Delta Electronics Single Mode SFP Transceiver LCP-1250B4QDRx Specification Sheet page 8

SFP timing parameters for SFP management
Parameter
TX_DISABLE Assert time
TX_DISABLE Negate time
Time to initialize, including
reset of TX_FAULT
TX Fault Assert Time
TX_DISABLE to reset
LOS Assert Time
LOS Deassert Time
Serial ID Clock Rate
Notes:
Time from rising edge of TX_DISABLE to when the optical output falls below 10% of nominal
1)
Time from falling edge of TX_DISABLE to when the modulated optical output rises above 90% of
2)
nominal
From power on or negation of TX_Fault using TX Disable
3)
Time from fault to TX fault on.
4)
Time TX Disable must be held high to reset TX_Fault
5)
6) Time from LOS state to Rx LOS assert
7) Time from non-LOS state to Rx LOS deassert
DELTA ELECTRONICS, INC.
Symbol Min.
t_off
t_on
t_init
t_fault
t_rest 10
t_loss_on
t_loss_off
f_serial_clock
8
Max. Unit
μsec
10
1 msec
300 msec
μsec
100
μsec
μsec
100
μsec
100
100 kHz
www.deltaww.com
Note
1
2
3
4
5
6
7
2008/1/23
Rev. 6G
