- Page 1 Owner’s Manual Ceiling Fan Installation Instructions For 5DRR52XXD-L Series Fans READ AND SAVE THESE INSTRUCTIONS Total fan weight with light...
-
Page 2: Installation
Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70- 1999), including fire-rated construction. - Page 3 Install 4 x 15 watt candelabra base Tighten 2 downrod set screws and Align hole in downrod with hole in bulbs included. lock nuts. yoke and install cross pin. Install downrod into yoke. Install keeper into cross pin. Remote Transmitter Dip swtiches Remote Receiver Dip switches Set dip switches on the Remote T ransmitter and Remote Raise fan with downrod assembled to...
- Page 4 Check the motor for shipping stabilizer Loosen 2 screws with key slots and and remove if present. The screws, wash- Twist lower cover plate into place by remove the 1 screw with closed slot. ers and motor pads are pre-installed to twisting in direction of arrow.
-
Page 5: Fan Speed
Reverse function for this fan is a Attach front cover to wall control switch on top housing of the fan with screws provided. Snap dip body. Turn fan off and flip switch to switch and battery cover in place. reverse the direction of the blades. Remote Control Transmitter Features: LED LIGHT MEDIUM SPEED... -
Page 6: Troubleshooting
Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet. - Page 7 9/21/04 REV.0 New made from 5AHR manual...
