Installation instruc-
tions
DHP-A
DHP-A Opti
DHP-AL
DHP-AL Opti
DHP-C
DHP-H
DHP-H Opti Pro
DHP-L
DHP-L Opti
VMBMA702

Advertisement

loading
Need help?

Need help?

Do you have a question about the DHP-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Danfoss DHP-A

Summary of Contents for Danfoss DHP-A

  • Page 1 Installation instruc- tions DHP-A DHP-A Opti DHP-AL DHP-AL Opti DHP-C DHP-H DHP-H Opti Pro DHP-L DHP-L Opti VMBMA702...
  • Page 2 If these instructions are not followed during installation and serv- ice, Danfoss A/Sliability according to the applicable warranty is not binding. Danfoss A/S retains the right to make changes to com- ponents and specifications without prior notice. © 2010 Copyright Danfoss A/S.
  • Page 3 Recommended location............27 4.11 Space requirement, outdoor unit, DHP-A, DHP-AL..28 14.1 Sub-menu HOT WATER............85 4.12 Recommended location of outdoor unit, DHP-A, DHP-AL. 28 14.2 Sub-menu HEAT PUMP............85 14.3 Sub-menu AUX. HEATER............86 Drilling holes for brine pipes............29 14.4...
  • Page 4 Technical data, DHP-AL............121 Technical data, DHP-AL Opti..........123 2 – VMBMA702...
  • Page 5 About the instructions Introduction The installation instructions start by describing heat pump data. The installation instructions later give instructions in a logical order covering unpacking, installation procedure, and checking the installation. References to chapters and sections within the instructions are in italics, e.g.: About the instructions. References to menu options in the heat pump’s control system are in upper case, e.g.: INFORMATION ->OPERAT.
  • Page 6 Warning! Danfoss SP (1-phase) heat pumps have a factory installed safety valve for temperature and pressure, (10 bar 90-95° C), in accordance with the requirements in Great Britain. This valve is located in the water tank and may not be used for any purpose other than connecting the outlet pipe.
  • Page 7 Caution! The hot water tank must be equipped with an approved safety valve. Caution! Heating systems with closed expansion tanks must also be supplied with approved pressure gauges and safety valves. Caution! Cold and hot water pipes and overflow pipes from safety valves must be made of heat resistant and corrosion-resistant material, e.g.
  • Page 8 Warning! Risk of personal injury! Refrigerant exposed to a naked flame creates a poisonous irritating gas. This gas can be detected by its odour even at concentrations below its permitted levels. Evacuate the area until it has been sufficiently ventilated. 2.1.3 Work on the refrigerant circuit Caution! When repairing the refrigerant circuit, the refrigerant must not be released from the heat pump, it...
  • Page 9 Commissioning Caution! The installation may only be commissioned if the heating system and brine system have been filled and bled. Otherwise the circulation pumps can be damaged. Caution! If the installation is only to be driven by an auxiliary heater during the installation, ensure that the heating system is filled and the brine pump and compressor cannot be started.
  • Page 10 Check and safety functions The heat pump has a number of check and safety functions to protect the installation against damage during abnor- mal operating conditions. The diagram below shows the heat pump's three circuits with respective safety functions. Symbol explanation Heat transfer fluid circuit Safety valve, heat transfer fluid circuit, externally mounted...
  • Page 11 The compressor is equipped with a thermal over current relay to protect it against over current. Symbol explanation Thermal over current relay (F11) Figure 2. The thermal over current relay on the electrical panel If the thermal over current relay (1) is activated, the heat pump's normal operation is blocked, an alarm indicator on the heat pump's control panel flashes and a warning text appears in the display of the control panel.
  • Page 12 The auxiliary heater consists of an electric heating element mounted on the heating system supply line. It has an overheat protector that switches off the electric heating element if it is at risk of becoming overheated. The overheat protector's control unit is on the electrical panel. Symbol explanation Overheating protection Reset button...
  • Page 13 Heat pump information Note! Illustrations of products are not precise drawings and must only be considered as schematic images. Differences in component parts may occur. DHP-H 4.1.1 Dimensions and connections The brine pipes can be connected on either the left or right-hand sides of the heat pump. Symbol explanation Brine in, 28 Cu Brine out, 28 Cu...
  • Page 14 4.1.2 Components The component image below shows a schematic of what the inside of a heat pump looks like. There may be differences between different versions. Figure 5. The components are shown above Symbol explanation Water heater, 180 litres Drying filter Return pipe sensor, heating system Expansion valve Evaporator, insulated...
  • Page 15 DHP-H Opti Pro 4.2.1 Dimensions and connections The brine pipes can be connected on either the left or right-hand sides of the heat pump. Symbol explanation Brine in, 28 Cu Brine out, 28 Cu Heating system supply pipe, 22 Cu: 4-10 kW, 28 Cu: 12-16 kW Heating system return pipe, 22 Cu: 4-10 kW, 28 Cu: 12-16 kW Expansion pipe, 22 Cu Hot water line, 22 mm...
  • Page 16 4.2.2 Components The component image below shows a schematic of what the inside of a heat pump looks like. There may be differences between different versions. Figure 7. Components Symbol explanation Water heater, 180 litres Drying filter Return pipe sensor, heating system Hot water temperature sensor (displays max- imum temperature) Evaporator, insulated...
  • Page 17 DHP-C 4.3.1 Dimensions and connections The brine pipes can be connected on either the left or right-hand sides of the heat pump. Symbol explanation Brine in, 28 Cu Brine out, 28 Cu Heating system supply pipe, 22 Cu Heating system return pipe, 22 Cu Expansion pipe, 22 Cu Hot water line, 22 mm Cold water line, 22 mm...
  • Page 18 4.3.2 Components The component image below shows a schematic of what the inside of a heat pump looks like. There may be differences between different versions. Figure 9. The components are shown above Symbol explanation Water heater, 180 litres Brine out Return pipe sensor, heating system Brine pump, brine system Evaporator, insulated...
  • Page 19 Symbol explanation Brine in, 28 Cu Brine out, 28 Cu Heating system supply pipe, 22 Cu: 4-10 kW, 28 Cu: 12-16 kW Heating system return pipe, 22 Cu: 4-10 kW, 28 Cu: 12-16 kW Lead-in for supply, sensor and communication cables 40±10 4.4.2 Components...
  • Page 20 Brine pump brine system High pressure switch Drying filter Condenser with primary side drain DHP-A, DHP-A Opti 4.5.1 Dimensions and connections The brine pipes can be connected on either the left or right-hand sides of the heat pump. Symbol explanation...
  • Page 21 4.5.2 Outdoor unit 1175 Figure 12. Outdoor unit, dimensions and connections. Symbol explanation Brine in, 28 Cu Brine out, 28 Cu Figure 13. Outdoor unit and connections Symbol explanation Outdoor unit Cover Cover Connection, brine in to outdoor unit Front cover Connection, brine out from outdoor unit Stand Connection, drain drip tray...
  • Page 22 4.5.3 Components The component image below shows a schematic of what the inside of a heat pump looks like. There may be differences between different versions. Figure 14. The components are shown above Symbol explanation Water heater, 180 litres Brine out Defrosting tank Hot water temperature sensor (displays maximum tem- perature)
  • Page 23 DHP-AL, DHP-AL Opti 4.6.1 Dimensions and connections The brine pipes can be connected on either the left or right-hand sides of the heat pump. 40±10 40±10 Figure 15. Dimensions and connections heat pump and water heater Symbol explanation Heat pump Brine in, 28 Cu Heating system supply pipe, 22 Cu: 6-10 kW, 28 Cu: 12 kW Brine out, during normal operation, 28 Cu...
  • Page 24 4.6.2 Outdoor unit 1175 Figure 16. Outdoor unit, dimensions and connections. Symbol explanation Brine in, 28 Cu Brine out, 28 Cu Figure 17. Outdoor unit and connections Symbol explanation Outdoor unit Cover Cover Connection, brine in to outdoor unit Front cover Connection, brine out from outdoor unit Stand Connection, drain drip tray...
  • Page 25 4.6.3 Components The component image below shows a schematic of what the inside of a heat pump looks like. There may be differences between different versions. Figure 18. The components are shown above Symbol explanation Heating system supply pipe Drying filter Brine out to outdoor unit Expansion valve Return pipe, heating system...
  • Page 26 Symbol explanation Circulation pump coolant system Operating pressure switches Exchange valve, heating system High pressure switch Symbol explanation Defrosting tank Water heater TWS coil Connection, expansion line when outdoor unit is positioned at high level Connection, to TWS coil Cold water line, 22 mm Hot water line, 22 mm Bleed valve, at stainless steel water heater Connection, brine out, during defrost...
  • Page 27 Part no. Quan Name tity 086U0026 Rubber bellows for 22-32 mm hole 086U6033 Flexible hose R20 L=550 086U6006 Filler device DN25 086U3427 Dirt filter with shut-off DN20 4.7.3 Sizes 12 kW - 16 kW Table 3. Package contents, 12-16kW Part no. Quan Name tity...
  • Page 28 Part no. Quan Name tity 086U6007 Filler device DN32 086U6005 Dirt filter with shut-off DN25 Transporting the heat pump Caution! During transportation or lifting of the entire heat pump, the front panel must always be installed as it locks the other panels construction. Caution! The heat pump must always be transported and stored in a dry area.
  • Page 29 300 mm 300 mm 10 mm 600 mm Symbol explanation DHP-H DHP-H Opti Pro DHP-C DHP-A DHP-A Opti DHP-L DHP-L Opti DHP-AL DHP-AL Opti Figure 19. Minimum headroom for heat pump installation 4.10 Recommended location Caution! To avoid condensation problems for the brine lines, as short a brine line as possible is recommended indoors.
  • Page 30 Necessary service space for outdoor unit. 4.12 Recommended location of outdoor unit, DHP-A, DHP-AL When positioning the outdoor unit, note the following: Caution! When the outdoor unit is defrosting, water will drip straight down under the unit. The area around the outdoor unit must therefore be properly drained in order to take the water (approximately 2 litres per defrost).
  • Page 31 Drilling holes for brine pipes Caution! Ensure that the holes for the insert pipes are positioned so that there is room for the other installations. Caution! The brine pipes shall have separate lead-ins. If the wall lead-ins are below the highest ground water level watertight lead-ins must be used.
  • Page 32 Separating the heat pump Note! Does not apply to DHP-L, DHP-L Opti, DHP-AL, DHP-AL Opti. If there is a shortage of space when transporting the heat pump to the installation location it may be necessary to separate the heat pump unit and the water heater. The following instruction describes how a heat pump is separated to transport the separate parts more easily.
  • Page 33 Figure 23. Top panel and side panels Slacken off the screws that hold the rear panel and remove it. Disconnect the electrical connectors at the exchange valve, circulation pump and electrical auxiliary heater. Disconnect the cables for the following sensors at the electrical panel: •...
  • Page 34 Disconnect the flexible hose at the electrical auxiliary heater, see figure below. Figure 25. Connections Unscrew the four screws in the corners that hold the water heater’s bottom plate. Warning! Always use two people for heavy lifting. Lift off the unit with the water heater, pipe and electrical auxiliary heater. Figure 26.
  • Page 35 Unpacking and installation Setting up Note! The heat pump has feet that can be adjusted to compensate for irregularities in the surface on which it is sitting. If the surface is so irregular that the feet cannot compensate for it, the installation engineer must remedy this.
  • Page 36 Lift the front cover upwards to remove it from the heat pump. Unpacking and installing the outdoor unit Note! Applies from AtriamodellernaDHP-A, DHP-A Opti, DHP-AL, DHP-AL Opti. The outdoor unit is packed and delivered in a crate. Start by unpacking the unit from the crate.
  • Page 37 Symbol explanation Ends Strut Feet Figure 30. Assembling the stand Screw the adjustable feet (3) into the holes under the ends. 7.3.2 Preparing the outdoor unit While the outdoor unit remains on the pallet it should be prepared for placing on the stand. Carry out the following: There are three M6x20 screws on the lower edge of the outdoor unit.
  • Page 38 7.3.3 Assembling the outdoor unit on the stand Lift the outdoor unit into the place on the stand. Figure 31. Lift the outdoor unit onto the stand Screw the outdoor unit onto the stand. Use 4 x M6x20 screws. It may be necessary to push and pull the stand slightly in order to get the screw holes to align.
  • Page 39 7.3.5 Install the cover Hook the cover at the front edge on the front cover. Figure 33. Hook the front cover into place Secure the cover using a screw on each side. Use 2 x cross head screws. If the cover does not align with the side cover plates it may be necessary to drill new 3 mm holes: •...
  • Page 40 7.3.7 Assembling the defrost sensor Figure 36. Hook the defroster sensor into place Slide the mounting for the defroster sensor into the hole on the reverse of the outdoor unit until the cover hooks into place on the edge. Secure the defroster sensor at the bottom of the mounting using a cable tie. The outdoor unit is now mounted and can be adjusted on the site where it should be set up.
  • Page 41 Warning! Danfoss SP (1-phase) heat pumps have a factory installed safety valve for temperature and pressure, (10 bar 90-95° C), in accordance with the requirements in Great Britain. This valve is located in the water tank and may not be used for any purpose other than connecting the outlet pipe.
  • Page 42 Safety valve Shut-off cock and strainer Connection to any water heaters Flexible hose Flexible hose Figure 38. Principle solution for a piping installation Expansion tank To drain 8.1.3 Connection heat transfer fluid DHP-A, DHP-A Opti 40 – Installation instructions VMBMA702...
  • Page 43 The image shows the principles of a pipe installation with all components Symbol explanation Supply line Return line Shut-off cock and strainer Flexible hose Flexible hose Filler tap Safety valve, 9 bar cold water Expansion tank Figure 39. Principle solution for a piping Safety valve installation Pressure gauge...
  • Page 44 For system solution 1, select the factory setting in menu SERVICE\AUX. HEATER\EXTERNAL ADDITION: EXTERNAL AUX. HEATER = 0 (Off) REV.V. HOT WATER = INT 8.2.1 Example system solution 1 System solution for DHP-H, DHP-H Opti Pro, DHP-C, DHP-A, DHP-A Opti. Symbol explanation Heat pump Supply line Return line...
  • Page 45 8.2.2 Example system solution 1 System solution for DHP-L, DHP-L Opti Symbol explanation Heat pump Supply line Return line Cold water Hot-water Water heater Shut-off valve Non-return valve Safety valve expansion heating system Safety valve cold water 9 bar Vacuum valve Strainer Flexible hose Expansion heating system...
  • Page 46 For system solution 2, select in menu SERVICE\AUX. HEATER\EXTERNAL ADDITION: EXT.AUX.HEATER = ON REV.V. HOT WATER = INT 8.3.1 Example system solution 2 System solution for DHP-H, DHP-H Opti Pro, DHP-C, DHP-A, DHP-A Opti. Symbol explanation Heat pump Supply line Return line...
  • Page 47 8.3.2 Example system solution 2 System solution for DHP-L, DHP-L Opti. 72 36 51 Symbol explanation Heat pump Supply line Return line Cold water Hot-water Water heater Circulation pump Supply line sensor, moved out from heat pump Additional shunt Shut-off valve Non-return valve Safety valve expansion heating system Safety valve cold water 9 bar...
  • Page 48 8.3.3 Example system solution 2 System solution for DHP-AL, DHP-AL Opti. Symbol explanation Heat pump Supply line Return line 89 83 80 Cold water 83 80 Hot-water Water heater (DHP-AL) Circulation pump Supply line sensor, moved out from heat pump Additional shunt Shut-off valve Non-return valve...
  • Page 49 8.4.1 Example system solution 3 System solution for DHP-H, DHP-C, DHP-A, DHP-A Opti. Symbol explanation Heat pump Supply line Return line Cold water Hot-water Circulation pump Supply line sensor, moved out from heat pump Additional shunt Reversing valve Shut-off valve...
  • Page 50 8.4.2 Example system solution 3 System solution for DHP-L, DHP-L Opti. 72 36 51 77 Symbol explanation Heat pump Supply line Return line 89 83 Cold water Hot-water Water heater Circulation pump Supply line sensor, moved out from heat pump Additional shunt Reversing valve Shut-off valve...
  • Page 51 8.4.3 Example system solution 3 System solution for DHP-AL, DHP-AL Opti. 36 51 77 Symbol explanation Heat pump Supply line Return line 89 83 Cold water Hot-water Water heater (DHP-AL) Circulation pump Supply line sensor, moved out from heat pump Additional shunt Reversing valve Shut-off valve...
  • Page 52 Noise information 8.6.1 Flexible hoses Caution! The press sleeves may never be used as a counterhold when tightening connections. All pipes should be routed in such a way that vibrations cannot be transmitted from the heat pump through the piping and out into the building. This also applies to the expansion pipe. We recommend that flexible hoses are used for all pipe connections to avoid the transmission of vibrations.
  • Page 53 • Ensure that all pipes are elastically suspended, with mountings as illustrated or similar. This is so that the rubber (or similar material) compresses 1 to 2 mm under vibration. It is not recommended to suspend the pipes from too many points, as the force at each mounting is then not sufficient. Figure 54.
  • Page 54 Filling the water heater and heating system Fill the water heater with cold water by opening the filler valve that is on the valve pipe. Bleed by opening one of the hot water taps. Then fill the water heater coil and the heating system with water through the filling valve to a pressure of approx.
  • Page 55 Electrical Installation DANGER! Electrical voltage! The terminal blocks are live and can be highly dangerous due to the risk of electric shock. All power supplies must be isolated before electrical installation is started. The heat pump is connected internally at the factory, for this reason electrical installation consists mainly of the connection of the power supply.
  • Page 56 Electrical components Symbol explanation Terminal block (applies to the expansion card) Terminal block (applies to DHP-A, DHP-AL) Defrost card (applies to DHP-A, DHP-AL) Terminal block Space for Danfoss Online Warning decal Space for expansion card Motor protection for compressor Automatic fuses Resetting overheating protection Figure 56.
  • Page 57 Position and connect outdoor sensors Caution! The outdoor sensor uses protected extra low voltage. Follow the specific installation instructions for the outdoor sensor! Figure 58. Positioning the outdoor sensor Recommended location Unsuitable location • Position the outdoor sensor on the north or north west side of the house. •...
  • Page 58 Additional shunt Terminal block, 215/216 Internal exchange I/O-card, 214 (normal connection) valve For DHP-A, DHP-A Opti, DHP-AL, DHP-AL Opti the electrical connection for system solution 2 must be carried out according to the following table: Table 7. Electrical connection Component...
  • Page 59 Terminal block, 215/216 External exchange I/O-card, 214 kW, connected and fused with 086U9685 valve For DHP-A, DHP-A Opti, DHP-AL, DHP-AL Opti the electrical connection for system solution 3 must be carried out according to the following table: Table 10. Electrical connection...
  • Page 60 Change the number of auxiliary heating power stages in the control system's menu SERVICE -> AUX.HEAT -> MAXSTEP, select the number of stages using + and -. Connect outdoor unit, DHP-A, DHP-AL Caution! The power cable may only be connected to the terminal block intended for this purpose. No other terminal blocks may be used! Route the power cable through the opening in the top panel of the heat pump to the terminal blocks.
  • Page 61 Brine installation 10.1 Heat sources 10.1.1 Bedrock heat To use rock as the heat source one or more boreholes is/are drilled and the brine hose is lowered into it/them. The hole is filled with water and a fitting with a weight is fastened to the hose before it is lowered. Figure 59.
  • Page 62 10.1.2 Lake heat When lake water is used as the heat source one or more brine coils is/are submerged in the water . The coils must be anchored to the bottom with weights or a net to prevent them floating. Figure 60.
  • Page 63 When ground water is used as a heat source the heat pump installation must be equipped with a flow sensor (available as an accessory) that stops the heat pump if the flow in the brine line is too low, which can create a risk of freezing in the ground water exchanger.
  • Page 64 Air heat The DHP-A andDHP-AL heat pumps are equipped with an outdoor unit that uses outdoor air as a heat source. DHP- AL can make use of the energy in the air outdoors down to temperatures of -20 degrees. To obtain the correct airflow through the outdoor section it is equipped with a fan.
  • Page 65 The maximum lengths in the table below are based on ethylene glycol (which is mixed to anti-freeze protection down to -32°C) at 0°C. Table 11. Max coil length between heat pump and outdoor unit DHP-A, DHP-AL Ext.avail. Calculated maximum coil length between the HP and outdoor unit, in metres press. Size...
  • Page 66 DHP-H, DHP-C, DHP-L Calculated maximum coil length per coil, in metres <190 <2 x 350 <70 <2 x 175 <3 x 183 4 x 197 Table 13. Maximum coil length, hose type PEM DN 32, Øi = 28.0 DHP-H Opti Pro, DHP-L Opti Calculated maximum coil length per coil, in metres Size 1 coil...
  • Page 67 The collection well for distributing to several brine coils Choke valves with flow indicators (available as accessories from the Danfoss range) are used to adjust the brine flow so that it is the same in all coils. If choke valves with flow indicators are not available adjust the valves until the temperature of all the coil return hoses is the same.
  • Page 68 3 4 3 Bleed and expansion tank Shut-off valve Pressure tank Figure 68. General connection diagram, brine lines 10.5.3.1 Outdoor unit DHP-A, DHP-AL, DHP-A Opti, DHP-AL Opti Symbol explanation Brine out Brine in Flexible hoses Figure 69. General connection diagram, brine lines 10.5.4...
  • Page 69 If the outdoor unit is installed at the same level or lower than the heat pump, the accompanying plastic vessel can be used. The upper part of the outdoor unit must then not exceed the fluid level in the vessel. Figure 70.
  • Page 70 Collector (single pipe): PEM 40 approximately 1.0 litre/m; PEM 32 approximately 0.6 litre/m; Cu 28 approximately 0.5 litre/m 10.7.2 Calculated volume DHP-A, -AL The volume of the brine system is calculated as follows: • Heat pump (exchanger, pipe and outer jacket) approximately 47 litres •...
  • Page 71 Fill the system with the mixture using an external pump (11) which can bleed the brine pipes. Connect the pressure side of the pump to the filler connection at valve (5). For DHP-A, DHP-AL: open the defroster shunt in the control computer menu SERVICE -> MANUAL TEST -> SHUNT DEFR, set the value to -.
  • Page 72 Caution! Max 150kpa (1.5 bar) Close valve (5). For DHP-A, DHP-AL: close the defroster shunt in the control computer menu SERVICE -> MANUAL TEST -> SHUNT DEFR, set the value to 0. Stop the external pump (11) and disconnect the filling equipment.
  • Page 73 Symbol explanation Bleed screws Figure 74. Location, bleed screws If the outdoor unit is installed at the same level or lower than the heat pump it is recommended that the brine circuit in the outdoor unit is also bled. After bleeding, the side panels and decor front panel must be installed. Installation instructions VMBMA702 –...
  • Page 74 Installing accessories/additional functions 11.1 Room sensor The room temperature sensor has a temperature sensor that provides a further value that the control system can use when calculating the supply temperature. The impact of the room sensor in the calculation can be set in the menu HEAT CURVE ->...
  • Page 75 Wait 10 seconds until the display stops flashing. If the display shows "--" for indoor temperature no indoor temperature has been read. 11.2 EVU function The EVU function prevents the operation of HEATPUMP, ADD.HEAT and CIRC.PUMP as long as the contact is closed. The text EVU STOP is shown in the display when this function is active.
  • Page 76 If necessary, the heat pump can be connected to produce hotter water for the heating system and hot water system when it is installed. Figure 76. The pressure switches on the compressor’s pressure pipe Move the grey cables, which are normally connected to pressure switch A, to pressure switch B. 74 –...
  • Page 77 Menu information Menu description regards software with version 1.3. The heat pump has an integrated control system which automatically calculates the heat demand in the house to ensure that the correct amount of heat is produced and emitted where necessary. There are many different values (parameters), which are required in order to do the calculation of the heat demand.
  • Page 78 The SERVICE menu is used during installation and services with many settings, see Installation instructions. Figure 78. The menus are reached by pressing different buttons. Position Description Information menu Press the left or right buttons. Service menu Press and hold the left button for at least five seconds The INFORMATION menu is opened by pressing the left or right buttons.
  • Page 79 INFORMATION menu Open the menu by pressing the left or right button. The menu also shows history and operating times. Note! The menu information below describes all possible parameters. The parameters that appear in the display vary depending on the selections made in menus (e.g. type of heat pump) and on the connected hardware (e.g.
  • Page 80 Menu Sub menu Sub menu Sub menu HEAT PUMP AUX. HEAT 1 AUX. HEAT 2 AUX. HEAT 3 HOT WATER COOLING ACT COOLING DEFROST DEFROSTS BETW. 2 DEFR TIME LAST DEFR FAN H OFF AT DEFROST CURVE MANUAL DEFR LANGUAGE SVENSKA ENGLISH DEUTSCH...
  • Page 81 13.2 Sub-menu HEAT CURVE Table 20. Used to change settings for the heat curve. Menu selection Meaning Factory setting CURVE Calculated supply temperature at 0°C outdoor temperature. Shown as 40°C a graphic curve. The curve will be limited by the set values of MIN and (for under floor heating 30°C) MAX.
  • Page 82 13.4 Sub-menu TEMPERATURE The history of different temperature measurements can be viewed by pressing the right arrow key. The graph shows the last 60 measurement points for the set time interval (SERVICE -> INSTALLATION -> LOG TIME). In the event of an alarm, history stops being logged until the alarm is reset by changing the operating mode to OFF.
  • Page 83 Menu selection Meaning Factory setting DEFROST CURVE Used to change the angle of the defrost curve using + or– (Change -10°C the start temperature for defrost). (range: -13°C / -7°C) MANUAL DEFR Used to perform a manual defrost. Started using + or -. (range: 0 / 1) 13.7 Sub-menu LANGUAGE...
  • Page 84 SERVICE menu The SERVICE menu is for use during installation and service to optimise and adjust the operation of the heat pump. Open the menu by pressing the left button for five seconds. Note! The menu information below describes all possible parameters. The parameters that appear in the display vary depending on the selections made in menus (e.g.
  • Page 85 Menu Sub menu Settings/Sub menu Settings MANUAL TEST MANUAL TEST HEAT PUMP BRINE PUMP CIRC. PUMP REV.V. HOT WATER SHUNT SYSTEM SHUNT HGW-SHUNT AUX. HEAT 1 AUX. HEAT 2 AUX. HEAT 3 EXT.AUX.HEATER EXT. CIRC. PUMP SHUNT DEFR FAN L FAN H EXT.
  • Page 86 Menu Sub menu Sub menu Sub menu Sub menu 0-10V (Ø EXT. AUX. HEATER) FLOW SENSOR CURRENT LIMITER PHASE FAULT (Ø PHASE READING) SERVICE TIME FACTORY SET CANCEL RADIATOR FLOOR RESET OPER. TIME SENSOR CALIBRATION OUTDOOR SUPPLY LINE RETURN LINE HOT WATER BRINE IN BRINE OUT...
  • Page 87 Menu Sub menu Sub menu Sub menu Sub menu HGW TEMPERATURE TEMPERATURE DIFF HOT WATER DIFF HOT WATER TO RAD MAX TEMPERATURE START HGW INITIALIZING HGW INTEGRAL DELAY HGW-SHUNT TIME HGW INT. BOUND. HGW INTEGRAL PULSE WIDTH 14.1 Sub-menu HOT WATER Table 28.
  • Page 88 Menu selection Meaning Factory setting START INTERVAL Minimum time interval between two heat pump starts in minutes. 20M (range: 10M / 30M) ALARM BRINE Gives an alarm when the outgoing brine temperature falls below the set value. (range: , -14°C / 10°C) PRESS.
  • Page 89 Menu selection Meaning Factory setting REV.V. HOT WATER Indicates whether the INT / EXT exchange valve for hot water is located before or after the external auxiliary heater. (Determines whether the external auxiliary heater may produce hot water.) TOPH. AUX Indicates whether the exter- / ON nal auxiliary heater can be...
  • Page 90 Menu selection Meaning Factory setting SHUNT DEFR - = opens flow from defrosting tank 0 = shunt unaffected + = closes flow from defrosting tank FAN L 0 = stop fan 1 = start fan at low speed FAN H 0 = stop fan 1 = start fan at high speed EXT.
  • Page 91 14.5 Sub-menu INSTALLATION Table 32. Used for settings that are set during installation. Menu selection Meaning Factory setting SYSTEM Sub menu SERVICE -> INSTALLATION -> SYSTEM: Note! The menu selection in the SYSTEM menu varies depending on the selected values. Tip: start in the top menu and work downwards.
  • Page 92 (range: 10S / 60S) 14.6 Sub-menu DEFROST The menu applies to DHP-A, DHP-AL with defrost card and only appears if OUTDOOR AIR in SERVICE -> INSTALLATION -> SYSTEM -> HEAT SOURCE menu is selected. Table 33. Used to change settings for outdoor unit defrost.
  • Page 93 Menu selection Meaning Factory setting DEFR TEMPERA- The temperature shunted to the outdoor unit during a defrost. 15°C TURE (range: 13°C / 25°C) STOP DEFR The temperature that the Brine In sensor must reach to complete a 11°C defrost. (range: 7°C / 12°C) BELOW 5°C DEFR Safety defrosting occurs when the outdoor temperature has been below 5°C for a set number of days, shunts +20°C for 10 minutes.
  • Page 94 14.8 Sub-menu HGW The menu applies to DHP-H Opti Pro models with de-superheater and only appears if ON in SERVICE -> INSTALLATION -> SYSTEM -> ADDITION -> HGW menu is selected. Table 35. Used to change the de-superheater’s operating settings. Menu selection Meaning Factory setting...
  • Page 95 Important parameters 15.1 Heat production - calculating The indoor temperature is adjusted by changing the heat pump’s heat curve, which is the control system’s tool for calculating what the supply temperature should be for water that is sent out in the heating system. The heat curve calculates the supply temperature depending on the outdoor temperature.
  • Page 96 Position Description Set value (standard 40°C). In the event of outdoor temperatures below 0°C, a higher setpoint value is calculated and in the event of outdoor temperatures greater than 0°C, a lower setpoint value is calculated. -2 0 Figure 80. Increasing or reducing the CURVE changes the slope of the curve.
  • Page 97 • When changing the CURVE value, the angle of the curve on the system's heat curve changes. -2 0 Figure 81. Changing the ROOM value changes the heat curve upwards or downwards. Position Description Supply temperature (°C) Maximum supply temperature Outdoor temperature (°C) The relationship of the supply temperature to the outdoor temperature will not be affected.
  • Page 98 15.7 INTEGRAL The heat demand in the house depends on the season and weather conditions and is not constant. The heat demand can be expressed as temperature difference over time and can be calculated giving an integral value as a result (heat demand).
  • Page 99 Symbol explanation INTEGRAL A3 External auxiliary heater The calculation of the integral value stops during heat stop. The calculation of the integral value stops when heat stop has stopped. In this example INTEGRAL A3 < INTEGRAL A2. This means that the external addition will be activated earlier than the internal addition.
  • Page 100 The two parameters that are mainly changed are DEFR CURVE 0 and DEFR CURVE -20. The numbers behind the DEFR CURVE display what outdoor temperature the setting is for, that is to say at 0°C for DEFR CURVE 0 and -20°C for DEFR CURVE -20.
  • Page 101 Adjustable value for DEFR CURVE -20 is 1°C to 8°C lower than OUTDOOR STOP These three settings together create the defrosting curve and all three values have an effect on when defrosting will start, even if it is mainly DEFR CURVE 0 and DEFR CURVE -20 that is changed. Installation instructions VMBMA702 –...
  • Page 102 Start up Note! Read the safety instructions! Caution! The installation may only be commissioned if the heating system, water heater and brine system have been filled and bled. Otherwise the circulation pumps can be damaged. Caution! Any alarms that may occur in connection with the installation must be fault-traced. Caution! If the installation is only to provide heat by an auxiliary heater during the installation, ensure that the heating system is filled and bled and the compressor cannot be started.
  • Page 103 • Direction of rotation of the compressor • Coolant pump • For DHP-A, DHP-AL, outdoor unit • For DHP-A, DHP-AL, defrost sensor • Positioning of the outdoor sensor • Control computer settings If a an external water heater is installed, also check: •...
  • Page 104 • Listen for air If the pump does not start, see Starting circulation pumps manually If there is air in the heating system, vent, see Bleeding the heating system Stop the circulation pump by setting the value to 0. 16.2.4 Test the exchange valve Activate the 3-way valve by setting the value REV.V.
  • Page 105 Stop the circulation pump by setting the value to 0. 16.2.8 Test the outdoor unit for DHP-A, -AL Start the defroster shunt by setting the value SHUNT DEFR to 1. Start the fan at low speed by setting the FAN L value to 1. Check that the fan runs at low speed.
  • Page 106 Noise is produced from the outdoor unit when the fan is in operation, check during that manual operation that there is no disturbance in your own home as well as to any neighbours. A noise kit is available for purchase for the outdoor unit for DHP-A 10 and 12 if it is necessary to reduce the noise. 17.2.2 Select operating mode Set the heat pump to the desired operating mode in the menu INFORMATION ->...
  • Page 107 17.3 Installing the front cover Caution! Take care not to damage the front cover or display cables! Hook on the lower edge of the front cover. Carefully press the front cover’s upper edge towards the heat pump. Turn the catch in the top panel 90 degrees clockwise. 17.4 After start up Note! Remember that it takes time for the heat pump to heat a cold house.
  • Page 108 Customer information After installation and test operation, the customer must be informed about their new heat pump installation. Below is a checklist regarding the information that the installer must give the customer: • The model of the heat pump that has been installed •...
  • Page 109 Technical data, DHP-H Table 36. Technical data DHP-H Type Brine/water Refrigerant Type R407C Amount 0,75 1,20 1,30 1,45 1,55 2,00 Test pressurisation Design pressure Compressor Type Scroll Electrical data Mains power supply V 3-N, ~50 Hz Rated output, com- pressor Rated output, circu- lation pumps Auxiliary heater, 3...
  • Page 110 DHP-H De-superheater Antifreeze Ethylene glycol/ Ethanol Number of units Dimensions L x W 690x596x1845 Weight empty Weight filled Sound effect dB(A level Measurements have been carried out on a limited number of circulation pumps, which can give variations in results. Tolerances in the measurement methods can also give variations.
  • Page 111 Technical data; DHP-H Opti Pro Table 37. Technical data DHP-H Opti Pro Type Brine/water Refrigerant Type R407C Amount 1,15 1,35 1,40 1,55 1,70 Test pressurisation Design pressure Compressor Type Scroll Electrical data Mains power supply 3-N, ~50 Hz Rated output, com- pressor Rated output, circula- tion pumps...
  • Page 112 DHP-H Opti Pro Number of units Dimensions L x W x 690x596x1845 Weight empty Weight filled Sound effect level dB(A) 45 Measurements have been carried out on a limited number of circulation pumps, which can give variations in results. Tolerances in the measurement methods can also give variations.
  • Page 113 Technical data, DHP-L Table 38. Technical data DHP-L Type Brine/water Refrigerant Type R407C Amount 0,75 1,20 1,30 1,45 1,55 2,00 Test pressurisation Design pressure Compressor Type Scroll Electrical data Mains power supply V 3-N, ~50 Hz Rated output, com- pressor Rated output, circu- lation pumps Auxiliary heater, 3...
  • Page 114 DHP-L De-superheater Antifreeze Ethylene glycol/ Ethanol Number of units Dimensions L x W 690x596x1538 Weight empty Weight filled Sound effect dB(A) level Measurements have been carried out on a limited number of circulation pumps, which can give variations in results. Tolerances in the measurement methods can also give variations.
  • Page 115 Technical data, DHP-L Opti Table 39. Technical data DHP-L Opti Type Brine/water Refrigerant Type R407C Amount 1,20 1,35 1,45 1,55 2,00 Test pressurisation Design pressure Compressor Type Scroll Electrical data Mains power supply 3-N, ~50 Hz Rated output, com- pressor Rated output, circula- tion pumps Auxiliary heater, 3 step kW...
  • Page 116 DHP-L Opti Number of units Dimensions L x W x 690x596x1538 Weight empty Weight filled Sound effect level dB(A) 44 Measurements have been carried out on a limited number of circulation pumps, which can give variations in results. Tolerances in the measurement methods can also give variations.
  • Page 117 Technical data, DHP-C Table 40. Technical data DHP-C Type Brine/water Refrigerant Type R407C R407C R407C R134a R134a R134a Amount 1,20 1,30 1,45 0,90 1,00 1,10 Test pressurisation Design pressure 2,45 2,45 2,45 Compressor Type Scroll Electrical data Mains power supply V 3-N, ~50 Hz Rated output, com- pressor...
  • Page 118 DHP-C De-superheater Antifreeze Ethylene glycol/ Ethanol Number of units Dimensions L x W 690x596x1845 Weight empty Weight filled Sound effect dB(A) 47 level Measurements have been carried out on a limited number of circulation pumps, which can give variations in results. Tolerances in the measurement methods can also give variations.
  • Page 119 Technical data, DHP-A Table 41. Technical data DHP-A Type Air/water Refrigerant Type R404A Amount 0,95 1,45 1,50 1,60 Test pressurisation Design pressure Compressor Type Scroll Electrical data Mains power supply V 3-N ~50Hz Rated output, com- pressor Rated output, circ.pumps/fan...
  • Page 120 DHP-A Water volume Water heater Condenser Evaporator Ethylene glycol + water solution with freezing point -32±1°C Antifreeze Number of units Indoor unit Dimensions L x W x 690x596x1845 Weight empty Weight filled dB(A) Sound effect level Outdoor unit Dimensions L x W x...
  • Page 121 Technical data, DHP-A Opti Table 42. Technical data DHP-A Opti Type Air/water Refrigerant Type R404A Amount 0,95 1,45 1,50 1,60 Test pressurisation Design pressure Compressor Type Scroll Electrical data Mains power supply V 3-N ~50Hz Rated output, com- pressor Rated output, circ.pumps/fan...
  • Page 122 DHP-A Opti Water volume Water heater Condenser Evaporator Ethylene glycol + water solution with freezing point -32±1°C Antifreeze Number of units Indoor unit Dimensions L x W x H mm 690x596x1845 Weight empty Weight filled Sound effect level dB(A) Outdoor unit...
  • Page 123 Technical data, DHP-AL Table 43. Technical data DHP-AL Type Air/water Refrigerant Type R404A Amount 0,95 1,45 1,50 1,60 Test pressurisation Design pressure Compressor Type Scroll Electrical data Mains power supply V 3-N ~50Hz Rated output, com- pressor Rated output, circ.pumps/fan Auxiliary heater, 5 3/6/9/12/15 step...
  • Page 124 DHP-AL Water volume Water heater Condenser Evaporator Ethylene glycol + water solution with freezing point -32±1°C Antifreeze Number of units Indoor unit Dimensions L x W x H mm 690x596x1538 Weight empty Weight filled Sound effect level dB(A) Water heater Dimensions L x W x H mm 690x596x1538 Weight empty...
  • Page 125 Technical data, DHP-AL Opti Table 44. Technical data DHP-AL Opti Type Air/water Refrigerant Type R404A Amount 0,95 1,45 1,50 1,60 Test pressurisation Design pressure Compressor Type Scroll Electrical data Mains power supply V 3-N ~50Hz Rated output, com- pressor Rated output, circ.pumps/fan Auxiliary heater, 5 3/6/9/12/15...
  • Page 126 DHP-AL Opti Condenser Evaporator Ethylene glycol + water solution with freezing point below -32? Antifreeze Number of units Indoor unit Dimensions L x W x H mm 690x596x1538 Weight empty Weight filled dB(A) 42,5 47,7 45,5 48,1 Sound effect level Water heater Dimensions L x W x H mm 690x596x1538...
  • Page 127 VMBMA702...
