XV23-ZX0-AAJ1
NVIDIA MGX™ Server - AMD EPYC™ 9005/9004 - 2U DP NVIDIA OVX™ 4 x PCIe Gen5 GPUs
User Manual
Rev. 3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XV23-ZX0-AAJ1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gigabyte XV23-ZX0-AAJ1

Summary of Contents for Gigabyte XV23-ZX0-AAJ1

  • Page 1 XV23-ZX0-AAJ1 NVIDIA MGX™ Server - AMD EPYC™ 9005/9004 - 2U DP NVIDIA OVX™ 4 x PCIe Gen5 GPUs User Manual Rev. 3.0...
  • Page 2 For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller portal: http://reseller.b2b.gigabyte.com For further technical assistance, please contact your GIGABYTE representative or visit https://esupport.gigabyte.com/ to create a new support ticket For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email: server.grp@gigabyte.com...
  • Page 3 Conventions The following conventions are used in this user's guide: NOTE! Gives bits and pieces of additional information related to the current topic. CAUTION! Gives precautionary measures to avoid possible hardware or software problems. WARNING! Alerts you to any damage that might result from doing or not doing specific actions.

  • Page 4: Server Warnings And Cautions

    Server Warnings and Cautions Before installing a server, be sure that you understand the following warnings and cautions. WARNING! To reduce the risk of electric shock or damage to the equipment: • Do not disable the power cord grounding plug. The grounding plug is an important safety feature. •...

  • Page 5: Electrostatic Discharge (Esd)

    Electrostatic Discharge (ESD) CAUTION! ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE, PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT- TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER WHEN HANDLING PARTS.
  • Page 6 CAUTION! Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. CAUTION “Warning Stability hazard” “The slide-rail may tip over causing serious personal injury”...

  • Page 7: Table Of Contents

    Table of Contents Chapter 1 Hardware Installation ...................10 Installation Precautions .................. 10 Product Specifications ..................11 System Block Diagram ................... 15 Chapter 2 System Appearance ..................16 Front View ...................... 16 Rear View ....................... 17 Front Panel LEDs and Buttons ............... 18 Power Supply Unit (PSU) LED ...............
  • Page 8 Chapter 5 BIOS Setup ....................43 The Main Menu ....................45 Advanced Menu ..................... 47 5-2-1 Demo Board ......................48 5-2-2 Boot Configuration ....................49 5-2-3 Peripheral Configuration ..................50 5-2-4 SATA Configuration....................51 5-2-5 Memory Configuration ....................52 5-2-6 USB Configuration ....................53 5-2-7 CPU Related Configuration ..................54 5-2-8 CPU Configuration ....................55 5-2-9...
  • Page 9 Appendix I 141 NVLink Bridge Removal ................141 - 9 -...

  • Page 10: Chapter 1 Hardware Installation

    Chapter 1 Hardware Installation Installation Precautions The motherboard/system contain numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the service guide and follow these procedures: • Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or warranty sticker provided by your dealer.

  • Page 11: Product Specifications

    Product Specifications NOTE: We reserve the right to make any changes to the product specifications and product-related information without prior notice. Dimensions Š 438mm (W) x 87mm (H) x 900mm (D) (WxHxD, mm) Š Motherboard MZX3-MG0 Š AMD EPYC™ 9005 Series Processors Š...
  • Page 12 Storage Front hot-swap: 6 x 2.5" Gen5 NVMe/SATA/SAS-4 Š - (4 x NVMe from CPU_0, 2 x NVMe from CPU_1) Internal M.2: 2 x M.2 (2280/22110), PCIe Gen3 x2, from CPU_1 Š Internal M.2: 1 x M.2 (2280/22110), PCIe Gen3 x1, from CPU_0 Š...
  • Page 13 - Max 2000W/ 220-240V~ or 240Vdc Input +12.2V/ 164A +12.2Vsb/ 3A System ASPEED AST2600 Baseboard Management Controller Š ® Management GIGABYTE Management Console web interface Š Dashboard Š HTML5 KVM Š Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Š Sensor Reading History Data Š...
  • Page 14 Operating Operating temperature: 10°C to 35°C Š Operating humidity: 8-80% (non-condensing) Properties Š Non-operating temperature: -40°C to 60°C Š Non-operating humidity: 20%-95% (non-condensing) Š Hardware Installation - 14 -...

  • Page 15: System Block Diagram

    System Block Diagram PCIe5.0 x8 (NVMe x2) PCIe5.0 x16 (NVMe x4) 6-bay 2.5" Gen5 NVMe 12-Channel DDR5 RDIMM 12-Channel DDR5 RDIMM CPU0 CPU1 12 x DIMM slots 12 x DIMM slots xGMI3 32GT/s 3x16 xGMI AMD EPYC™ 9005 AMD EPYC™ 9005 AMD EPYC™...

  • Page 16: Chapter 2 System Appearance

    Chapter 2 System Appearance Front View PSU3 PSU4 PSU1 PSU2 Description Front Panel LEDs and Buttons USB 3.2 Gen1 Port x 2 NOTE! Drives with green latches support NVMe. • Please Go to Chapter 2-3 Front Panel LED and Buttons for detail description of function LEDs. System Appearance - 16 -...

  • Page 17: Rear View

    Rear View SLOT 11 (DPU) SLOT 9 SLOT 7 PSU4 (GPU) (GPU) SLOT 8 (NIC) PSU3 SLOT 3 SLOT 1 SLOT 5 (NIC) PSU2 (GPU) (GPU) PSU1 Description PCIe Card Slot ID LED Data LAN Port x2 Mini DP Management LAN Port USB 3.2 Gen1 Port x2 System Appearance - 17 -...

  • Page 18: Front Panel Leds And Buttons

    Front Panel LEDs and Buttons No. Name Color Status Description Reset Button Press the button to reset the system. Green System is powered on Power button with LED System is not powered on or in ACPI S5 state (power off) Press the button to activate system identification ID Button (Note)

  • Page 19: Power Supply Unit (Psu) Led

    Power Supply Unit (PSU) LED NOTE! The power supply may be vary based on the system configuration. PSU LED State Description No AC power to all power supplies 1Hz Green Blinking AC present / only standby on / Cold redundant mode 2Hz Green Blinking Power supply firmware updating mode AC cord unplugged or AC power lost;...

  • Page 20: Hard Disk Drive Leds

    Hard Disk Drive LEDs HDD Present RAID SKU LED #1 Locate Rebuilding HDD Access Fault (No Access) Green ON(*1) BLINK (*2) Disk LED (LED on Back Panel) Amber No RAID configuration Removed HDD Green ON(*1) (via PCH, HBA) Slot (LED on Amber Back Panel) Green...

  • Page 21: Chapter 3 System Hardware Installation

    Chapter 3 System Hardware Installation Pre-installation Instructions Computer components and electronic circuit boards can be damaged by electrostatic discharge. Working on computers that are still connected to a power supply can be extremely dangerous. Follow the simple guidelines below to avoid damage to your computer or injury to yourself. •...

  • Page 22: Removing Chassis Cover

    Removing Chassis Cover Before you remove or install the system cover • Make sure the system is not turned on or connected to AC power. Follow these instructions to remove the chassis cover: Remove the screw securing the chassis cover. Push button to unlock the handle.

  • Page 23: Installing The Pcie / Gpu Card

    Installing the PCIe / GPU Card • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered-down and all power sources have been disconnected from the server prior to installing a PCI card.
  • Page 24 Follow these instructions for the PCI Expansion / GPU card: Remove the riser bracket from the system. Loosen and remove the screw securing the slot covers on the riser bracket then detach the slot covers. Unscrew the screws securing the PCIe Card/GPU in the Slot. Alignthe PCIe card/GPU with the riser guide slot, and gently push it in the direction of the arrow until it securely connects to the PCIe card connector.

  • Page 25: Installing The Hard Disk Drive

    Installing the Hard Disk Drive Read the following guidelines before you begin to install the HDD: • Take note of the drive tray orientation before sliding it out. • The tray will not fit back into the bay if inserted incorrectly. •...

  • Page 26: Installing The Cpu And Heat Sink

    Installing the CPU and Heat Sink Read the following guidelines before you begin to install the CPU: • Make sure that the motherboard supports the CPU. • Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage.

  • Page 27: Removing And Installing The Heat Sink

    Removing and installing the Heat Sink Read the following guidelines before you begin to remove/install the heat sink: • Always turn off the computer and unplug the power cord from the power outlet before installing the heat sink to prevent hardware damage. •...

  • Page 28: Installing The Memory

    Installing the Memory Read the following guidelines before you begin to install the memory: • Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. • Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.

  • Page 29: Processor And Memory Module Matrix Table

    3-6-2 Installing the Memory Before installing a memory module, make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module. Be sure to install DDR5 DIMMs on this motherboard. Follow these instructions to install the Memory: Insert the DIMM memory module vertically into the DIMM slot, and push it down.

  • Page 30: Dimm Population Table

    3-6-4 DIMM Population Table EPYC Memory Speed based on DIMM Population (One DIMM per Channel) DIMM Population DIMM EPYC 9004 Type DDR5 Frequency (MT/s) DIMM 0 1R (1 Rank) 4800 RDIMM 2R (2 Ranks) 4800 2S2R (4 Ranks) 4800 3DS RDIMM 2S4R (8 Ranks) 4800 2S8R (16 ranks)

  • Page 31: Installing The M.2 Device And Heat Sink

    Installing the M.2 Device and Heat Sink CAUTION The position of the stand-off screw will depend on the size of the M.2 device. Refer to the size of the M.2 device and change the position of the stand-off screw accordingly. WARNING Please ensure a heatsink is attached to any M.2 device installed into the system.

  • Page 32: Replacing The Fan Assembly

    Replacing the Fan Assembly • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered-down and all power sources have been disconnected from the server prior to replacing a system fan.

  • Page 33: Removing Ans Installing The Fan Duct

    Removing ans Installing the Fan Duct Follow these instructions to remove/install the fan duct: Lift up to remove the fan duct To install the fan duct, align the fan duct with the guiding groove. Push down the fan duct into chassis until its firmly seat.

  • Page 34: Replacing The Power Supply

    3-10 Replacing the Power Supply CAUTION! • In order to reduce the risk of injury from electric shock, disconnect AC power from the power supply before removing the power supply from the system Follow these instructions to replace the power supply: Flip and then grasp the power supply handle.

  • Page 35: Cable Routing

    3-11 Cable Routing 3-11-1 Motherboard to HDD BPB / Front IO Board / Power Board Power Board (CPDXD40) HDD Backplane Board Front I/O Board Power Board (CPDXD41) CPU0 CPU1 System Hardware Installation - 35 -...
  • Page 36 Signal Cable Power Cable Motherboard F_USB1 Motherboard PWR_STBY Front IO Board F_USB3 Power Board PWR_STBY - CPDXD41 Motherboard FP_1 Motherboard BP_PWR Front IO Board FP_1 HDD BPB BPB_PWR Motherboard MB_PSU_COM Power Board MB_PSU_COM - CPDXD41 Motherboard BP_1 HDD BPB BP_1 NVMe Cable P1(U_2_0) HDD BPB...

  • Page 37: Motherboard To Pcie Slot / Rear Io Board

    3-11-2 Motherboard to PCIe Slot / Rear IO Board Power Board (CPDXD40) Power Board (CPDXD41) CPU0 CPU1 P2 P1 P2 P1 P2 P1 SLOT 11 SLOT 9 SLOT 7 SLOT 8 SLOT 5 SLOT 1 SLOT 3 Rear I/O Board System Hardware Installation - 37 -...
  • Page 38 Power Cable for PCIe Slot MCIO Cable for PCIe Slot P1(U2_P1_P0_0) PCIe Slot SLOT 1 Motherboard P2(U2_P1_P0_1) Motherboard PCIE1_PWR PCIe Slot PCIe Slot SLOT 1 SLOT 5 P1(U2_P1_P1_1) Motherboard PCIE5_PWR Motherboard P2(U2_P1_P1_0) PCIe Slot SLOT 7 PCIe Slot Motherboard SLOT 5 PCIE7_PWR PCIe Slot P1(U2_P1_P2_0)

  • Page 39: Chapter 4 Motherboard Components

    Chapter 4 Motherboard Components Motherboard Components 49 50 CPU0 CPU1 Motherboard Components - 39 -...
  • Page 40 Code Description BUSBAR_GND Bus Bar Input Power (GND) BUSBAR_P12V Bus Bar Input Power (P12V) CASE_OPEN Case Open Intrusion Alert Header PSOUT Side Band Signal Connector U2_P1_P0_0 MCIO Connector Slot1 (PCIe Gen5)_PB U2_P1_P0_1 MCIO Connector Slot1 (PCIe Gen5)_PA U2_P1_P1_0 MCIO Connector Slot5 (PCIe Gen5)_PB U2_P1_P1_1 MCIO Connector Slot5 (PCIe Gen5)_PA PCIE1_PWR...
  • Page 41 Code Description FP_1 Front Panel Header BP_1 HDD Backplane Board Connector BP_PWR 2 x 3 Pin ATX Backplane Board Power Connector System Battery PWR_IN1 Input Power Connector PWR_IN2 Input Power Connector F_USB1 Front Panel USB 3.2 Gen 1 Connector PWR_IN3 Input Power Connector PWR_IN4 Input Power Connector...

  • Page 42: Jumper Setting

    Jumper Setting Default Enable Clear CMOS 1 2 3 CLR_CMOS CPU0 CPU1 CDCX101 CSC400 (Top) (Bottom ) BMC Readiness LED BMC2 BMC1 BIOS2 BIOS1 Motherboard Components - 42 -...

  • Page 43: Backplane Board Storage Connector

    Backplane Board Storage Connector 4-3-1 CBPX060 Item Description MCIO Connector (U_2_0) MCIO Connector (U_2_1) MCIO Connector (U_2_2) MCIO Connector (U_2_3) MCIO Connector (U_2_4) MCIO Connector (U_2_5) Motherboard Components - 43 -...

  • Page 44: Chapter 5 Bios Setup

    Chapter 5 BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the EFI on the motherboard. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters, loading the operating system etc. The BIOS includes a BIOS Setup program that allows the user to modify basic system configuration settings or to activate certain system features.
  • Page 45  Main This setup page includes all the items of the standard compatible BIOS.  Advanced This setup page includes all the items of Insyde BIOS special enhanced features. (ex: Auto detect fan and temperature status, automatically configure hard disk parameters.) ...

  • Page 46: The Main Menu

    The Main Menu Once you enter the BIOS Setup program, the Main Menu (as shown below) appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter other sub-menu. Main Menu Help The on-screen description of a highlighted setup option is displayed on the bottom line of the Main Menu.
  • Page 47 Parameter Description BIOS Information BIOS Vendor/BIOS Version/AGESA Displays the BIOS related information. Version Build Date and Time Displays the date and time when the BIOS setup utility was created. VR Information Version Displays VR version information. Onboard LAN Information LAN1/LAN2 MAC Address Displays LAN MAC address information.

  • Page 48: Advanced Menu

    Advanced Menu The Advanced Menu displays submenu options for configuring the function of various hardware components. Select a submenu item, then press <Enter> to access the related submenu screen. BIOS Setup - 47 -...

  • Page 49: Demo Board

    5-2-1 Demo Board Description Parameter Selects between onboard or external VGA support. OnBrd/Ext VGA Select Options available: Auto, Onboard, External. BIOS Setup - 48 -...

  • Page 50: Boot Configuration

    5-2-2 Boot Configuration Description Parameter Select Power-on state for NumLock. Numlock Options available: On, Off. BIOS Setup - 49 -...

  • Page 51: Peripheral Configuration

    5-2-3 Peripheral Configuration Parameter Description Peripheral Configuration Enable/Disable BIOS TPM physical presence. Note: Need to reboot when set from disablel to enable before Trust Platform Module selecting TPM operation. Options available: Disabled, Enable discrete TPM. BIOS Setup - 50 -...

  • Page 52: Sata Configuration

    5-2-4 SATA Configuration Parameter Description SATA Configuration SATA operates in To set the SATA Controller operates amximum Gen2. maximum Gen2 Options available: Disabled, Enabled. SATA clock auto off To set the SATA clock auto off. Options available: Disabled, Enabled. SATA controller auto To set the Options available: Disabled, Enabled.

  • Page 53: Memory Configuration

    5-2-5 Memory Configuration Parameter Description Memory Configuration 5-Level Paging To enable or disable 5-Level Paging. Options available: Disabled, Enabled. BIOS Setup - 52 -...

  • Page 54: Usb Configuration

    5-2-6 USB Configuration Parameter Description USB Configuration Enable/Disable USB Hardware SMI support. USB Hardware SMI support Options available: Disabled, Enabled. BIOS Setup - 53 -...

  • Page 55: Cpu Related Configuration

    5-2-7 CPU Related Configuration Parameter Description CPU Related Configuration Enable/Disable the CPU Virtualization. SVM support Options available: Enabled, Disabled. Enable or disable the SSM (System Management mode) code segment/ SMM Code Lock registers. Options available: Enabled, Disabled. BIOS Setup - 54 -...

  • Page 56: Cpu Configuration

    5-2-8 CPU Configuration Description Parameter Displays the installed processor. CPU Information Socket 1 Socket 2 Processor Version CPUID CPU Speed CPU Voltage CPU Stepping L1 Data Cache (Per Core) Displays the technical specifications for the installed processor(s). L1 Instruction Cache Per Core L2 Cache (Per Core) L3 Data Cache (Per Core) Number of Processors...

  • Page 57: Pci Subsystem Settings

    5-2-9 PCI Subsystem Settings BIOS Setup - 56 -...
  • Page 58 Description Parameter Displays the PCI Bus Driver version information. PCI Subsystem Setting If the system has SR-IOV capable PCIe devices, this item Enable/ Disable Single Root IO Virtualization Support. PCIe SR-IOV Options available: Enabled,Disabled. To load PCI network device embedded UEFI Option ROM during POST.

  • Page 59: Gtc Item

    5-2-10 GTC Item Parameter Description GCT Item Displays the NVMe devices connected to the system. ErP Lot 9 support. ErP Mode Options available: Lot 9, Disabled.. Enable/Disable system redriver. System Redriver Enable Options available: Enabled, Disabled. Enable/Disable system onboard redriver. System Onboard Redriver Enable Options available: Enabled, Disabled.
  • Page 60 Parameter Description Press [Enter] to configure advanced items. GBT Dual BIOS WDT Enable Š – Options available: Enabled, Disabled. GBT Dual BIOS WDT Time (Sec) Š GBT Dual BIOS Watchdog Timer – Configure Dual BIOS WDT Time. Options Enable Test Mode in PEI Š...

  • Page 61: Amd Mem Configuration Status

    5-2-11 AMD Mem Configuration Status Description Parameter Press [Enter] to view the memory configuration status related to socket 0/1. Socket 0/1 BIOS Setup - 60 -...

  • Page 62: Cxl Device Information

    5-2-12 CXL Device Information Description Parameter Displays the capacity of all CXL type 3 device Total Memory BIOS Setup - 61 -...
  • Page 63 5-2-13 H20 IPMI Configuration BIOS Setup - 62 -...
  • Page 64 Description Parameter IPMI Interface Configuration page. This page contains IPMI Interface related settings. IPMI Support Options available: Enabled, Disabled. Press [Enter] to configure advanced items. Max Detect Time (Sec) IPMI Interface Configuration Š – Configure IPMI Max Detect Time. Enable/Disable the ACPI SPMI Table for IPMI driver installation. ACPI SPMI Table Options available: Enabled, Disabled.
  • Page 65 Description Parameter User Configuration Š – Press [Enter] to configure advanced items. CHA LAN Channel Number Š – Configure CHA LAN Channel Number CHA IPv4 Mode Š – Selects to configure LAN channel parameters statically or dynamically (DHCP). Do nothing option will not modify any BMC network parameters during BIOS phase.

  • Page 66: Console Redirection Configuration

    5-2-14 Console Redirection Configuration Description Parameter Console Redirection Configuration Enable/Disable the Serial Port (COM). When set to Enabled allows you to configure the Serial port 1 settings. When set to Disabled, displays no Console Serial Redirect configuration for the serial port. Options available: Enabled,Disabled.
  • Page 67 A parity bit can be sent with the data bits to detect some transmission errors. Even: parity bit is 0 if the num of 1's in the data bits is even. Odd: parity bit is 0 if num of 1's in the data bits is odd. Parity Mark: parity bit is always 1.

  • Page 68: Memory Information

    5-2-15 Memory Information Description Parameter Memory Information Hidden Not Installed Press [Enter] to hide the empty memory slot. Memory Memory Error Correction Displays the memory error correction types information. Types Displays the total memory size of the installed memory. Total Memory DIMM_P0_#0 Press [Enter] to enable/disable specific memory channel.

  • Page 69: Sata Drive Information

    5-2-16 SATA Drive Information Description Parameter By Controller Display Mode AMD FCH SATA Controller AMD FCH SATA controller information. BIOS Setup - 68 -...

  • Page 70: Usb Device Viewer

    5-2-17 USB Device Viewer Description Parameter Click to show detailed information of this host controller. Flat View BIOS Setup - 69 -...

  • Page 71: H20 Redfish Configuration

    5-2-18 H20 Redfish Configuration Description Parameter Redfish Configuration Options available: Enable, Disable. Redfish Support Options available: Enable, Disable. Redfish BIOS Support Redfish Boot Option Options available: Enable, Disable. Support Options available: Enable, Disable. Redfish SMBIOS Support Redfish OS Deployment Options available: Enable, Disable. Support Redfish PCI Device Info Options available: Enable, Disable.

  • Page 72: Sio Ast2Xxx

    5-2-19 SIO AST2XXX Description Parameter UART Port 1 Configuration Press [Enter] for advanced configuration. Options available: Enabled, Disabled. UART Port 1 Options available: 3F8h, 2F8h, 3E8h, 2E8h, 338h, 238h, 220h, 228h, 210h, Base I/O Address 218h, 218h, 240h, 248h. Options available: IRQ4, IRQ3, IRQ5, IRQ6, IRQ7, IRQ10, IRQ11. Interrupt Options available: Rising Edge Trigger, Low Level Trigger, High Level Trigger.

  • Page 73: Nvm Express Information

    5-2-20 NVM Express Information Parameter Description NVMe Configuration Displays the NVMe devices connected to the system. BIOS Setup - 72 -...

  • Page 74: Pxe Configuration

    5-2-21 PXE Configuration Parameter Description PXE Configuration Displays the PXE devices connected to the system. BIOS Setup - 73 -...

  • Page 75: Amd Cbs Menu

    AMD CBS Menu AMD CBS menu displays submenu options for configuring the CPU-related information that the BIOS automatically sets. Select a submenu item, then press [Enter] to access the related submenu screen. Parameter Description AMD CBS Revision Number Displays AMD CBS Revision Number information. BIOS Setup - 74 -...
  • Page 76 5-3-1 CPU Common Options BIOS Setup - 75 -...

  • Page 77: Cpu Common Options

    Parameter Description CPU Common Options Performance Press [Enter] for configuration of advanced items. Allow REP-MOV/STOS to use non-caching streaming stores for large sizes. REP-MOV/STOS Streaming Options available: Enabled ,Disabled, Auto. Prefetcher settings Press [Enter] for configuration of advanced items. Core Watchdog Press [Enter] for configuration of advanced items.
  • Page 78 Parameter Description Enhanced REP MOVSB/ Options available: Disabled, Enabled, Auto. Default setting is Auto. STOSB (ERSM) Enable/Disable the log Transparent errors function. Log Transparent Errors Options available: Auto, Disabled, Enabled. Enable/Disable AVX512. AVX512 Options available: Disabled, Enabled, Auto. Enhanced REP Movs Stos B Options available: Disabled, Enabled, Auto.
  • Page 79 5-3-1-1 Performance Parameter Description Performance Options available: Normal Operation., Customized. OC Mode (Note) Allows you to accept or decline enabling Custom Core Pstates. When Custom Core Pstates accepted, you can disable or customize core pstates. Allows you to accept or decline enabling CCDs, processor cores and threads.
  • Page 80 5-3-1-2 Prefetcher Settings Parameter Description Prefetcher settings Enable/Disable L1 Stream HW Prefetcher. L1 Stream HW Prefetcher Options available: Disable, Enable, Auto. Use memory access history of individual instructions to fetch additional lines when each access is a constant distance from the previous. L1 Stride Prefetcher Enable/Disable L1 Stride Prefetcher.
  • Page 81 5-3-1-3 Core Watchdog Parameter Description Core Watchdog Enable/Disable CPU Watchdog Timer. Core Watchdog Timer Enable (Note) Options available: Disabled, Enabled, Auto. Select the CPU Watchdog Timer interval. Options available: 2.681s, 1.340s, 669.41ms, 334.05ms, 166.37ms, Core Watchdog Timer Interval 82.53ms, 40.61ms, 20.970ms, 10.484ms,5.241ms, 2.620ms, 1.309ms, 654.08us, 326.4us, 162.56us, 80.64us, 39.68us, Auto.

  • Page 82: Df Common Options

    5-3-2 DF Common Options Parameter Description DF Common Options Memory Addressing Press [Enter] for configuration of advanced items. ACPI Press [Enter] for configuration of advanced items. Link Press [Enter] for configuration of advanced items. SDCI Press [Enter] for configuration of advanced items. Probe Filter Press [Enter] for configuration of advanced items.
  • Page 83 Parameter Description Options available: Auto, 1 Segment, 2 Segments, 4 Segment. Number of PCI Segments CCM Throttler Options available: Disabled, Enabled, Auto. Clean Victim FTI Cmd Options available: Disabled, Enabled, Autoo. Balancing CXL Strongly Ordered writes Options available: Disabled, Enabled, Auto. BIOS Setup - 82 -...
  • Page 84 5-3-2-1 Memory Addressing Parameter Description Memory Addressing Specifies the number of desired NUMA nodes per socket. Options available: NPS0, NPS1, NPS2, NPS4, Auto. NUMA nodes per socket NOTE! • Available options may vary by system configuration. • Only dual processor configuration supports NPS0. Enable/Disable the Memory interleaving feature.
  • Page 85 5-3-2-2 ACPI Parameter Description ACPI ACPI SRAT L3 Cache As Enable/Disable report each L3 cache as a NUMA Domain to the OS. Options available: Disabled, Enabled, Auto. NUMA Domain Determines how the SLIT distances are declared. ACPI SLIT Distance Control Options available: Manual, Auto.
  • Page 86 5-3-2-3 Link Parameter Description Enable/Disable GMI link encryption. GMI encryption control Options available: Disabled, Enabled, Auto. Enable/Disable xGMI link encryption. xGMI encryption control Options available: Disabled, Enabled, Auto. Configures the number of xGMI2 links used on a multi-socket system. Options available: Auto, 3 xGMI Links, 4 xGMI Links, 2 xGMI Links + 2 PCI xGMI Link Configuration Links.
  • Page 87 Parameter Description Press [Enter] to configure the xGMI AC/DC Coupled link. xGMI AC/DC Coupled Link xGMI AC/DC Coupled Link Control (Note) Š – Options available: Manual, Auto. Press [Enter] to configure the xGMI Channel Type. xGMI Channel Type xGMI Channel Type Control (Note) Š...
  • Page 88 5-3-2-4 SDCI Parameter Description Options available: Disabled, Enabled, Auto. SDCI (Note) DisRmSteer Options available: Disabled, Enabled, Auto. (Note) Advanced items prompt when this item is defined. BIOS Setup - 87 -...
  • Page 89 5-3-2-5 Probe Filter Parameter Description Specifies whether multiple memory/CXL channels will share probe filter Organization storage. Options available: Auto, Dedicated, Shared. Controls PDR settings that may impact performance by workload and/or Periodic Directory Rinse (PDR) processor. Tuning Options available: Memory-Sensitive, Cache-Bound, Neutral, Adaptive, Auto.

  • Page 90: Umc Common Options

    5-3-3 UMC Common Options Parameter Description UMC Common Options DDR Addressing Options Press [Enter] for configuration of advanced items. DDR Controller Configuration Press [Enter] for configuration of advanced items. DDR MBIST Options Press [Enter] for configuration of advanced items. DDR RAS Press [Enter] for configuration of advanced items.
  • Page 91 5-3-3-1 DDR Addressing Options Parameter Description DDR Addressing Options Interleaves memory blocks across the DRAM chip selects for node 0. Chipselect Interleaving Options available: Disabled, Auto. Enable or disable bank addressing hashing. Address Hash Bank Options available: Disabled, Enabled, Auto. Enable or disable CS addressing hashing.
  • Page 92 5-3-3-2 DDR Controller Configuration Parameter Description DDR Controller Configuration DDR Power Options Press [Enter] for configuration of advanced items. Memory Channel Disable Press [Enter] for configuration of advanced items. Refresh Management (RFM) Press [Enter] for configuration of advanced items. Memory Context Restore Options available: Disabled, Enabled, Auto.
  • Page 93 5-3-3-2-1 DDR Power Options Parameter Description DDR Power Options Enable or disable DDR power down mode. Power Down Enable Options available: Disabled, Enabled, Auto. Sub Urgent Refresh Lower Specifies the stored refresh limit required to enter sub-urgent refresh mode. Bound Urgent Refresh Limit Specifies the stored refresh limit required to enter urgent refresh mode.
  • Page 94 5-3-3-2-2 Memory Channel Disable Parameter Description Memory Channel Disable Memory Channel Disable Float Options available: Disabledd, Enabled. Power Good Memory Channel Disable Bitmask Socket 0/1 Channel_# Press [Enter] to enable/disable specific memory channel. BIOS Setup - 93 -...
  • Page 95 5-3-3-2-3 Refresh Management (RFM) Parameter Description Refresh Management (RFM) Configure Refresh Management. Refresh Management Options available: Enable, Disable, Auto, Force Enable. Options available: Auto, Disable, ARFM Level A, ARFM Level B, ARFM Adaptive Refresh Management Level C. RAA Initial Management Override Rolling Accumulated ACT Initial Management Threshold.
  • Page 96 5-3-3-3 DDR MBIST Options Parameter Description DDR MBIST Options Enable/Disable the Memory MBIST function. MBIST Enable Options available: Disabled, Enabled, Auto. Selects MBIST Test Mode. Interface Mode: Tests Single and Multiple CS transactions and Basic MBIST Test Mode (Note1) Connectivity. Data Eye Mode: Measures Voltage vs.
  • Page 97 5-3-3-3-1 Data Eye Parameter Description Data Eye Pattern Select Options available: PRBS, SSO, Both. Pattern Length Determines the pattern length. The possible options are N=3..12. This item helps read the aggressors channels. Aggressor Channel Options available: One Sub-Channel, Half Channels, All Channels. Aggressor Static Lane Enable/Disable the Aggressor Static Lane Control function.
  • Page 98 Parameter Description Target Static Lane Select This item is configurable when Target Static Lane Control is set to Upper 32 bits Enabled. Target Static Lane Select This item is configurable when Target Static Lane Control is set to Lower 32 bits Enabled.
  • Page 99 5-3-3-4 DDR RAS Parameter Description DDR RAS Enable/Disable the Data Poisoning function. Data Poisoning Options available: Auto, Enabled, Disabled. DRAM Boot Time Post Package Enable/Disable the DRAM Boot Time Post Package Repair function. Options available: Enable, Disable. Repair DRAM Runtime Post Package Enable/Disable the DRAM Runtime Post Package Repair function.
  • Page 100 Parameter Description DRAM ECC Enable Š – Enable/Disable DRAM ECC. When set to Auto, it will set ECC to enable. – Options available: Auto, Enabled, Disabled. Default setting is . DRAM UECC Retry Š – Enable/Disable DRAM UECC Retry. – Options available: Auto, Enabled, Disabled. Default setting is Disabled.
  • Page 101 Parameter Description – DRAM ECS WriteBack Suppression DRAM Scrubbers » Options available: Auto, Enable, Disable. (continued) – DRAM X4 WriteBack Suppression » Options available: Auto, Enable, Disable. DRAM Corrected Error Counter Configure DRAM Corrected Error Counter function. Enable Options available: Disable, NoLeakMode, LeakMode. Enable SMI when DRAM corrected Error Counter count exceeds the DRAM Corrected Error Counter threshold value.
  • Page 102 5-3-3-5 DDR Bus Configuration Parameter Description DDR Bus Configuration Press [Enter] to configure advanced items. RTT_NOM_WR P-State 0 Š – Default setting is Auto. RTT_NOM_RD P-State 0 Š – Default setting is Auto. P-State 0 Dram ODT RTT_WR P-State 0 Š...
  • Page 103 Parameter Description Select the ODT impedance for all DBYTE IOs. Options available: Auto, High Impedance, 480 ohm, 240 ohm, 160 ohm, Processor ODT Pull Up 120 ohm, 96 ohm, 80 ohm, 68.6 ohm, 60 ohm, 53.3 ohm,48 ohm, 43.6 ohm, impedance 40 ohm, 36.9 ohm, 34.3 ohm, 32 ohm, 30 ohm, 28.2 ohm, 26.7 ohm, 25.3 ohm.
  • Page 104 5-3-3-6 DDR Timing Configuration Parameter Description Enforce POR Decline/Accept to configure the advanced items. Accept Active Memory Timing Active memory Timing Settings. Options available: Auto, Enabled. Settings (Note) Specifies the memory target speed in MT/s. Memory Target Speed Options available: Auto, DDR3600, DDR4000, DDR4400, DDR4800, DDR5200, DDR5600, DDR6000, DDR6400.
  • Page 105 5-3-3-7 DDR Training Options Parameter Description DDR Training Options Specify PDA enumeration mode. DRAM PDA Enumerate ID Options available: Auto, Toggling PDA enumeration mode, Legacy PDA Programming Mode enumeration mode. Press [Enter] to configure advanced items. Periodic Training Mode Š –...
  • Page 106 5-3-3-8 DDR Security Parameter Description Security Enable/Disable Transparent SME. TSME Options available: Auto, Enabled, Disabled. Options available: AES-128, AES-256. Enable/Disable Data Scrambling. Data Scramble Options available: Enabled, Disabled. SME-MK Options available: Enabled, Disabled. BIOS Setup - 105 -...
  • Page 107 5-3-3-9 DDR PMIC Configuration Parameter Description DDR PMIC Configuration Enables support for PMIC Error Reporting. PMIC Error Reporting Options available: Auto, False, True. PMIC Operation Mode Options available: Secure Mode, Programmable Mode. Options available: Always, Never, Once. PMIC Fault Recovery Default setting is 1100.
  • Page 108 5-3-3-10 DDR Thermal Throttling Parameter Description DDR Thermal Throttling ODTS Thermal Throttle Options available: Auto, >85 C, >90 C, >95 Threshold TDTS Thermal Throttle Control Options available: Disabled, Enable. BIOS Setup - 107 -...
  • Page 109 5-3-3-11 DDR Miscellaneous Parameter Description DDR Miscellaneous BIOS Setup - 108 -...

  • Page 110: Nbio Common Options

    5-3-4 NBIO Common Options Parameter Description NBIO Common Options SMU Common Options Press [Enter] for configuration of advanced items. NBIO RAS Common Press [Enter] for configuration of advanced items. Options PCIE Press [Enter] for configuration of advanced items. nBif Common Options Press [Enter] for configuration of advanced items.
  • Page 111 5-3-4-1 SMU Common Options Parameter Description SMU Common Options Power Policy Quick Options available: Standard, Best Performance, Energy Efficient. Setting TDP Control Options available: Manual, Auto. PPT Control Options available: Manual, Auto. Selects use the fused Determinism or set customized Determinism. Determinism Control Options available: Manual, Auto.
  • Page 112 Parameter Description Enable/Disable the CPPC feature. CPPC Options available: Disabled, Enabled, Auto. Enable/Disable the HSMP support. HSMP Support Options available: Disabled, Enabled, Auto. SVI3 SVC Speed Control Options available: Auto, Manual. 3D V-Cache Options available:Auto, Disable, 1 stack, 2 stack, 4 stack. L3 BIST Options available: Auto, Disable, Enable.
  • Page 113 5-3-4-2 NBIO RAS Common Options Parameter Description NBIO RAS Common Options NBIO RAS Control Options available: Disabled, MCA, Auto. The value may be used to mask SyncFlood caused by NBIO RAS options. NBIO SyncFlood Generation Options available: Enabled, Disabled, Auto. The value may be used to enable SyncFlood reporting to APML.
  • Page 114 5-3-4-3 PCIE Parameter Description PCIE Options available: Auto, Disabled, Enabled. Data Object Exchange RTM Margining Support Options available: Auto, Disable, Enable. Multi Auto Speed Change On Options available: Auto, Disable, Enable. Last Rate Multi Upstram Auto Speed Options available: Auto, Disable, Enable. Change When enabled, allows the PCIe RP to enter Polling.Compliance state.
  • Page 115 Parameter Description Enable/Disable PCIe ten bit tags for supported devices. (Auto=Disabled) PCIe Ten Bit Tag Support Options available: Disable, Enable, Auto. ARI Forwarding Enable for each downstream port. PCIe ARI Enumeration Options available: Disable, Enable, Auto. Enable/Disable Alternative Routing-ID Interpretation. PCIe ARI Support Options available: Disable, Enable, Auto.
  • Page 116 5-3-4-4 nBif Common Options Parameter Description RCC_DEV0 ACS Rcc_Dev0 Š – Options available: Auto, Disabled, Enabled. AER Rcc_Dev0 Š – Options available: Auto, Disabled, Enabled. DlfEnableStrap1 Š – Options available: Auto, Disabled, Enabled. Phy16GTStrap1 Š – Options available: Auto, Disabled, Enabled. MarginEnStrap1 Š...
  • Page 117 Parameter Description P2PEgressStrap5 Š – Options available: Auto, Disabled, Enabled. DirectTranslatedStrap5 Š – Options available: Auto, Disabled, Enabled. SsidEnStrap5 Š – Options available: Auto, Disabled, Enabled. PriEnPageReq Š – Options available: Auto, Disabled, Enabled. PriResetPageReq Š – Options available: Auto, Disabled, Enabled. SourceVal ACS cntl Š...
  • Page 118 5-3-4-5 IOMMU/Security Parameter Description Enable/Disable the SEV-SNP support. SEV-SNP Support Options available: Disable., Enable. Enable/Disable DRTM Memory reservation. DRTM Memory Reservation Options available: Disabled, Enabled, Auto. Enable/Disable DRTM ACPI virtual device. DRTM Virtual Device Support Options available: Disabled, Enabled, Auto. Enable/Disable DMA remap support in IVRS IVinfo Field.
  • Page 119 5-3-4-6 Enable Port Bifurcation Parameter Description Options available: Disable, Enable, Auto. Enable Bifurcation (Note) Socket0 Slot Info Override Socket1 Slot Info Override (Note) Advanced items prompt when this item is defined. BIOS Setup - 118 -...
  • Page 120 5-3-4-7 Link EQ Preset Options Parameter Description Press [Enter] to configure advanced items. GEN3/4/5 Preset Search Mask Configuration Š – Options available: Custom, Auto. BIOS Setup - 119 -...

  • Page 121: Fch Common Options

    5-3-5 FCH Common Options Parameter Description FCH Common Options I3C/I2C Configuration Options Press [Enter] for configuration of advanced items. SATA Configuration Options Press [Enter] for configuration of advanced items. USB Configuration Options Press [Enter] for configuration of advanced items. AC Power Loss Options Press [Enter] for configuration of advanced items.
  • Page 122 5-3-5-1 I3C/I2C Configuration Options Parameter Description I3C/I2C Configuration Options I3C/I2C 0/1/2/3 Enable Options available: Both Disabled, I3C Enabled, I2C Enabled, Auto. I2C 4/5 Enable Options available: Disabled, Enabled, Auto. Release SPD Host Control Options available: Disabled, Enabled. PMFW Poll DDR5 Telemetry Options available: Disabled, Enabled.
  • Page 123 5-3-5-2 SATA Configuration Options Parameter Description SATA Configuration Options Enable/Disable OnChip SATA controller. SATA Enable Options available: Disabled, Enabled, Auto. SATA RAS Support Options available: Disabled, Enabled, Auto. SATA Staggered Spin-up Options available: Disabled, Enabled, Auto. SATA Disabled AHCI Prefetch Options available: Disabled, Enabled, Auto.
  • Page 124 5-3-5-3 USB Configuration Options Parameter Description USB Configuration Options Enable/Disable USB controller. XHCI Controller0/1 enable Options available: Enabled, Disabled, Auto. Press [Enter] for configuration of advanced items. MCM USB enable XHCI2/ XHCI3 enable (Socket1) Š – Options available: Enabled, Disabled, Auto. BIOS Setup - 123 -...
  • Page 125 5-3-5-4 AC Power Loss Options Parameter Description AC Power Loss Options Selects the AC Loss Control Method. AC Loss Control Options available: Power Off, Power On, Last State. Enable/Disable set FCH power failed shadow by AC Loss control policy in Set FCH Power failed ABL.
  • Page 126 5-3-5-5 Uart Configuration Options Parameter Description Uart Configuration Options Uart 0/1/2/3 Enable Options available: Auto, Disabled. BIOS Setup - 125 -...
  • Page 127 5-3-5-6 FCH RAS Options Parameter Description FCH RAS Options Enable/Disable the ALink RAS Support. ALink RAS Support Options available: Disabled, Enabled, Auto. Enables AB to forward downstream sync-flood message to system Reset After Sync-Flood controller. Options available: Enable, Disable, Auto. BIOS Setup - 126 -...

  • Page 128: Miscellaneous Options

    5-3-5-7 Miscellaneous Options Parameter Description Miscellaneous Options Select whether or not Enable the Spread Spectrum Feature. FCH Spread Spectrum Options available: Disabled, Enabled, Auto. Enable/Disable Boot Timer. Boot Timer Enable Options available: Auto, Disabled, Enabled, Auto. BIOS Setup - 127 -...

  • Page 129: Soc Miscellaneous Control

    5-3-6 SOC Miscellaneous Control Parameter Description SOC Miscellaneous Control Enable/Disable the ConsoleOut function for ABL. ABL Console Out Control (Note) Options available: Disable, Enable, Auto. ABL Console Out Serial Options available: eSPI, SOC UART0, SOC UART1, Auto. Portl (Note) ABL Console Out Serial Port Options available: 0x3F8, 0x2F8, 0x3E8, 0x2E8, Auto.
  • Page 130 Parameter Description Options available: False, True. PSP error injection support Press [Enter] for configuration of advanced items. FAR enforcement state Š – Default setting is Enabled. Firmware Anti-rollback (FAR) SPL value in the CPU Fuse Š SPL value in the SPL table Š...

  • Page 131: Cxl Common Options

    5-3-7 CXL Common Options Parameter Description CXL Common Options Options available: Auto, Enabled, Disabled. CXL Control CXL Physical Addressing Options available: Auto, Normalized address, System address. Options available: Auto, Enabled, Disabled. CXL Memory Attribute CXL Encryption Options available: Disabled, Enabled. Options available: Auto, Enabled, Disabled.
  • Page 132 Parameter Description Press [Enter] for configuration of advanced items. CXL Protocol Error Reporting Š – Options available: SameAsPcieAer, Disabled, ForceAerFwFirstIfCxlPresent. CXL Component Error Reporting Š CXL RAS – Options available: Debug FW-First ,Allow OS First, Force FW- First. CXL Root Port Isolation Š...

  • Page 133: Amd Pbs Menu

    AMD PBS Menu AMD PBS Option menu displays submenu options for configuring the function of AMD PBS. Select a submenu item, then press [Enter] to access the related submenu screen. Parameter Description Protect some AMD specific variables for CBS, PBS and AOD. If locked, some AMD Variable Protection utilities like RU that modify variable at runtime do not work.

  • Page 134: Ras

    5-4-1 RAS Parameter Description Enable/Disable the Periodic SMI for polling [MCA Threshold] error. RAS Periodic SMI Control Options available: Disabled, Enabled. SMI Threshold Configures the SMI Threshold value. SMI Scale Configures the SMI Scale value. Defines the unit of time scale. SMI Scale Unit Options available: millisecond, second, minute.
  • Page 135 Parameter Description PCIe Root Port UnCorr Err Initialize the PCIe AER Uncorrected Error Mask register of Root Port. Mask Reg PCIe Root Port UnCorr Err Initialize the PCIe AER Uncorrected Error Severity register of Root Port. Sev Reg PCIe Device Corr Err Mask Initialize the PCIe AER Corrected Error Mask register of PCIe device.

  • Page 136: Security Menu

    Security Menu The Security menu allows you to safeguard and protect the system from unauthorized use by setting up access passwords. There are two types of passwords that you can set: • Administrator Password Entering this password will allow the user to access and change all settings in the Setup Utility. •...

  • Page 137: Server Management Menu

    Server Management Menu Parameter Description Determines the action taken when the system power is off and a PCI Wake on PME power Management Enable wake up event occurs. Options available: Enabled, Disabled. Auto wake on S5, By Day of month or Fixed time of every day. Auto Wake on S5 Options available: Disabled, Enabled.

  • Page 138: Boot Menu

    Boot Menu The Boot menu allows you to set the drive priority during system boot-up. BIOS setup will display an error message if the legacy drive(s) specified is not bootable. Parameter Description Boot Configuration Enable/Disable showing the logo during POST. Quiet Boot Options available: Enabled, Disabled.
  • Page 139 Parameter Description Power Up Standby Support Options available: Disabled, Enabled. Storage PCI Option Rom Options available: Enabled, Disabled. access right Support ESATA drive boot access right Options available: Enabled, Disabled. Support Position in Boot Order Shell, network and Re movables. Add Boot Options Options available: Auto, First, Last.

  • Page 140: Exit Menu

    Exit Menu The Save & Exit menu displays the various options to quit from the BIOS setup. Highlight any of the exit options then press <Enter>. Parameter Description Saves changes made and closes the BIOS setup. Exit Saving Changes Options available: Yes, No. Save your changes and without exiting system.

  • Page 141: Bios Recovery

    BIOS Recovery The system has an embedded recovery technique. In the event that the BIOS becomes corrupt the boot block can be used to restore the BIOS to a working state. To restore your BIOS, please follow the instructions listed below: Recovery Instruction: 1.
  • Page 142 Appendix I NVLink Bridge Removal Before you remove the NVLink Bridge. • Make sure the system is not turned on or connected to AC power. WARNING! • NVLink Bridges must be removed via the NVLink Bridge Removal Tool to avoid damage to the NVLink interface.

Table of Contents
