Smittybilt SB76892 Installation Instructions Manual

NOTE: Carefully read entire instructions thoroughly before attempting to install this part.
Parts Included
93-9148 Skid Plate Front Bumper
93-9152 Winch Mounting Plate
93-9160 Atlas Bumper
93-9233 Bull Bar
93-9275 Bumperette
90-9280 Bolt Plate:
90-9407 Stainless Grill:
90-9408 Stainless Grill:
90-6928 Hardware Pack:
#10-24 X 3/8" Stainless Button Head Bolt
90-6920 Hardware Pack:
#8 Plastic Clip On Nut (Purchase)
#8 X 3/4" Phillips Screw
90-6921 Hardware Pack:
7/16" X 1" Black Button Head Bolt
7/16" Hex Nut
7/16" Split Lock washer
7/16" SAE Hardened Flat Washer
INSTALLATION:
Step 1: Unbolt and remove the OE front bumper and hardware from the vehicle.
NOTE: Be sure to unclip the factory fog light wiring harnesses if equipped
Step 2: Unbolt and remove the OE driving lights from the OE bumper.
Step 3: Lift the winch mounting plate (93-9152) into place and insert the mounting studs
into the holes on the frame horn bumper mounting brackets. Secure using the supplied 7/16"
washers and nuts. Do not tighten the 7/16" bolts at this time. (Fig A)
For Technical Support/Warranty Information please call 310-762-9944
Driver
Passenger
S.S. Grill
Driving Lights
Bull Bar to Bumper
Smittybilt, 400 W. Artesia, Compton, CA 90220
Installation Instructions:
(Part # SB76892)
2007-2013 Jeep JK
Atlas Front Bumper Kit
Qty Parts Included
1
90-6922 Hardware Pack:
1
3/8"-16 X Clip On Nut
1
3/8" -16 X 1" Black Button Head Bolt
1
3/8" SAE Hardened Flat Washer
1
90-6923 Hardware Pack:
2
7/16" Hex Nut
1
7/16" Split Lock washer
1
7/16" USS Flat Washer
1
90-6924 Hardware Pack:
8
5/8" X 1" Hex Bolt Gr. 8
5/8" Hex Nut
1
5/8" USS Flat Washer
8
90-6943 Hardware Pack:
8
3/8" Nylock Nut
1
3/8" SAE Flat Washer
8
90-6944 Hardware Pack:
8
3/8" Hex Nut:
8
3/8" Split Lock washer :
8
3/8" USS Flat Washer
Revised 11.19.13
Skid Plate Bumper
Front Bumper to Frame
Winch Plate to Frame
Front Bumper to Bumperette
Front Bumper
Winch Plate to Frame
w/Vacuum Pump
Qty
1
6
6
6
1
8
8
8
1
2
2
4
1
4
4
1
1
1
2
