Vishay TSOP963 Series Manual

www.vishay.com
IR Receiver Modules for Remote Control Systems
1
DESIGN SUPPORT TOOLS
Model
Available
DESCRIPTION
The TSOP96... series devices are the latest generation miniaturized IR receiver modules for infrared remote control systems.
These series provide improvements in sensitivity to remote control signals in dark ambient as well as in sensitivity in the
presence of optical disturbances e.g. from CFLs.
The devices contain a PIN diode and a preamplifier assembled on a lead frame. The epoxy package contains an IR filter. The
demodulated output signal can be directly connected to a microprocessor for decoding.
The TSOP963.. and TSOP965.., series devices are designed to receive short burst codes (6 or more carrier cycles per burst).
The third digit designates the AGC level (AGC3 or AGC5) and the last two digits designate the band-pass frequency (see table
below). The higher the AGC, the better noise is suppressed, but the lower the code compatibility. AGC3 provides enhanced
noise suppression and AGC5 provides maximized noise suppression. Generally, we advise to select the highest AGC that
satisfactorily receives the desired remote code.
These components have not been qualified to automotive specifications.
PARTS TABLE
AGC
30 kHz
33 kHz
36 kHz
Carrier frequency
38 kHz
40 kHz
56 kHz
Package
Pinning
Dimensions (mm)
Mounting
Application
Best choice for
Note
• 30 kHz and 33 kHz only available on written request
Rev. 1.0, 13-Dec-2018
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
4
3
2
16797
click logo to get started
ENHANCED NOISE SUPPRESSION
(AGC3)
TSOP96330
TSOP96333
TSOP96336
TSOP96338
TSOP96340
TSOP96356
(1)
RCMM
TSOP963.., TSOP965..
Vishay Semiconductors
FEATURES
• Improved dark sensitivity
• Improved immunity against optical noise
• Very low supply current
• Photo detector and preamplifier in one package
• Internal filter for PCM frequency
• Supply voltage: 2.0 V to 3.6 V
• Insensitive to supply voltage ripple and noise
• Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
MECHANICAL DATA
1 = GND, 2 = N.C., 3 = V
ORDERING CODE
Taping:
TSOP96...TT - top view taped
TSOP96...TR - side view taped
MAXIMIZED NOISE SUPPRESSION
(1)
(2)(4)
Panhead
1 = GND, 2 = N.C., 3 = V , 4 = OUT
S
7.5 W x 5.3 H x 4.0 D
SMD
Remote control
(2) (3)
RECS-80 Code r-map
1
www.vishay.com/doc?91000
, 4 = OUT
S
(AGC5)
TSOP96530
TSOP96533
TSOP96536
TSOP96538
TSOP96540
(3)
TSOP96556
(4)
XMP-1, XMP-2
Document Number: 82848
