Steel Gazebo
Assembl
We are forever grateful and appreciative of you considering
purchasing our product. After careful evaluation of our product
serie, we are excited to launch this product to the public as it is
more technically advanced with lots of exciting and useful
features. One of the great features added to the arsenal is its
mere size, which will require 3-4 people with about 4-5 hours of
installing time. Making it a beast at its finest!
y Instruction
MA-OB-HTG006
Advertisement
Related Manuals for Dancover MA-OB-HTG006
Summary of Contents for Dancover MA-OB-HTG006
- Page 1 Steel Gazebo Assembl y Instruction MA-OB-HTG006 We are forever grateful and appreciative of you considering purchasing our product. After careful evaluation of our product serie, we are excited to launch this product to the public as it is more technically advanced with lots of exciting and useful features.
- Page 2 Steel Gazebo Assembly Instructio...
- Page 3 M6*47 M6*25 M6*25 M6*30 M6*15 M6*10 M6*42 M6*50 5*12...
- Page 4 STEP 1 STEP 2 STEP 2: Attach Crossbeams 1 (Part B) and Crossbeams 4 (Part C1) to Pillars (Part A) . Attach Support Brackets ( Part F and F1) to Crossbeam and Pillar. Attach Crossbeams 2 Part B1) and Crossbeams 3 (Part C) to Pillars (Part A). Attach Support Brackets (Parts F and F1) to Cross Beam and Pillar...
- Page 5 STEP 3:Connect the Ionger Crossbeams B and B1 using Crossbeam Connector (Part P) STEP 3 Note: After sliding the Crossbeam Connector (Part P) into a crossbeam you should start one bolt to hold the Crossbeam Connector in place. STEP 4 STEP 4: Stand both sides Upright and Connect Crossbeams B and crossbeams B1 using the Crossbeam Connectors (Part P)
- Page 6 STEP 5-1 STEP 5-1: Attach the Corner Protectors (Part J1) and the Rib Supports (Part J2) Just twist the top two screws of (Part J2) STEP 5-2 STEP 5-2: Slide 7 Netting Hooks (Part Q) into Long Crossbeams (Parts B and B1).
- Page 7 STEP 6: Assemble the Roof Frame by Attaching the Roof Ribs Long (Part E) to the STEP 6 Roof Top Brace (Part K1). STEP 7...
- Page 8 STEP 8 STEP 9...
- Page 9 STEP 10 STEP 10: Attach the Clips (Part R1) and Clips (Part R) as shown in the diagram. R/R1 Tap lightly with the screwdriver STEP 11 STEP 11：Install the Roof Plates (Part N6 N7 N8) on the Long Sides of the Gazebo. Install the Roof Plates (Part O5 O6) on the Short Sides of the Gazebo.
- Page 10 STEP 12 STEP 12：Tighten the screw (part U) halfwy,then install(Part G G5 G6 G7), and finally tighten the (Part U) G5/G6 G7/G STEP 13 STEP 13: Attach the Roof Supports (Part H H1 H2) to the roof frame using Connectors 1 (Part M3) and Connectors 2 (Part M4) as Don't tighten all the screws, just shown in the diagram...
- Page 11 STEP 14 STEP 14:Part N1 N2 N3 N4 N5 for the Long Sides of the Gazebo, Part O1 O2 O3 O4 for the short Sides of the Gazebo. Install the Roof Plates on the Long Sides of the Gazebo. Start by sliding Roof Plate 1 (Part N2 N3 N4) into position.
- Page 12 STEP 16 Note: First fix 4 (Part M2) with V, but do not screw too tight, then install (Part G G1 G2 G3 and G4 )as shown in the diagram. You'd better from left to right. Attach the Center Rib Braces (PartM1) as shown in the diagram.
- Page 13 STEP 18 STEP 18: Install the Mosquito Netting as Shown in the iagram.
