- Page 1 ASSEMBLY INSTRUCTIONS Solar carport SP40/5-1 | SP40/5-1A | SP40/5-1W | SP40/5-1AW SPG5 | SPG5-A | SPG5-W | SPG5-AW SPG | SPG-A | SPG-W | SPG-AW Please read this manual before using the product and follow the instructions it contains!
-
Page 2: Parts List
PARTS LIST A Support post 1 B Support post 2 x 1* x 1* C Support post 3 D Support post 4 x 1* x 1* E Side member F Pedestal x 1* x 2* G M16 x 130 Hexagon head screw H Cross member x 16 x 8*... - Page 3 K Side rail with rain gutter (short / long) L Rain gutter connection x 3* x 3* M Solar module N Outer clamp x 12 x 16 x 12* x 8* O Centre clamp P Earthing terminal x 16 x 24* x 4* Q Rain gutter R Square profile...
- Page 4 U C-rail V M10 x 130 Hexagon head screw x 2* x 2* x 4** x 4** W Cover for side member (E) X Switch cabinet x 2* Y LED light Z Motion detector AA Ground spike For the installation instructions for the add-on panels, see page 10.
- Page 5 MOUNTING BASE FIELD A-D 2 x E 2 x F 4 x G 16 x T 4 x Place the aluminium profiles for the side frame on the Attach the feet (F) to the free ends of the support posts ground.
- Page 6 Assembly aid 90° 90° 90° 90° 3460 mm Fit the outer cross members (H) to the side member (E) Set up the two side frames parallel to each other so that the using the cross member clamps (I). Place them directly two assembled the two assembled cross beams (H) rest on over the vertical support posts (A, B) to ensure direct force the other longitudinal beam (E).
- Page 7 2-3 1 x L 4 x J 32 x K 4 x Insert the long side of the cross clamps (J) into the cross members (H). Guide the long side member (K) through the mounted cross connectors. Slide the longitudinal beam with rain gutter (K) from below into the upper area of the carport. The side rails with gutter (K) should protrude 560 mm Connect the side rail with gutter (K) to the connecting at the deep end of the carport.
- Page 8 M 3 x N 4 x O 4 x Ensure that the solar panels can be connected in series. Do not connect the +/- plugs until the solar panels are firmly mounted. Slide the first solar panel (M) from bottom to top onto the side rails with rain gutter (K).
- Page 9 Attach the solar panel to the outer longitudinal beams with rain gutters (K) using the outer clamps (N). Fasten the solar panel with the centre clamps (O), see steps 4-5. Install the centre terminals (O) as shown in the illustration. Repeat this process 2 times.
- Page 10 M 9 x N 12 x O 12 x Q 9 x Align the upper side rails with rain gutter (K) parallel again. After each row, insert three rain gutters (Q) at right angles to the side rails by carefully lifting the solar panels and sliding the rain gutters (Q) underneath. Tighten the clamps (N+O). R 1-2 x S 2-4 x T 2-4 x...
- Page 11 Position the C-rails (U) in the centre, mark and drill. Fasten the C-rails (U) to the cross member from both sides and the reinforcement strut (T) from the front using the screws (V). Fold out the reinforcing struts (T) to the centre of the Attach reinforcing struts (T) to the upright using square upright, mark and drill.
- Page 12 For the motorhome version, reinforcement struts are also atta- ched to the rear stand. See steps 6-1 to 6-4. MOUNTING ADD-ON PANEL A-D 1 x E 1 x T 2 x F 2 x G 8 x Place the aluminium profiles for the side frame on the Attach the feet (F) to the free ends of the support posts ground.
- Page 13 1 1 x H 2 x Assembly aid 3460 mm Mount the outer cross beams (H) to the longitudinal beam Position the side frame parallel to the base section so that (E) using the cross beam clamps (I). Position them 150 the two assembled cross members (H) rest on the other mm offset to the vertical support posts (A, B) so that they side member (E).
- Page 14 die Verstärkungsstreben werden bei jedem zweiten Anbaufeld benötigt. INSTALLATION OF SWITCH CABINET, LED LIGHT AND GROUND SPIKE V 1 x U 1 x W 1 x X 1 x 10-1 10-2 Position the switch cabinet (U) on one of the outer The switch cabinet (U) should be positioned as close as supports (A or B).
- Page 15 10-3 10-4 Find a suitable position on one of the crossbars of the Plug in the cables of the solar modules and the power carport to install the light and motion detector. cable of the light once installation is complete. Plug the Before installation, check whether the 6 m cable is long cables of the solar modules into 1 and the cable of the enough to pull it from the control cabinet to the desired...
- Page 16 C Rain gutter – upper part D Rain gutter clamp E Side panels left / right F Water collection pot G Downpipe bend 65° H Spacer ring I Downpipe spacer I and J are supplied in a length of 3000 mm. Please saw these to the dimensions specified above.
- Page 17 RAIN GUTTER INSTALLATION A 4 x B 1 x D 4 x C 1 x Insert the four rain gutter clamps (D) first and then the rain Tighten the hexagon socket screw to secure the rain gutter brackets (A) into the side members with rain gutter. gutter bracket.
- Page 18 G 2 x H 1 x E 2 x F 1 x J 1 x K 1 x Place the side sections on the left and right of the Position the water collection tray (F) so that the round assembled rain gutter and glue them together with a outlet is aligned with the support post.
-
Page 19: Service & Contact
Insert the sliding block into the guide of the support post Open the pipe clamp, then insert the downpipe (J) into and connect the pipe clamp (K) with the hexagon socket the lower downpipe bend (G) and the pipe clamp (K), then screw supplied.
