Summary of Contents for Gram OM 6340-90 RT
- Page 1 Dishwasher Instruction Instruction Manual Manual Instruction Instruction Manual Manual OM 6340-90 RT...
-
Page 2: Table Of Contents
CONTENTS Technical specifications …………………………………………………….. • Conformity with the standards and Test data …………………………….. • Safety information and Recommendations………………………………….. Recycling ..………………………............• Safety information …………………………………………………………… • Recommendations …...……………………………………………………… • Items not suitable for dishwashing ………………………………………… • Installing the machine ………………………………………………………….. Positioning the machine …………………………………………………….. •... - Page 3 Loading your dishwasher .……………………………………………………. Top basket…………………………………………………………………... • Lower basket………………………………………………………………... • Alternative basket loads …………………………………………………... • Programme descriptions .…………………………………………………….. Programme items ………………………………………………………….. • Selection of Program and Starting of the Machine..……………..• ……………………. …………………………………………………… • …………………………… • • Maintenance and Cleaning ................ Filters ..………………………………………………………………………...
- Page 4 Turbo Drying Unit: This system provides better drying performance for your dishes. Ceiling Spray Arm: It provides better washing for the dishes at upper basket. Rating plate Upper basket with racks Control Panel Upper spray arm Detergent and rinse-aid dispenser Lower basket Salt dispenser Lower spray arm...
-
Page 5: Technical Specifications
Technical specifications Capacity 15 plate settings Height 820 mm- 870 mm/870mm- 920mm Width 598 mm Depth 570 mm Net Weight 53,6 kg Electricity input 220-240 V, 50 Hz Total Power 1900 W Heating Power 1800 W Pump Power 100 W Drain Pump Power 30 W Water supply pressure 0.03 MPa... -
Page 6: Safety Information And Recommendations
• Check for any damage to your machine or to its packaging. Never start a machine damaged in any way, make sure to contact GRAM service. • Unwrap the packaging materials as indicated and dispose of them in accordance with the rules. -
Page 7: In Daily Use
• Check whether the indoor electrical fuse system is connected according to the regulations. • All electrical connections must match the values indicated on the rating plate. • Pay special attention and be sure that the machine does not stand on the electricity supply cable. •... - Page 8 mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.Cleaning and user maintenance shall not be made by children without supervision.
-
Page 9: Recommendations
For your children’s safety • After removing the machine’s packaging, make sure that the packaging material is out of reach of children. • Do not allow children to play with or start the machine. • Keep your children away from detergents and rinse aids. •... -
Page 10: Items Not Suitable For Dishwashing
Items not suitable for dishwashing: • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials; • Forks, spoons and knives with wooden or bone, or ivory or nacre-coated handles; glued items,items soiled with abrasive, acidic or base chemicals. • Plastic items that are not heat-resistant, copper or tin-coated containers. -
Page 11: Water Connections
Position the machine close to a water tap or drain. You need to site your machine, taking into consideration that its connections will not be altered once they are made. Do not grip the machine by its door or panel in order to move Take care to leave a certain clearance from all sides of the machine so that you can comfortably move it back and forth during cleaning. -
Page 12: Water Inlet Hose
Water inlet hose Do not use the water inlet hose of your old machine,if any. Use the new water inlet hose supplied with your machine instead. If you are going to connect a new or long - unused water inlet hose to your machine ,run water through it for a while before making the connection. -
Page 13: Water Outlet Hose
Water outlet hose The water drain hose can be connected either directly to the water drain hole or to the sink outlet spigot. Using a special bent pipe (if available), the water can be drained directly into the sink via hooking the bent pipe over the edge of the sink. -
Page 14: Electrical Connection
Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current. If there is no earthing installation, have a competent electrician carry out an earthing installation. In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur. -
Page 18: Prior To Using The Machine
Prior to using the machine for the first time Check whether the electricity and supply water specifications match the values indicated by the • installation instructions for the machine. Remove all packaging materials inside the machine. • Set the water softener. •... -
Page 19: Testing Strip
Testing strip The washing effectiveness of your machine depends on the softness of the tap water. For this reason, your machine is equipped with a system that reduces the hardness in mains water supply. The washing effectiveness will increase when the system is correctly set. To find out the water hardness level of water in your area, contact your local water board or determine water hardness level by using the test strip(if available). -
Page 20: Detergent Usage
Detergent usage Use a detergent specifically designed for use in domestic dishwashers. You can find powder,gel,and tablet detergents in the market that have been designed for household dishwashers. Detergent should be put into the compartment prior to starting the machine. Keep your detergents in cool, dry places out of reach of your children. - Page 21 They produce good results for certain types of usage only. If you are using this type of • detergents, you need to contact the manufacturers and find out about the suitable conditions of use. When the conditions of use of such products and the machine settings are appropriate, •...
-
Page 22: Loading Your Dishwasher
LOADING YOUR DISHWASHER If you properly place your dishes into the machine, you will be using it in the best way in terms of energy consumption, washing and drying performance. There are two separate baskets for you to load your dishes into your machine. You can load into the lower basket such round and deep items as pots with long handles, pot lids, plates, salad plates, cutlery sets. -
Page 23: Lower Basket
Top basket height adjustment while it is full Basket height adjustment mechanism on the top basket of your machine is designed to let you adjust the height of your top basket upwards or downwards, without removing it from your machine when it is full, and create large spaces at the top or bottom area of your machine as needed. - Page 24 Upper Cutlery Basket The upper cutlery basket is designed for you to place forks, spoons and knives, long dippers and small items. Because it can easily be taken out of the machine, it allows your dishes to be taken out of the machine along with the basket after washing.
- Page 25 Multi-functional Rack System Multi-functional rack system is located in the bottom basket of your machine. You can easily wash spare glasses or dishes like long ladles, bread knife with the help of this accesory. Please fold the racks by putting them from position to position, in order to put the racks in the multi-functional rack system into the...
-
Page 26: Alternative Basket Loads
Alternative basket loads Lower Basket Top basket... - Page 27 Faulty loads Important Note for Test Laboratories For detailed information on performance tests, please contact following address: "dishwasher@standardtest.info” . In your email, please provide the model name and serial number (20 digits) which you can find on the appliance door.
-
Page 28: Programme Descriptions
PROGRAM DESCRIPTIONS Duration Programme Description (min) Jet wash 14’ To rinse dishes that you plan to wash later. Fast programme intended for recently used dishes which are lightly soiled. Quick 30’ Suitable for 4 place settings. Eco (Reference) Standard programme for normally soiled, daily-used dishes. For both lightly soiled delicate glassware and heavily soiled crockery at Dual Pro Wash the same time. -
Page 29: The Control Panel
THE CONTROL PANEL need to switch to 0 hour by using the delay when the machine is paused. 4. Washing Cycle Progress Indicators The display will show the symbols corresponding to the status of the programme in operation. While the Drying symbol is on, the machine will remain silent with respect to the programme you have selected for 15 to 100 minutes. - Page 30 11. Half Load Indicator NOTE: If you switch the machine to off Select the Half Load function to choose position after selecting the delay time and which area of the dishwasher contains the programme has started, the delayed dishes to be washed. You can select both time is cancelled.
- Page 31 Changing a programme If you would like to change the programme When the End light turns on, when the machine is already running. switch your machine off by pressing the On/Off button. Press the Start/ Pause button. Switching the Machine Off After the programme stops, select Switch your machine off with On/Off button your desired programme via the...
-
Page 32: Maintenance And Cleaning
MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, select a programme that runs at high temperature, and start the machine. -
Page 33: Spray Arms
Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left. - Page 35 If one of program monitor lights is on and start/Pause light is on and off, Your machine’s door is open, shut the door. If the programme won’t start Check if the plug is connected. • Check your indoor fuses. • Be sure that the water inlet tap is turned on.
-
Page 36: Practical And Useful Information
If the dishes won't dry up A programme without a dry operation selected. • Rinse aid dosage set too low • Dishes unloaded too fast. • If there are rust stains on the dishes Stainless-steel quality of the dishes washed is insufficient. •... - Page 37 THE PRODUCT FICHE (Spect) GRAM Supplier's trade mark OM 6340-90 RT Supplier's model A ++ Capacity of dishwasher The energy ef iciency class Annual energy consumption in kWh per year (AE ) ( 280 Cycle ) * 0,50 0, 5...
- Page 38 Gram A/S Gram A/S Gram A/S Tel.: 22 07 26 30 Tel.: 040 38 08 40 Tel.: 020 7756 350 www.gram.no www.gram.se www.gram.fi Gram A/S . Gejlhavegård 2B . DK-6000 Kolding . +45 73 20 10 00 . www.gram.dk 52248820 R35...
