BOSS™ Multi V 1... & Multi V 2... EC Booster Sets
EN
Installation and operating instructions
For models:
BOSS-1 MultiV 204/EC2 - 1PH (80460442)
BOSS-1 MultiV 202/EC2 - 1PH (80460453)
BOSS-1 MultiV 404/EC2 - 1PH (80460464)
BOSS-1 MultiV 406/EC2 - 1PH (80460475)
BOSS-1 MultiV 804/EC2 - 1PH (80460486)
BOSS-1 MultiV 806/EC2 - 1PH (80460497)
BOSS-2 MultiV 204/EC2 - VFC - 1PH (80460505)
BOSS-2 MultiV 206/EC2 - VFC - 1PH (80460516)
BOSS-2 MultiV 404/EC2 - VFC - 1PH (80460527)
BOSS-2 MultiV 406/EC2 - VFC - 1PH (80460538)
BOSS-2 MultiV 804/EC2 - VFC - 1PH (80460549)
BOSS-2 MultiV 806/EC2 - VFC - 1PH (80460560)
1 & 2 Pump.indd 1
11/01/2017 08:52:11

Advertisement

loading
Need help?

Need help?

Do you have a question about the Multi V 1 EC Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Boss Multi V 1 EC Series

  • Page 1 BOSS™ Multi V 1... & Multi V 2... EC Booster Sets Installation and operating instructions For models: BOSS-1 MultiV 204/EC2 - 1PH (80460442) BOSS-1 MultiV 202/EC2 - 1PH (80460453) BOSS-1 MultiV 404/EC2 - 1PH (80460464) BOSS-1 MultiV 406/EC2 - 1PH (80460475)
  • Page 2 Fig. 2 (Control box supplied with 2 pump model only) Fig. 3 1 & 2 Pump.indd 2 11/01/2017 08:52:14...
  • Page 3 BOSS_Booster_NON-VFC_230615_[PRINT].pdf 3 23/06/2015 10:52:16 Fig. 4 Fig. 5 Fig. 6 MAX. MIN. Fig. 7 Fig. 7 Fig. 7 VFC Fig. 7 Pos. Description of the components Pump Electro controller Check valve Bladder tank * Isolation valves *Bladder tank supplied loose complete with flow through cut off valve.
  • Page 4 (serious). The mention of warning involves that The use of other spare parts may invalidate claims personal (serious) injuries may happen when invoking the liability of BOSS™ for any conse- precautions are not observed. quences. ATTENTION! Damage could be caused to the pump or installation.
  • Page 5 5.3 Scope of delivery wrapped to protect it against moisture and dust. • Booster • The equipment must be transported by means of • Installation and operating instruction of the authorised load devices booster • Transport straps must be placed around the steel 5.4 Accessories base frame • The manifolds will not withstand loads and...
  • Page 6 6.2.5 Diameter of the manifolds voltage...), the RED LED flashes and the Electronic BOSS 1 Multi V series : threaded valves 1¼” BSP Control will try to start the pump regularly. After BOSS 2 Multi V series : threaded manifolds 2” BSP many trials the Electronic Control stops and the RED LED is ON and does not flash anymore.
  • Page 7 To select a menu level, use the VALUE SETTING UP and VALUE SETTING DOWN buttons. With the ENTER button the new value selected is validated and the next menu is displayed on the screen. With the ENTER button you can exit the SETTINGS (no saving of the last change) or HISTORIC menu and go back to STANDARD display mode (or SERVICE) NOTE: the data is saved in a non-volatile memory...
  • Page 8 6.3.3 Setting menu 1 & 2 Pump.indd 8 11/01/2017 08:52:17...
  • Page 9 6.3.4 Manual mode WARNING! The electrical connection must be You can access this mode via the OPERATING performed according to the local regulations by MODE HAND/AUTO button an electrical installation engineer approved by the local authority. The pump starts at maximum frequency. When releasing it the pump slows down to a complete To make the electrical connection, the corre- stop.
  • Page 10 8. Commissioning 8.4 Start The maximum operating pressure in the instal- ATTENTION! Never let the booster run as dry lation is equal to the pressure at zero flow of over a few seconds. Dry running may damage the the pumps plus the water supply pressure at the mechanical seal.
  • Page 11 10. Faults and remedies 1 & 2 Pump.indd 11 11/01/2017 08:52:17...
  • Page 12 BOSS_Booster_NON-VFC_230615_[PRINT].pdf 11 23/06/2015 10:52:19 Fault Contoller behaviour Remedies E011 The controller starts the Check the hydraulic supply. DRY RUN pump every 30 minutes over 24 hours. If dry running If a set point pressure higher remains, it switches off the than the pressure the pump pump.
  • Page 13 BOSS_Booster_NON-VFC_230615_[PRINT].pdf 12 23/06/2015 10:52:19 (Fig.8) Wiring Diagrams (Fig.9) 1 & 2 Pump.indd 2 11/01/2017 08:52:18...
  • Page 14 BOSS_Booster_NON-VFC_230615_[PRINT].pdf 13 23/06/2015 10:52:19 Typical Single Pump Booster Schematic (Fig. 10) Typical 2/3 Pump Booster Schematic (Fig. 11) 1 & 2 Pump.indd 3 11/01/2017 08:52:18...
  • Page 15 1 & 2 Pump.indd 4 11/01/2017 08:52:18...
  • Page 16 1 & 2 Pump.indd 5 11/01/2017 08:52:18...
