- Page 1 ASSEMBLY INSTRUCTIONS Solar carport SP40/5-1 | SP40/5-1A | SP40/5-1W | SP40/5-1AW SPG5 | SPG5-A | SPG5-W | SPG5-AW SPG | SPG-A | SPG-W | SPG-AW Please read this manual before using the product and follow the instructions it contains!
-
Page 2: Parts List
PARTS LIST A Support post 1 B Support post 2 x 1* x 1* C Support post 3 D Support post 4 x 1* x 1* E Longitudinal beam F Base x 1* x 2* G M16 x 130 hexagon head screw H Cross beam x 16 x 8*... - Page 3 K Longitudinal beam with rain gutter (short / long) L Rain gutter connection x 3* x 3* M Solar module N Outer clamp x 12 x 16 x 12* x 8* O Center clamp P Ground clamp x 16 x 24* x 4* Q Rain gutter R Square profile...
- Page 4 U Electrical cabinet V LED light W Motion detector X Ground spike For the installation instructions for the extensions, see page 10. Before setting up the carport, it must be ensured that the location has a level and stable ground condition. After installation, the carport must be fixed to the ground.
- Page 5 ASSEMBLY BASE FIELD A - D 2 x E 2 x F 4 x G 16 x T 4 x 1 - 1 1 - 2 Place the aluminum profiles for the side frame on the ground. Attach Attach the bases (F) to the free ends of the support posts (A, B, C, D). the support posts (A, B, C, D) to the longitudinal beam (E).
- Page 6 2 - 3 x = 745 mm H 6 x 2 1 x I 24 x Install the remaining cross beams (H) at even intervals of 745 mm (x) between the first two cross beams. Proceed as described in step 2-1. 2 - 3 1 x L 4 x J 32 x...
- Page 7 3 - 2 3 - 3 The longitudinal beams with gutter (K) should protrude 22.05“ at the Connect the longitudinal beam with rain gutter (K) to the connecting deep end of the carport. Align the first outer longitudinal beam with piece (L).
- Page 8 4 - 2 4 - 3 Slide the first solar module (M) from bottom to top onto the longitudinal beams with rain gutter (K). Align the inner longitudinal beam according to the width of the solar module and tighten the cross clamps (J) firmly. 4 - 4 Attach the solar panel to the outer longitudinal beams with rain gutters (K) using the outer clamps (N).
- Page 9 M 9 x N 12 x O 12 x Q 9 x 5 - 1 5 - 2 Align the upper longitudinal beams with rain gutter (K) parallel again. After each row, insert three rain gutters (Q) at right angles to the longitudinal beams by carefully lifting the solar panels and sliding the rain gutters (Q) underneath.
- Page 10 ASSEMBLY EXTENSION A - D 1 x E 1 x G 8 x F 2 x T 2 x 7 - 1 7 - 2 Place the aluminum profiles for the side frame on the ground. Attach the Attach the bases (F) to the free ends of the support posts (A, B, C, D). support posts (A, B, C, D) to the longitudinal beam (E).
- Page 11 8 - 3 x = 29.33" 8 1 x H 6 x I 24 x Fit the remaining cross beams (H) in the center of the cross beams of the base panel. Proceed as described in steps 2-3. All other steps can be derived from the installation steps for the base field. See page 6, from step 3. 8 1 x H 6 x 9 - 1...
- Page 12 ASSEMBLY OF ELECTRIC CABINET, LED LIGHT AND GROUND SPIKE U 1 x V 1 x W 1 x X 1 x 10 - 1 10 - 2 Position the electric cabinet (U) on one of the outer posts (A or B). Attach the bases (F) to the free ends of the support posts (A, B, C, D).
- Page 13 PARTS LIST - RAIN GUTTER A Rain gutter brackets B Rain gutter - lower part C Rain gutter - upper part D Rain gutter clamp E Side panels left / right F Water collection container G Downpipe bend 65° G Spacer ring I Downpipe intermediate piece J Downpipe K Pipe clamp...
-
