Check for updates at bontrager.com.
Parts list
- Computer
- Battery cover
- 31.8mm handlebar shim
- Out front mount
- CR2032 battery
- Speed sensor
- Mounting shim
- Speed magnet (wheel)
- Zip ties
Tools needed for assembly: 2.5mm Hex wrench, pliers, scissors.
Safety
When riding your bicycle, do not stare at the computer for a long time. If you do not watch the road, you could hit an obstacle, which might cause you to lose control and fall.
Battery Installation
Mount computer
NOTE: Remove rubber cover over the mounting clamp bolt.
31.8mm handlebar mounting
Use 2.5mm hex wrench.
0.8 N-m (7 in-lb) recommended torque.
NOTE: The mount can be reversed to position computer over the stem. Mount not to be used with phones.
For 35mm handlebar mounting remove the shim.
Mount speed sensor
NOTE: Sensor uses A23 12V battery.
NOTE: Zip ties should be trimmed in the illustration after installation.
Understanding the instructions
| Button location | Quick press | Multi press | Long press (2 seconds) |
| Front |  |  |  |
| Rear |  |  |
The letters indicate the order in which to push the buttons.
More than one arrow means you should push the button until you see the value you want.
Press and hold until next digit flashes to switch to next digit or field.
Selection note
Setup mode
Rear Button
Press rear button to enter set up anytime. Confirms selection and advances to next step. A 5 second long press exits set up at any time.
AC (all clear) button
AC button will reset to factory default setting.
Ride mode
Wake the computer: push any button or spin the wheel. The computer turns on as soon as you start your ride.
Additional
Clear ride data:
Clear service reminder
When the wrench icon reminder is visible, service is recommended. The service reminder wrench icon will appear every 300 miles for road bikes and every 200 miles for city and mountain bikes indicating service and inspection of your equipment is highly suggested. For a complete list of your bike's recommended service at specific levels, please visit www.trekbikes.com/service.
Low battery
The Bontrager RIDEtime Computer is covered by a warranty. For details, visit www.bontrager.com
- INGESTION HAZARD: This product contains a button cell or coin battery.
- DEATH or serious injury can occur if ingested.
- A swallowed button cell or coin battery can cause Internal Chemical Burns in as little as 2 hours.
- KEEP new and used batteries OUT OF REACH OF CHILDREN.
- Seek immediate medical attention if a battery is suspected to be swallowed or inserted inside any part of the body. Remove and immediately recycle or dispose of used batteries according to local regulations and keep away from children. Do NOT dispose of batteries in household trash or incinerate.
- Even used batteries may cause severe injury or death.
- Call a local poison control center for treatment information.
- Non-rechargeable batteries are not to be recharged.
- Do not force discharge, recharge, disassemble, heat above (manufacturer's specified temperature rating) or incinerate. Doing so may result in injury due to venting, leakage or explosion resulting in chemical burns.
- Ensure batteries are installed correctly according to polarity (+ and -).
- Do not mix old and new batteries, different brands or types of batteries, such as alkaline, carbon-zinc, or rechargeable batteries.
- Remove and immediately recycle or dispose of batteries from equipment not used for an extended period of time according to local regulations.
- Always completely secure the battery compartment. If the battery compartment does not close securely, stop using the product, remove the batteries, and keep them away from children.
![]()
contains coin battery
