Summary of Contents for Boss 104 Series
- Page 1 INSTRUCTION MANUAL BOSS SUBMERSIBLE PUMPS MODELS: BOSS 84 VOX BOSS 104 -110 Volt BOSS 104 -230 Volt BOSS 101 -400 Volt...
-
Page 3: Ce Declaration Of Conformity
Models: BOSS 84 VOX BOSS 104 -110 Volt BOSS 104 -240 Volt BOSS 104 -415 Volt CE DECLARATION OF CONFORMITY We, The BSS Group Limited Fleet House, Lee Circle, Leicester LE1 3QQ Declare under our responsibility that the products to which this... - Page 4 APPLICATIONS The BOSS 84 VOX & 104 pumps are a submersible centrifugal pump made of stainless steel with a vortex back impeller, designed and built for use with dirty water from septic tanks and dirty water in general containing solid bodies with maximum diameter 50 mm, but only for non-aggressive water.
-
Page 5: Installation
Totally immerse the pump in the water. BOSS 84 Vox and 104 INSTALLATION 1. On the version provided with a float... - Page 6 3. Connect the delivery pipe or hose directly to the pump mouth. If the pump is used in fixed installations it is advisable to connect it to the pipe with a coupling so as to facilitate disassembly and reinstallation. If a hose is used, fit a threaded hosetail on the pump mouth. Wrap the thread with suitable material to ensure an effective seal (teflon tape or similar).
- Page 7 3. When the pump is to be in a fixed installation, with a float, a check valve must always be fitted in the delivery pipe. This is also advisable on pumps with manual operation. ELECTRIC CONNECTION CAUTION! ALWAYS FOLLOW THE SAFETY REGULATIONS. 1.
-
Page 8: Maintenance And Cleaning
Ensure that the stop level does not uncover the strainer. (Fig.5) PRECAUTIONS 1. The intake strainer must always be in place during pump operation. 2. The pump should not be started more than 20 times in one hour so as not to subject the motor to excessive thermal shock. -
Page 9: Modifications And Spare Parts
MODIFICATIONS AND SPARE PARTS Any modification not authorized beforehand relieves the manufacturer of all responsibility. All the spare parts used in repairs must be original ones and the accessories must be approved by the manufacturer so as to be able to guarantee maximum safety of the machines and systems in which they may be fitted. - Page 10 All products sold are subject to our Group Sale Terms, a copy of which are available on request or are otherwise available at www.bssindustrial.co.uk. Travis Perkins Group is the owner of the registered trademark BOSS. ...
- Page 11 For spares and service, please contact AMS Aftersales on 0870 8503886...
- Page 12 The BSS Group Limited Tel: 0870 6092101 Fleet House il: amspumps@bssgroup.com Lee Circle Leicester Web: www.bssindustrial.co.uk LE1 3QQ...
