Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfi ll your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the reason they
are greatly appreciated throughout the world.
To get the most out of your new machine, we recommend that you read the
operating instructions before using the machine. The operating instructions also
include information on how you can help protect the environment.
Operating Instructions
Washing Machine
ASKO W6884W
WARNING: Read the instructions before using the machine.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W6884W and is the answer not in the manual?

Questions and answers

Related Manuals for Asko W6884W

Summary of Contents for Asko W6884W

  • Page 1 Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfi ll your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.

  • Page 2: Table Of Contents

    Contents Before using your machine High water level for the fi rst time Economy and effi ciency Transport protection Detergents Packing material Dyeing fabrics Washer door Washing Language selection Sort your laundry. Checking water hardness Turn on the main power switch Safety instructions Open the washer door and load the washing...
  • Page 3 Contents Troubleshooting The washer door will not open Opening the door in an emergency The machine will not start After power failure Wet washing still in the machine Error messages Close the Door Over fl ow fault Water outlet fault Water inlet fault Wash motor fault Unbalance...

  • Page 4: Before Using Your Machine For The Fi Rst Time

    Before using your machine for the fi rst time Transport protection Remove any transport protection devices before NOTE! installing the machine. See the "Transport protection" chapter. Each machine is tested before leaving the factory. A small amount of water may remain Packing material in the drain pump, though this does not aff...

  • Page 5: Safety Instructions

    Safety instructions General they do not play with the machine. • Read the operating instructions and • In the enclosed plastic bag you will fi nd keep them in a safe place. a tool for opening the washer door in •...

  • Page 6: Child Safety

    Child safety Keep an eye on children! • Always close the washer door and start the programme immediately after you have added detergent. • Do not allow small children to use or play with the washing machine. • Store detergent and fabric softener out of the reach of children.

  • Page 7: Description Of The Washing Machine

    Description of the washing machine 1. Main power switch 2. Dispenser 3. Programme panel 4. Serial number plate (on inside of washer door) 5. Drainage pump cover 6. Drainage pump (behind cover) 7. Washer door...

  • Page 8: Dispenser

    Dispenser 1. Pre-wash 2. Main wash with liquid detergent. Use the separator (A). 3. Main wash with powder detergent. Do not use the separator. 4. Fabric softener 5. Release button 6. Child safety catch...

  • Page 9: Advice And Tips Before Washing

    Advice and tips before washing Here are some tips that may help you before washing. Sorting your laundry Sort items according to: • how soiled they are • colour • material Clothing 1. Do up zips and close Velcro straps so that they don’t harm fabrics.

  • Page 10: Wool

    Advice and tips before washing Wool shirts or exercise clothes, for example. This These fabrics are labelled either machine wash will save both water and energy. or hand wash. The Wool/hand wash programme • If you select a fast spin speed, this reduces is at least as gentle as washing by hand.

  • Page 11: Washing

    Washing Sort your laundry. Wash ball or net See the "Advice and tips before washing" If you use a wash ball or net, place it directly in chapter. the drum and select a programme without pre- Place underwired bras in a laundry net. wash.

  • Page 12: Select The Programme

    Washing Select the programme 4. Standard cotton 60 °C 40 °C You select a programme by turning Program for normally to heavily soiled the programme selector. The selected laundry, whites and colors. You can select programme is shown in the display. Now use the temperature freely, so follow the washing the option buttons to select any options.
  • Page 13 Washing 8. Synthetics Programme for delicate garments made of synthetic fi bre, mixed fi bre, rayon and easy care cotton. The maximum temperature is 60°C, but follow the washing instructions for each garment. Many synthetics will come clean at 40°C. Garments worn next to the skin ought to be washed at 60°C.
  • Page 14 Washing Programme chart Program 1. Auto 2. Time program 1800 2:45 3. Heavy 1800 2:40 1800 8/4* 1,10/0,83* 2:50/2:20* 4. Standard cotton 60 °C 40 °C 1800 8/4* 0,67/0,48* 2:40/2:10* 5. Everyday wash 1800 1:40 6. Quick 1800 0,45 0:45 7.

  • Page 15: Select Options

    Washing Select options • No D, No drain means that the programme You can select options to adjust the does not include a spin cycle and ends wash programme to suit your own with the water from the fi nal rinse still in the specifi...
  • Page 16 Washing NOTE! Anti crease Anti crease means that the drum will rotate for Make sure the detergent compartment is three seconds per minute for two hours once completely dry before you add detergent, the wash programme has fi nished. This feature otherwise there is a risk that the detergent will prevents the garments from lying in the same clump before the machine starts.

  • Page 17: Close The Washer Door And Press The Start Button

    Washing Close the washer door and Once the program has fi nished press the Start button The text "Done" is shown on the display for 2 minutes. The machine then turns off . Once the program is fi nished, the washer door will automatically unlock.

  • Page 18: Settings

    Settings You can change the following Temperature settings: 1. Turn the programme selector to choose • Child-safe between: °C and °F. • Language 2. Press the Stop button once to save the • Temperature setting. • Extra rinses Extra rinses How to choose the settings: Upon delivery, your washing machine is set to 1.

  • Page 19: Care And Cleaning

    Care and cleaning Cleaning the trap and the drainage Cleaning the detergent compartment pump Pull out the detergent compartment using the The washing machine has a trap where smaller release button. objects such as coins and hairpins can collect. To clean the trap and the drainage pump, do as follows: 1.

  • Page 20: Cleaning The Inside Of The Machine To Avoid Unpleasant Smells

    Care and cleaning Cleaning the inside of the machine to 3. Lift the agitator. avoid unpleasant smells 4. Remove any objects. Modern detergents often allow clothes to be 5. Place the agitator in the mounting hole with washed at low temperatures. This means that the F-mark towards you.

  • Page 21: Troubleshooting

    Troubleshooting The washer door will not open D Push the tool downwards to open the • Check that the main power switch is on. washing machine door. • Has the power supply been cut off ? Check the house fuses (circuit breakers). Opening the door in an emergency WARNING! The door may only be opened manually if...

  • Page 22: Error Messages

    Troubleshooting Error messages Water inlet fault If an error occurs during the program a message Check: is shown on the display. To exit the message • that the tap on the water pipe is open. after taking measures, turn the machine off and •...

  • Page 23: Technical Information

    Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1061/2010 Asko Model designation: W6884W Max. washing capacity: 8 kg Energy effi ciency class: A+++ Annual energy consumption (AE 190 kWh per year Energy consumption Standard cotton 60 °C with full load (E...

  • Page 24: Information For Test Institute

    Technical information Information for test institute Program Max. load Temp. °C Auto (Quick) 2) 3) Standard cotton 60 °C 40 °C Easy care 1) Short programme for test institutes, max. 1/2 load. 2) Test programme for cold water connection in accordance with EN 60456. For large volumes of detergent we recommend removing the insert and adding detergent directly to the detergent compartment.

  • Page 25: Transport Protection

    Transport protection Remove the three transport bolts and the plastic plugs for locking the machine for transport before using the machine. NOTE! If the machine is to be transported, the bolts and plastic plugs for locking the machine during transport must be installed to prevent damage to the machine through shaking.

  • Page 26: Installation

    Installation Positioning the washing machine Connection to water supply The washing machine can be installed as Water connection should be carried out by an a built-in or freestanding unit. Position the appropriately qualifi ed person. Connect the machine so that the electrical plug is easily machine using the accompanying supply hose.

  • Page 27: Drainage Connection

    Installation Drainage connection Electrical installation The machine is supplied with a drainage hose Connect the machine by plugging it into an attached, which must be connected to a drain. earthed wall socket. The electrical wall socket See the examples below. The height must be must be placed outside of the installation area 600-900 mm above fl...

  • Page 28: Service

    Service Before contacting the service division Model designation Before you contact the service division, make sure that you know the model designation, type designation and serial number. The model designation can be found on the panel. The type designation and serial number Type plate can be found on the type plate on the inside of the washer door.

  • Page 29: Your Notes

    Your notes...
  • Page 30 Your notes...
  • Page 31 Your notes...

  • Page 32: Quick Guide

    The selected programme is shown in the display. CLOSE THE WASHER DOOR AND PRESS THE START BUTTON The time remaining is shown in hours and minutes. We reserve the right to make changes. Gorenje, Partizanska 12, 3320 Velenje, Slovenija www.asko.com WM70.2 W6884W en (11-16)
