireplace thank you and congratulations on your purchase of a pLeaSe reaD tHe InStaLLatIOn anD OperatIOn InStructIOnS BeFOre uSInG tHe appLIance! IMpOrtant: read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. Important Safety Information ...
  • Page 3: Important Safety Information

    IMpOrtant SaFety InFOrMatIOn InStaLLer Please leave these instructions with the appliance. • read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. • any change to this fireplace or its controls can be dangerous. •...
  • Page 4: Code Approval

    KHLDV Series Gas Fireplace Continued from page 3 15. This appliance, when installed, must be electrically grounded in accordance with local codes or in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1.
  • Page 5: Product Features

    prODuct FeatureS • This appliance has been certified for use with either natural or propane gas. See appropriate data plates. • This appliance is not for use with solid fuels. • The appliance is approved for bedroom or bedsitting room installations. •...
  • Page 6: Fireplace & Framing Dimensions

    KHLDV Series Gas Fireplace Figure 2 - Fireplace and Framing Dimensions ref. Framing Dimensions FIrepLace and FraMInG DIMenSIOnS Min. Rough Opening  Depth P - Min. Rough Opening Width Min. Rough Opening Height KHLDV400 KHLDV500 44ZB\zn" (1141 mm) 48ZB\zn" 35Z\x" (902 mm) 39Z\x" 32" (813 mm) 36" 22Z\x" (572 mm) 24Z\x"...
  • Page 7: Pre-Installation Information

    pre-InStaLLatIOn InFOrMatIOn BeFOre yOu Start Read this homeowner manual thoroughly and follow all instructions carefully. Inspect all contents for shipping damage and immediately inform your dealer if any damage is found. Do not install any unit with damaged, incomplete, or substitute parts. Check your packing list to verify that all listed parts have been received.
  • Page 8: Fireplace Location

    KHLDV Series Gas Fireplace FIrepLace LOcatIOn Plan for the installation of your appliance. This includes determining where the unit is to be installed, the vent configuration to be used, framing and finishing details, and whether any optional accessories (i.e. blower, wall switch, or remote control) are desired. Consult your local building code agency to ensure compliance with local codes, including permits and inspections.
  • Page 9: Mantel Clearances

    cLearanceS cLearanceS tO cOMBuStIBLeS Follow these instructions carefully to ensure safe installation. Failure to follow instructions exactly can create a fire hazard. the appliance cannot be installed on a carpet, tile or other combustible material other than wood flooring. If installed on carpet or vinyl flooring, the appliance shall be installed on a metal, wood or noncombustible material panel extending full width and depth of the appliance.
  • Page 10: Secure Fireplace

    KHLDV Series Gas Fireplace The fireplace must be secured to the floor and/or to framing studs as shown in Figure 6. Use two (2) wood screws or masonry/ concrete screws to secure fireplace to the floor. Use four (4) screws to attach fireplace to framing.
  • Page 11: Venting Installation

    VentInG InStaLLatIOn read all instructions completely and thoroughly before attempting installation. Failure to do so could result in serious injury, property damage or loss of life. Operation of improperly installed and maintained venting system could result in serious injury, property damage or loss of life.
  • Page 12: Installation Planning

    KHLDV Series Gas Fireplace InStaLLatIOn pLannInG There are two basic types of direct-vent installation: • Horizontal Termination • Vertical Termination It is important to select the proper length of vent pipe for the type of termination you choose. It is also important to note the wall thickness.
  • Page 13: Termination Locations

    VentInG InStaLLatIOn GeneraL VentInG InFOrMatIOn - terMInatIOn LOcatIOn D  E  L  B  Figure 8 - Termination Locations A = Clearance above grade, veranda, porch, deck, or balcony B = Clearance to window or door that may be opened C = Clearance to permanently closed window D = Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2’...
  • Page 14: How To Use The Vent Graph

    KHLDV Series Gas Fireplace terMInatIOn cLearanceS FOr BuILDInGS wItH cOMBuStIBLe anD nOncOMBuStIBLe exterIOrS G=6" (152mm) Combustible – 6" (152 mm) Noncombustible – 2" (51mm) Inside Corner G = Combustible 24"(610mm) Noncombustible 18"(457mm) Balcony with No Side Wall Figure 9 - Allowable Venting Chart HOw tO uSe tHe Vent GrapH The Vent Graph should be read in conjunction with the...
  • Page 15: Vertical/Horizontal Termination Configurations

    VentInG InStaLLatIOn VertIcaL/HOrIZOntaL terMInatIOn cOnFIGuratIOnS Since it is very important that the venting system maintain its balance between the combustion air intake and the flue gas exhaust, certain limitations as to vent configurations apply and must be strictly adhered to. The Vent Graph, showing the relationship between vertical and horizontal side wall venting, will help to determine the various dimensions allowable.
  • Page 16 KHLDV Series Gas Fireplace VertIcaL/HOrIZOntaL terMInatIOn cOnFIGuratIOnS (continued) • If a 90° elbow is used in the horizontal vent run (level height maintained) the horizontal vent length is reduced by 36". Refer to Page 17, Figures 11 and 12. This does not apply if the 90°...
  • Page 17: Below Grade Installation

    VentnG InStaLLatIOn BeLOw GraDe InStaLLatIOnS When it is not possible to meet the required vent terminal clearances of 12" above grade level, a snorkel kit is recommended. It allows installation depth down to 7" (178mm) below grade level. The 7" (178mm) is measured from the center of the horizontal vent pipe as it penetrates through the wall.
  • Page 18: Vertical Through-The-Roof Applications

    KHLDV Series Gas Fireplace VertIcaL (tHrOuGH-tHe-rOOF) appLIcatIOnS This gas fireplace has been approved for, • Vertical installations up to 40' (12 m) in height. Up to a 10' (3 m) horizontal vent run can be installed within the vent system using a maximum of two 90° elbows. Figure 18 nOte: Horizontal sections of this vent system require a minimum of 3"...
  • Page 19: Installation For Vertical Termination

    VentInG InStaLLatIOn InStaLLatIOn FOr VertIcaL terMInatIOn 1. Determine the route your vertical venting will take. If ceiling joist, roof rafters or other framing will obstruct the venting system, consider an offset. Refer to Figure 20 to avoid cutting load bearing members. For optimal flame appearance, a restrictor disk is necessary on straight vertical runs of 10' of more.
  • Page 20: Termination Heights For Vents Above Flat Or Sloped Roofs

    KHLDV Series Gas Fireplace 3. Cut a hole in the roof using the locating hole as a center point. (Cover any exposed open vent pipes before cutting hole in roof). The 10 "x10 length may be larger depending on the pitch of the roof. There must be a 1" minimum clearance from the vent pipe to combustible materials.
  • Page 21: Fireplace Installation

    FIrepLace InStaLLatIOn cHecK GaS type Use proper gas type for the fireplace you are installing. If you have conflicting gas type, do not install fireplace. See dealer where you purchased the fireplace for proper fireplace for your gas type or con- version kit.
  • Page 22 KHLDV Series Gas Fireplace Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. nOte: The gas line connection may be made using 1/2" rigid tubing or an approved flex connector. Since some municipalities have additional local codes it is always best to consult your local authorities and the current edition of the National Fuel Gas Code ANSI.Z223.1, NFPA54.
  • Page 23: Check Gas Pressure - Millivolt

    MILLIVOLt - cHecKInG GaS preSSure and eLectrIcaL InStaLLatIOn 1. Check gas type. The gas supply must be the same as stated on the appliance’s rating decal. If the gas supply is different from the fireplace, StOp! Do not install the appliance.
  • Page 24: Millivolt - Remote Wall Switch Installation

    KHLDV Series Gas Fireplace reMOte waLL MOunteD SwItcH A remote wall switch and up to fifteen (15) feet of 18 Ga. wire may be used with this appliance. Attach the wall switch in a junction box at the desired location on the wall.
  • Page 25: Junction Box Wiring

    MILLIVOLt - OptIOnaL Fan/BLOwer SySteM junction Box Figure 28 - Junction Box Wiring Diagram FP1912 7. Remove the access covers on the right and left side walls Junction box wiring of the firebox toward the front by unfastening the screws. nOte: the access covers are not identical.
  • Page 26 KHLDV Series Gas Fireplace Figure 31 - Blower Access Covers FP2136 blower access plates Remove Solid Access Door Replace with Louvered Access Door, Louvers Towards Bottom Figure 33 - Install New Louvers FP2234 install louvers 1/09 MILLIVOLt - OptIOnaL Fan/BLOwer SySteM FP2136 FP2137 Figure 34 -...
  • Page 27: For Your Safety Read Before Lighting

    MILLIVOLt - OperatInG InStructIOnS FOr yOur SaFety reaD BeFOre LIGHtInG a. This appliance is equipped with a pilot which must be lit with built-in piezo ignitor while following these instructions exactly. B. BEFORE OPERATING smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.
  • Page 28: Lighting Pilot

    KHLDV Series Gas Fireplace LIGHtInG pILOt FOr tHe FIrSt tIMe apprOVeD LeaK teStInG MetHOD You may check for gas leaks with the following methods only: • Soap and water solution • An approved leak testing spray • Electronic sniffer never check for gas leak with open flame! Check for gas leaks in each of the following locations: •...
  • Page 29: Lighting The Burner

    MILLIVOLt - OperatInG InStructIOnS MaIn Burner SwItcH The “ON/OFF/RS” switch for the main burner can be found behind door of the fireplace. This switch allows you to turn on and to turn off the main burner without using the gas valve knob. Make sure the button is in the “ON”...
  • Page 30: Check Gas Pressure - Signature Command

    KHLDV Series Gas Fireplace SIGnature cOMManD - cHecK GaS preSSure and eLectrIcaL InStaLLatIOn 1. Check gas type. The gas supply must be the same as stated on the appliance’s rating decal. If the gas supply is different from the fireplace, StOp! Do not install the appliance.
  • Page 31: Command Center Wall Installation

    SIGnature cOMManD OptIOnaL waLL cOMManD center and BLOwer SySteM TO JUNCTION BOX IN FIREPLACE BACK  LIGHT WHITE BLACK OPTIONAL WHITE BLOWER BLACK BLACK WHITE REAR BURNER SOLENOID Figure 41 - Signature Command Wiring Diagram Electrical connections should only be performed by a qualified, licensed electri- cian.
  • Page 32: Optional Fan/Blower Systems

    KHLDV Series Gas Fireplace OptIOnaL Fan/BLOwer SySteM (BLOtKHLSc) IMpOrtant: always check local building codes. this installation must comply with local regulations as well as the national electric code. wIrInG 1. Before installing the blower, wire the receptacle into an electrical circuit. This should be done before framing the fireplace.
  • Page 33 SIGnature cOMManD - OptIOnaL Fan BLOwer SySteM 13. Connect the two (2) wiring harness wires to the wires marked (blower) from the AC Module and snap wires into clips from Step 9. 14. Replace logs. 15. Replace the glass. 16. Replace the front plate below the glass frame. nOte: the front plate hides the wire har- ness in the front.
  • Page 34 KHLDV Series Gas Fireplace Figure 44 - Blower Access Plates FP2136 blower access plates Replace with Louvered Access Door, Louvers Towards Bottom Figure 46 - Install New Louvers SIGnature cOMManD - OptIOnaL Fan BLOwer SySteM FP2136 Figure 45 - Attach Blowers to Brackets Remove Solid Access Door FP2234...
  • Page 35: For Your Safety Read Before Lighting

    SIGnature cOMManD - OperatInG InStructIOnS FOr yOur SaFety reaD BeFOre LIGHtInG a. This appliance is equipped with an ignition device which automatically lights the pilot. Refer to the instructions for match lighting. B. BEFORE OPERATING smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.
  • Page 36: Operating Instructions

    KHLDV Series Gas Fireplace OperatInG InStructIOnS 1. StOp! Read the safety information above. 2. This appliance is equipped with an ignition device which automatically lights the burner. Do not try to light the burner by hand. 3. With five (5) minutes to clear out any gas. Then smell for gas, including near the floor. If you smell gas, StOp! Follow "B"...
  • Page 37: Signature Command System Operation Instructions

    SIGnature cOMManD SySteM OperatIOn InStructIOnS FeatureS command center • Easy Access Function Operation and System Configuration • Operation Confirmation/Fault Diagnostic Indications (LED/ Buzzer) • ON/OFF/HI/Low Operation control Board • Electronic Ignition • Pilot Lockout safety feature • Electric Power Regeneration from Thermopile to save battery •...
  • Page 38: System Configuration/Setup

    KHLDV Series Gas Fireplace SySteM cOnFIGuratIOn/Setup System configuration/setup is done on the Command Center. Intermittent/Standing pilot Setup (Default intermittent) 1. Holding the ON button on the Command Center while turning on the master switch will toggle between standing pilot and intermittent pilot. 2.
  • Page 39: Self Diagnostics Chart

    SIGnature cOMManD SySteM OperatIOn InStructIOnS cOMManD center FunctIOnS/OperatIOn turning on the fireplace 1. Turn on the master switch and wait for a beep. 2. Press the ON button on the Command Center. Pilot will light and burner will come on High setting. pilot Safety Lockout Function 1.
  • Page 40: Thermostatic Mode

    KHLDV Series Gas Fireplace reMOte tranSMItter OperatIOnS General Figure 48 The RFSC Remote Control has two (2) operating modes: Manual and Thermostatic. The control system can be set to a temperature range between 45° F and 90° F. The blower speed, light, rear burner shut down and flame height can be adjusted in either the manual and thermostatic mode.
  • Page 41: Remote Control Operation

    reMOte cOntrOL OperatIOn Flame Height Setting for thermostatic Mode Figure 52 1. Hold AUTO button for five (5) seconds and one number and flame icon will appear in LCD screen. 2. Use the ON / ▲ or OFF / ▼ button to set the desired flame height to 1 (min.) 2 (medium) or 3 (max.).
  • Page 42 KHLDV Series Gas Fireplace aux control (rear Burner Shut Down) Figure 56 1. Press AUX button once to turn rear burner off. AUX shows on the LCD. 2. Press AUX button again to turn on rear burner. AUX icon disappears. Low Battery Detection Figure 57 1.
  • Page 43: Glass Frame Removal

    GLaSS reMOVaL GLaSS FraMe reMOVaL 1. Remove the plate located in front of the glass at the bottom. 2. Remove rod provided for screen assembly located beneath the cover plate. 3. Rotate the access doors on the right and left side of the glass toward the glass. 4.
  • Page 44: Brick, Light Bulb, And Lens Placement

    KHLDV Series Gas Fireplace BrIcK, LIGHt BuLB, anD LenS pLaceMent 1. Remove the trapezoidal light shroud located at the back of the firebox by unfastening the three screws. 2. Disassemble the trapezoidal light shroud by unfastening the four screws which secure the front to the back. Set lens with the orange painted surface toward the bottom.
  • Page 45: Log Placement

    LOG pLaceMent LOG pLaceMent Burner Grate Assembly 1. Place the rear log over the grate toward the back by positioning the holes over the large pins located LG593 at the right and left. When the log is in place, the back surface of the log will come in contact with KHLDV grate the light trapezoid deflector.
  • Page 46 KHLDV Series Gas Fireplace 4. Place the middle log over the two burners by setting the flat surface over the burner and matching the indenta- tion located underneath the branch over the protrusion located at V-branch on the left front log placed in step #3. Rotate the right end of the log clockwise until it comes in contact with the reverse bend on the bracket located between the front and rear burner.
  • Page 47 LOG pLaceMent 8. Replace glass in reverse order of instructions on Page 45. 9. Slide the rings of the screen provided inside the unit above the grate over the rod. Make sure the screen handles are toward the center. 10.Hook the rod screen assemblies over the three hooks located behind the face in front of the glass.
  • Page 48: Cleaning And Maintenance

    KHLDV Series Gas Fireplace turn off gas before servicing fireplace. It is recommended that a qualified service technician perform these check-ups at the beginning of each heating season Burner, pILOt anD cOntrOL cOMpartMent Keep the control compartment, logs, and burner areas surround- ing the logs clean by vacuuming or brushing at least twice a year.
  • Page 49: Venting System

    cLeanInG anD MaIntenance Vent SySteM The fireplace and venting system should be inspected before initial use and at least annually by a qualified field service person. Inspect the external vent cap on a regular basis to make sure that no debris is interfering with the airflow.
  • Page 50: Standing Pilot Ignition

    KHLDV Series Gas Fireplace StanDInG pILOt IGnItIOn SyMptOM pOSSIBLe cauSe 1. Spark ignitor will A. Wire disconnected. not light pilot after repeated triggering of B. Defective ignitor. piezo. C. No gas or low gas pres- sure. D. No Propane/LPG in tank 2.
  • Page 51 trOuBLeSHOOtInG StanDInG pILOt IGnItIOn SyMptOM pOSSIBLe cauSe 4. Frequent pilot A. Pilot flame may be too high outage problem. or too low, causing pilot safety to drop out 5. The pilot and main A. Inner vent pipe leaking burner extinguish exhaust gases back into while in operation system...
  • Page 52: Signature Command System

    KHLDV Series Gas Fireplace SIGnature cOMManD SySteM OPERATION Install batteries and/or plug in the AC board No beep in about 8 seconds Flip the master switch (rocker switch) to the ON position No beep Press the ON button on the Command Center no sound from the valve indicating pilot solenoid open...
  • Page 53: Illustrated Parts Lists

    Right Access Panel, w/Louvers (used with blower) Left Access Panel, w/Louvers (used with blower) 11a. T-Stat Blower with Speed Control (Millivolt system) 11b. Blower Kit (Signature Command System) 73D0024 11a,b qty. KHLDV400 73D0020 730024 73D4521K KHLDV firebox parts 73D1015K 26D2128K 73D0022 73D0029K...
  • Page 54: Standing Pilot Millivolt Control

    KHLDV Series Gas Fireplace StanDInG pILOt — MILLIVOLt cOntrOL 730024 khldv mv valve parts repLaceMent partS 11,12,13,14 73D0024...
  • Page 55 Thermostatic Remote Control Wall Switch Kit Wall Thermostat Kit Forged Andiron 13" Cast Iron 12 " Fuel conversion Kits - Millivolt control natural Gas to Lp KHLDV400 Kit #KHL400CKP KHLDV500 Kit #KHL500CKP Lp to natural Gas KHLDV400 Kit #KHL400CKN KHLDV500...
  • Page 56: Signature Command System

    repLaceMent partS KHLDV Series Gas Fireplace SIGnature cOMManD SySteM 730024 KHLDV SG parts 12/08 73D0024...
  • Page 57 AC Module Solenoid (not shown) accessories Forged Andiron 13" Cast Iron 12 " Fuel conversion Kits - Signature command System natural Gas to Lp KHLDV400 Kit #KHL400CKPS KHLDV500 Kit #KHL500CKPS Lp to natural Gas KHLDV400 Kit #KHL400CKNS KHLDV500 Kit #KHL500CKNS 73D0024 qty.
  • Page 58: Venting Components

    KHLDV Series Gas Fireplace Vent cOMpOnentS 730024 KHLDV vent parts repLaceMent partS 73D0024...
  • Page 59 repLaceMent partS Vent cOMpOnentS FOr 5" qty./ Item Box Description Horizontal High Wind Termination Cap Horizontal Termination Cap w/Built-In Vinyl Siding Standoff, Heat Deflector, Firestop and Adjustable Pipe 7" to 11" Horizontal Termination Cap Built-In Vinyl Siding Standoff, Heat Deflector, Firestop, 90° Elbow and Adjustable Pipe 11" to 14" 24"...
  • Page 60: Logs

    KHLDV Series Gas Fireplace LOGS Item Description Log #1 Log #2 Log #3 Log #4 Log #5 Log #6 Log #7 qty. repLaceMent partS KHLDV400 KHLDV500 73D0532 73D0134 73D0533 73D0135 73D0534 73D0136 73D0535 73D0137 73D0536 73D0138 73D0537 73D0139 73D0538 73D0140...
  • Page 61 KHLDV Series Gas Fireplace 73D0024...
  • Page 62: Requirements For The Commonwealth Of Massachusetts

    KHLDV Series Gas Fireplace requirements for the commonwealth of Massachusetts This product must be installed by a licensed plumber or gas fitter when installed within the Commonwealth of Massachusetts. note regarding Vented products Flex line installation must not exceed 36 inches and must have a T shutoff valve.
  • Page 63: Limited Lifetime Warranty Policy

    KHLDV Series Gas Fireplace LIMIteD LIFetIMe warranty pOLIcy LIFetIMe warranty The following components are warranted for life to the original owner, subject to proof of purchase: Firebox, Combustion Chamber, Heat Exchanger, Grate and Stainless Steel Burners. FIVe year warranty The following components are warranted five (5) years to the original owner, subject of proof of purchase: Ceramic Fiber Logs.
  • Page 64: Efficiency Ratings

    efficiency ratings Model enerGuide ratings Fireplace efficiency (%) KHLDV400NV KHLDV400PV KHLDV400NSC KHLDV400PSC KHLDV500NV KHLDV500PV KHLDV500NSC KHLDV500PSC MHSc 149 Cleveland Drive • Paris, Kentucky 40361 www.mhsc.com 69.6 78.2 75.2 69.8...
