"L" Series Top Connection Bladder Series
Pressurized Expansion Tanks (ASME)
READ CAREFULLY THE PRODUCT INSTALLATION, OPERATING AND MAINTENANCE MANUAL. FAILURE TO
FOLLOW THE INSTRUCTIONS AND WARNINGS IN THE MANUAL MAY RESULT IN SERIOUS OR FATAL INJURY
AND/OR PROPERTY DAMAGE, AND WILL VOID THE PRODUCT WARRANTY. THIS PRODUCT MUST BE INSTALLED BY A QUALIFIED
PROFESSIONAL. FOLLOW ALL APPLICABLE LOCAL AND STATE CODES AND REGULATIONS, IN THE ABSENCE OF SUCH CODES,
FOLLOW THE CURRENT EDITIONS OF THE NATIONAL PLUMBING CODE AND NATIONAL ELECTRIC CODE, AS APPLICABLE.
EXPLOSION OR RUPTURE HAZARD. THE EXPANSION TANK MUST BE OPERATED SO THAT THE PRESSURE DOES NOT EXCEED THE
MAXIMUM WORKING PRESSURE.
EXPLOSION OR RUPTURE HAZARD A relief valve must be installed to prevent pressure in excess of local code
requirement or maximum working pressure designated in the Product Manual, whichever is less. Do not expose
Product to freezing temperatures or temperatures in excess of 240° F. Do not adjust the pre-charge or re-pressure this Product except
for any adjustments required at the time of initial installation, especially if Product corroded, damaged or with diminished integrity.
Adjustments to pre-charge must be done at ambient temperature only. Failure to properly size the Product or follow these instructions
may result in excessive strain on the system lead to Product failure, serious or fatal personal injury, leakage and/or property damage.
CALIFORNIA PROPOSITION 65 WARNING: This product contains a chemical known by the State of California to
cause cancer and to cause birth defects or other reproductive harm. (California Installer/Contractor - California
law requires that this notice be given to consumer/end user of this product.) For more information: www.amtrol.com/prop65/htm.
THIS IS A SAFETY ALERT SYMBOL. IT IS USED TO ALERT YOU TO POTENTIAL PERSONAL INJURY AND OTHER HAZARDS.
OBEY ALL SAFETY MESSAGES THAT FOLLOW THIS SYMBOL TO REDUCE THE RISK OF POSSIBLE INJURY AS WELL AS
PROPERTY DAMAGE.
Part #: 9017-094 (04/11)
INSTALLATION, OPERATION & SERVICE INSTRUCTIONS
EXTROL
L-SERIES
®
T: 401.884.6300
F: 401.885.2567
For Models:
200-L
300-L
400-L
500-L
600-L
800-L
1000-L
1200-L
1400-L
1600-L
www.amtrol.com
2000-L
2500-L
3000-L
3500-L
4000-L
5000-L
7500-L
10,000-L
15,000-L
