Aeotec AEOEZW189 Quick Start Manual

Aeotec
Aeotec Range Extender 7
SKU: AEOEZW189
Quickstart
This is a secure Range Extender for Europe. To run this device please connect it to your mains power supply.
1. Open up your Z-Wave gateway/controller/app.
2. Select SmartStart inclusion.
3. Scan the QR code located on the Range Extender 7.
4. Within 10 minutes after powering your Range Extender 7, it will automatically get included into your Z-Wave gateway/controller/hub.
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer,
distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this
equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and
every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is
not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-
Wave device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this
device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level
of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.
Product Description
The Aeotec Range Extender 7, is a device for amplifying the Z-Wave signal in Z-Wave networks. It allows remote devices to be connected to the central unit
without the need for adjustments. The GEN7 technology provides a much wider range than the previous Range Extender 6. SmartStart scans the QR code of the
nr device and adds it to your controller.
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do
this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended
to use the primary controller of the previous network to make sure the very device is excluded properly from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.
Press and hold the Z-Wave Button for 20 seconds to completely factory reset your Range Extender 7.
@1 second, LED will turn off.
@2 seconds, LED will breath its LED
@5 seconds, LED will flash its LED
@10 seconds, LED will speed up its flashing.
@20 seconds, LED will become solid for 2 seconds, then start breathing its LED slowly to indicate it was factory reset.
You may now release the button.
If successful, the LED should enter a slow breathing state to indicate it is ready to be paired to a new gateway/controller/hub.
