Freestanding
Elements of Nature Rock
IMPORTANT!
manual will provide important information pertaining to site preparation, footings, system stabilization and
other necessary information vital to the success of your installation.
I500101
200203905
Elements of Nature Rock
Model #
200203905
Notes: Model is available in 63.5mm surface mount, 305mm surface mount, and inground
footing options.
REV
ECN
DESCRIPTION
An (*) by a part number (Code) indicates: Color Code Required.
Installation Guide
Prior to installation of any components, refer to the "Owner/Operator Manual". This
Product
ELEMENTS OF NATURE ROCK
NOTE: 63.5mm surface mount footing is
shown, refer to customer specific model
for correct type of footing.
DATE
DRN CHK'D APP'D
REVISIONS
Ground
Space
11' x 8'-7"
TITLE:
SW
DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE
THE INFORMATION CONTAINED IN
TOLERANCES UNLESS OTHERWISE STATED
THIS DRAWING IS THE SOLE PROPERTY
OF PLAYPOWER. ANY
LINEAR: >0MM
REPRODUCTION IN PART OR AS A
>100MM
WHOLE WITHOUT THE WRITTEN
>1500MM ≤ 3000MM
PERMISSION OF PLAYPOWER IS
PROHIBITED.
>3000MM
WEIGHT:
1953.1
LB
ANGULAR
1
Protective
Area
23' x 21'
-
MAT'L:
AS INDEXED
≤ 100MM
1MM
DRAWN BY/DATE
CHECKED/DATE
≤ 1500MM
2MM
-
-
-
-
3MM
6MM
SHEET:
DRG
1 OF 1
No.
Page 1 of 70
22AUG24
Rev. A
surface mount
APPR0VAL/DATE
-
-
surface mount
REV:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 200203905 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Little Tikes 200203905

Summary of Contents for Little Tikes 200203905

  • Page 1 Prior to installation of any components, refer to the "Owner/Operator Manual". This manual will provide important information pertaining to site preparation, footings, system stabilization and other necessary information vital to the success of your installation. I500101 200203905 Elements of Nature Rock Ground Protective...
  • Page 2 22AUG24 Rev. A Freestanding Elements of Nature Rock ELEMENTS OF NATURE ROCK (63.5mm surface mount) Model 200203905 CODE DESCRIPTION 931728* EON ROCK ROPE KIT 931732 EON ROCK STEP 2 FLEXTREAD 1 931733 EON ROCK STEP 2 FLEXTREAD 2 931734 EON ROCK STEP 3 FLEXTREAD...
  • Page 3 22AUG24 Rev. A Freestanding Elements of Nature Rock ELEMENTS OF NATURE ROCK (63.5mm surface mount) Model 200203905 (continued) CODE DESCRIPTION HW15170-03 HRDW PKG 3LG D SCKL ST S1/1 931741* EON ROCK POST WLDMNT 1 931742* EON ROCK POST WLDMNT 2...
  • Page 4 22AUG24 Rev. A Freestanding Elements of Nature Rock ELEMENTS OF NATURE ROCK (305mm surface mount) Model 200203905 CODE DESCRIPTION 931728* EON ROCK ROPE KIT 931732 EON ROCK STEP 2 FLEXTREAD 1 931733 EON ROCK STEP 2 FLEXTREAD 2 931734 EON ROCK STEP 3 FLEXTREAD...
  • Page 5 22AUG24 Rev. A Freestanding Elements of Nature Rock ELEMENTS OF NATURE ROCK (305mm surface mount) Model 200203905 (continued) CODE DESCRIPTION HW15170-03 HRDW PKG 3LG D SCKL ST S1/1 931782* EON ROCK POST WLDMNT 1 F/305SM 931783* EON ROCK POST WLDMNT 2 F/305SM...
  • Page 6 22AUG24 Rev. A Freestanding Elements of Nature Rock ELEMENTS OF NATURE ROCK (inground) Model 200203905 CODE DESCRIPTION 931728* EON ROCK ROPE KIT 931732 EON ROCK STEP 2 FLEXTREAD 1 931733 EON ROCK STEP 2 FLEXTREAD 2 931734 EON ROCK STEP 3 FLEXTREAD...
  • Page 7 22AUG24 Rev. A Freestanding Elements of Nature Rock ELEMENTS OF NATURE ROCK (inground) Model 200203905 (continued) CODE DESCRIPTION HW15170-03 HRDW PKG 3LG D SCKL ST S1/1 932344* EON ROCK POST WLDMNT 1 F/ING 932345* EON ROCK POST WLDMNT 2 F/ING...
  • Page 8 22AUG24 Rev. A Freestanding Elements of Nature Rock HRDW PKG 3LG D SCKL ST S1/1 HW15170-03 CODE DESCRIPTION 200015170 SHACKLE "D" STYLE 300 S.S. (LARGE) 200016225 BOLT M10X1.5 300SS 6-LOBE F/DSHACKLE(LG) HDWR BAG OF LABELS F/5-12 FS PPLT 925105 CODE DESCRIPTION 200182847 LABEL ID/AGE 5-12...
  • Page 9 22AUG24 Rev. A Freestanding Elements of Nature Rock PPLT PARTS CARTON F/SFMT 929911 (used on surface mount only) CODE DESCRIPTION 200001776 ANCHOR CONCRETE WEDGE M10 X 1.50 X 100MM Page 9 of 70...
  • Page 10 22AUG24 Rev. A Freestanding Elements of Nature Rock FOOTING LAYOUT 63.5mm [2.5"] SURFACE MOUNT 1212mm 1754mm [47 3/4"] [69"] 396mm 1099mm [43 1/4"] [15 5/8"] 1063mm [41 7/8"] 1938mm 1896mm 1594mm [76 1/4"] [74 5/8"] 421mm 1154mm [62 3/4"] [16 5/8"] [45 3/8"] 705mm [27 3/4"]...
  • Page 11 22AUG24 Rev. A Freestanding Elements of Nature Rock FOOTING LAYOUT 305mm [12"] SURFACE MOUNT 1732mm 1228mm [68 1/8"] [48 3/8"] 1122mm 385mm [44 1/8"] [15 1/8"] 1033mm 1903mm [40 5/8"] 1850mm [74 7/8"] 1544mm [72 7/8"] 390mm 1125mm [60 3/4"] [15 3/8"] [44 1/4"] 678mm...

  • Page 12: Top View

    22AUG24 Rev. A Freestanding Elements of Nature Rock FOOTING LAYOUT INGROUND 1683mm 1262mm 305mm [12"] [66 1/4"] [49 5/8"] diameter, 610mm 358mm 1157mm [24"] deep footings [14 1/8"] [45 1/2"] 953mm 1813mm [37 1/2"] 1725mm [71 3/8"] 1398mm [67 7/8"] 305mm 1061mm [55"]...
  • Page 13 22AUG24 Rev. A Freestanding TOP VIEW Elements of Nature Rock UPPER LEVEL MIDDLE LEVEL MIDDLE LEVEL LOWER LEVEL NOTE: dimensions are from finished grade to bottom of horizontal tubes 656mm [25 7/8"] 376mm FINISHED GRADE 516mm [14 7/8"] [20 5/16"] SIDE VIEW - 63.5mm surface mount and inground only Page 13 of 70...
  • Page 14 22AUG24 Rev. A Freestanding Elements of Nature Rock TOP VIEW UPPER LEVEL MIDDLE LEVEL MIDDLE LEVEL LOWER LEVEL NOTE: dimensions are from finished grade to bottom of horizontal tubes 647mm [25 1/2"] 367mm FINISHED GRADE 507mm [14 1/2"] [20"] SIDE VIEW - 305mm surface mount only Page 14 of 70...
  • Page 15 22AUG24 Rev. A Freestanding Elements of Nature Rock FOOTING INFORMATION PN 200001776 ANCHOR CONCRETE WEDGE M10 X 1.50 X 100MM FINISHED (4) REQ'D PER PLATE GRADE GROUND LEVEL GROUND COVER (UNDERSURFACING) 63.5mm CONCRETE PAD [2 1/2"] (4" minimum) OR CONCRETE FOOTING (12"...
  • Page 16 22AUG24 Rev. A Freestanding Elements of Nature Rock FOOTING INFORMATION FINISHED GRADE LOOSE-FILL CUSHIONING 305mm MATERIAL [12"] GROUND LEVEL CONCRETE FOOTING 610mm [24"] COMPACTED SOIL BLOCK 305mm (see note) [12"] NOTE: Block at bottom of footing hole is optional, and recommended for installation of posts. If used, compensate by digging deeper footings.
  • Page 17 22AUG24 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION 931732 931732 931732 931733 EON ROCK STEP 2 EON ROCK STEP 2 FLEXTREAD 1 FLEXTREAD 2 TITLE: EON Rock Step 2 flextread 1 TITLE: EON Rock Step 2 flextread 1 DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: THE INFORMATION CONTAINED IN...
  • Page 18 22AUG24 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION 931737 931737 931736DGY EON ROCK STEP 2 HDPE 1 931735DGY EON ROCK STEP 1 HDPE TITLE: TITLE: EON ROCK STEP 2 HD EON ROCK STEP 2 HDPE 2 DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L:...
  • Page 19 22AUG24 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION 1282mm 50 2 " 931729* EON ROCK ROPE 1 1291mm 50 4 " 931730* EON ROCK ROPE 2 1173mm 46 4 " 931731* EON ROCK ROPE 3 931728* EON ROCK ROPE KIT TITLE: EON RO DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE...
  • Page 20 22AUG24 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION 931739* EON ROCK TOP PLATE 1 931740* EON ROCK TOP PLATE 2 931750 TITLE: EON ROCK TOP PLATE 1 DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: THE INFORMATION CONTAINED IN SHST 11GA GALV A653 CS-B G90 TOLERANCES UNLESS OTHERWISE STATED THIS DRAWING IS THE SOLE PROPERTY...
  • Page 21 22AUG24 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION 931754* 931753 931753* EON ROCK STEP 2 WLDMNT 2 EON ROCK STEP 2 WLDMNT 1 931753 931755* 931753 EON ROCK STEP 2 WLDMNT 3 931756* EON ROCK STEP 2 WLDMNT 4 931758* 931757* EON ROCK STEP 2 WLDMNT 6...
  • Page 22 22AUG24 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION 931761* EON ROCK HDPE BASE PLATE WLDMNT 1 931761 931762* EON ROCK HDPE BASE PLATE WLDMNT 2 DESCRIPTION DATE DRN CHK'D AP REVISIONS AAU6261* TITLE: EON Rock HDPE Base Plate W CASTING - 2.375"...
  • Page 23 22AUG24 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION 931726* EON ROCK CROSSMEMBER 10 931722* EON ROCK CROSSMEMBER 6 931723* EON ROCK CROSSMEMBER 7 TITLE: 931727* DIMENSIONS ARE IN MM UNLESS ST THE INFORMATION CONTAINED IN EON ROCK CROSSMEMBER 11 TOLERANCES UNLESS OTHER THIS DRAWING IS THE SOLE PROPERTY OF PLAYPOWER.
  • Page 24 22AUG24 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION 63.5mm surface mount. 931741 931741 931741* EON ROCK POST WLDMNT 1 931742* EON ROCK POST WLDMNT 2 931743* EON ROCK POST WLDMNT 3 TITLE: EON Rock Post Wldmnt 1 DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: THE INFORMATION CONTAINED IN AS INDEXED...
  • Page 25 22AUG24 931745 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION 63.5mm surface mount. 931746* EON ROCK POST WLDMNT 6 931747* EON ROCK POST WLDMNT 7 931745 TITLE: EON Rock Post Wldmnt 5 TITLE: DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: THE INFORMATION CONTAINED IN AS INDEXED...
  • Page 26 22AUG24 931782 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION 305mm surface mount 931783 931782* EON ROCK POST WLDMNT 1 F/305SM 931784 TITLE: EON Rock Post Wldmnt 1 f/305sm DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: THE INFORMATION CONTAINED IN AS INDEXED TOLERANCES UNLESS OTHERWISE STATED THIS DRAWING IS THE SOLE PROPERTY...
  • Page 27 22AUG24 Rev. A 931787 Freestanding Elements of Nature Rock PARTS IDENTIFICATION 305mm surface mount 931788 931787* EON ROCK POST WLDMNT 6 F/305SM TITLE: EON Rock Post Wldmnt 6 f/305sm 931789 DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: THE INFORMATION CONTAINED IN AS INDEXED TOLERANCES UNLESS OTHERWISE STATED THIS DRAWING IS THE SOLE PROPERTY...
  • Page 28 932344 22AUG24 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION inground 932345 932344* EON ROCK POST WLDMNT 1 F/ING 932346 932345* TITLE: EON Rock Post Wldmnt 1 f/ ing EON ROCK POST WLDMNT 2 F/ING DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: THE INFORMATION CONTAINED IN AS INDEXED...
  • Page 29 932349 22AUG24 Rev. A Freestanding Elements of Nature Rock PARTS IDENTIFICATION inground 932350 932349* EON ROCK POST WLDMNT 6 F/ING 932351 TITLE: EON Rock Post Wldmnt 6 f/ ing DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: THE INFORMATION CONTAINED IN AS INDEXED TOLERANCES UNLESS OTHERWISE STATED THIS DRAWING IS THE SOLE PROPERTY...
  • Page 30 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 1 DIG FOOTINGS 1a. Dig footings (if applicable) per Footing Layout and Construction Drawings for surface mount and inground footing criteria for installation. Refer to footing details in Installation Manual, and see pages 10 - 16.
  • Page 31 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 3 ASSEMBLE LOWER LEVEL FRAME AND POSTS 63.5mm SURFACE MOUNT 3a. Identify the lower level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931753* EON ROCK STEP 2 WLDMNT 1 PN 931757*...
  • Page 32 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 3 ASSEMBLE LOWER LEVEL FRAME AND POSTS (continued) 63.5mm SURFACE MOUNT 3b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in twelve places as shown below.
  • Page 33 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 4 ASSEMBLE MIDDLE LEFT LEVEL FRAME AND POSTS 63.5mm SURFACE MOUNT 4a. Identify the middle left level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931756* EON ROCK STEP 2 WLDMNT 4...
  • Page 34 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 4 ASSEMBLE MIDDLE LEFT LEVEL FRAME AND POSTS (continued) 63.5mm SURFACE MOUNT 4b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in eight places as shown below.
  • Page 35 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 4 ASSEMBLE MIDDLE LEFT LEVEL FRAME AND POSTS (continued) 63.5mm SURFACE MOUNT 4c. See below for typical casting tube connection. Insert casting into ends of tubes, align holes, and loosely attach with hardware as shown below. PN 200002145 PN 200002079 BOLT M8 X 1.25...
  • Page 36 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 5 ASSEMBLE UPPER LEVEL FRAME AND POSTS 63.5mm SURFACE MOUNT 5a. Identify the upper level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931727* PN AAU6261* EON ROCK CASTING - 2.375"...
  • Page 37 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 5 ASSEMBLE UPPER LEVEL FRAME AND POSTS (continued) 63.5mm SURFACE MOUNT 5b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in eight places as shown below.
  • Page 38 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 6 ASSEMBLE MIDDLE RIGHT LEVEL FRAME AND POSTS 63.5mm SURFACE MOUNT 6a. Identify the middle right level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931759* EON ROCK STEP 2 WLDMNT 7...
  • Page 39 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 6 ASSEMBLE MIDDLE RIGHT LEVEL FRAME AND POSTS (continued) 63.5mm SURFACE MOUNT 6b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in four places as shown below.
  • Page 40 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 7 ASSEMBLE LOWER LEVEL FRAME AND POSTS 305mm SURFACE MOUNT 7a. Identify the lower level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931753* EON ROCK STEP 2 WLDMNT 1 PN 931757*...
  • Page 41 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 7 ASSEMBLE LOWER LEVEL FRAME AND POSTS (continued) 305mm SURFACE MOUNT 7b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in twelve places as shown below.
  • Page 42 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 8 ASSEMBLE MIDDLE LEFT LEVEL FRAME AND POSTS 305mm SURFACE MOUNT 8a. Identify the middle left level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931756* EON ROCK STEP 2 WLDMNT 4...
  • Page 43 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 8 ASSEMBLE MIDDLE LEFT LEVEL FRAME AND POSTS (continued) 305mm SURFACE MOUNT 8b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in eight places as shown below.
  • Page 44 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 9 ASSEMBLE UPPER LEVEL FRAME AND POSTS 305mm SURFACE MOUNT 9a. Identify the upper level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931727* PN AAU6261* EON ROCK CASTING - 2.375"...
  • Page 45 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 9 ASSEMBLE UPPER LEVEL FRAME AND POSTS (continued) 305mm SURFACE MOUNT 9b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in eight places as shown below.
  • Page 46 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 10 ASSEMBLE MIDDLE RIGHT LEVEL FRAME AND POSTS 305mm SURFACE MOUNT 10a. Identify the middle right level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931759* EON ROCK STEP 2 WLDMNT 7...
  • Page 47 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 10 ASSEMBLE MIDDLE RIGHT LEVEL FRAME AND POSTS (continued) 305mm SURFACE MOUNT 10b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in four places as shown below.
  • Page 48 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 11 ASSEMBLE LOWER LEVEL FRAME AND POSTS INGROUND 11a. Identify the lower level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931757* EON ROCK STEP 2 PN 931751* WLDMNT 5 EON ROCK STEP 1...
  • Page 49 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 11 ASSEMBLE LOWER LEVEL FRAME AND POSTS (continued) INGROUND 11b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in twelve places as shown below.
  • Page 50 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 12 ASSEMBLE MIDDLE LEFT LEVEL FRAME AND POSTS INGROUND 12a. Identify the middle left level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931756* EON ROCK STEP 2 WLDMNT 4 PN 931726*...
  • Page 51 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 12 ASSEMBLE MIDDLE LEFT LEVEL FRAME AND POSTS (continued) INGROUND 12b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in eight places as shown below.
  • Page 52 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 13 ASSEMBLE UPPER LEVEL FRAME AND POSTS INGROUND 13a. Identify the upper level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931727* EON ROCK CROSSMEMBER 11 PN AAU6261* CASTING - 2.375"...
  • Page 53 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 13 ASSEMBLE UPPER LEVEL FRAME AND POSTS (continued) INGROUND 13b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in eight places as shown below.
  • Page 54 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 14 ASSEMBLE MIDDLE RIGHT LEVEL FRAME AND POSTS INGROUND 14a. Identify the middle right level frame components in the exploded view below. Note correct orientation of posts and horizontal tubes. PN 931759* EON ROCK STEP 2 WLDMNT 7 PN 931758* EON ROCK...
  • Page 55 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 14 ASSEMBLE MIDDLE RIGHT LEVEL FRAME AND POSTS (continued) INGROUND 14b. Place posts in footing locations and rotate to correct orientation. If applicable, block up to correct height and brace in position. Loosely attach the horizontal tubes to the posts with hardware in four places as shown below.

  • Page 56: Top View

    22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 15 ATTACH METAL PLATES TO MIDDLE LEVELS 15a. There are three metal plates that will attach to the middle level frames with thirteen chains. The chains will need to be cut to the correct length for each attachment location. See next page for chain information.
  • Page 57 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 15 ATTACH METAL PLATES TO MIDDLE LEVELS (continued) 15b. See below for approximate number of chain links required for each location. Adjust the number of chain links if necessary. Do not cut off any chain links until all metal plates are attached to the frame.
  • Page 58 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 15 ATTACH METAL PLATES TO MIDDLE LEVELS (continued) 15c. Loosely attach the three metal plates to the middle level left and right frames with chains in thirteen places. Metal plates should be oriented so that welded-on rope blocks are on bottom side.
  • Page 59 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 15 ATTACH METAL PLATES TO MIDDLE LEVELS (continued) 15d. Attach chains to the rope blocks welded on to the frame and the bottom of the metal plates with hardware as shown below. See step 15b for approximate number of chain links required for each location.
  • Page 60 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 16 ATTACH FLEXTREAD TO METAL PLATES AND FRAME 16a. Loosely attach the two flextreads to the frames with metal trim plates. The ends of the flextread marked below will not be attached at this time. Flextread should be attached with the textured side UP.

  • Page 61: Washer Flat

    22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 16 ATTACH FLEXTREAD TO METAL PLATES AND FRAME (continued) 16b. Loosely attach the two flextreads to the frames on the middle levels with hardware as shown below. A metal trim plate wil go on top of the flextread - orient the trim plates on the flextread as shown below.
  • Page 62 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 17 ATTACH PLASTIC PANELS TO METAL PLATES 17a. Loosely attach the four plastic panels to the metal plates, with the plastic panels textured side UP. The plastic panels will be on top of the metal plates and flextread. Surface mount footing shown, refer to customer specific model for correct type of footing.
  • Page 63 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 17 ATTACH PLASTIC PANELS TO METAL PLATES (continued) 17b. Place the four plastic panels on the metal plates. For PN 931736DGY and 931738DGY, the flextread will fit in a cutout in the bottom of the plastic panels. Loosely attach the plastic panels to the metal plates with hardware as shown below.
  • Page 64 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 18 ATTACH UPPER LEVEL FLEXTREAD TO FRAME 18a. Loosely attach the flextread to the upper level frame. Bend tabs around frame and loosely attach with hardware as shown on next page. Surface mount footing shown, refer to customer specific model for correct type of footing.
  • Page 65 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 18 ATTACH UPPER LEVEL FLEXTREAD TO FRAME (continued) 18b. Bend the flextread tabs around frame and loosely attach with hardware as shown below. PN 200002030 SCREW MACH BUTTONHEAD M10 X 1.50 X 30MM PN 117007 WASHER 7/16 FLAT 18-8 SS (2) REQ'D...
  • Page 66 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 19 ATTACH ROPES TO POSTS 19a. Loosely attach the three ropes to the posts as shown on next page. Surface mount footing shown, refer to customer specific model for correct type of footing. PN 931730* EON ROCK ROPE 2 PN 931729*...
  • Page 67 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 19 ATTACH ROPES TO POSTS (continued) 19b. Loosely attach the three ropes to the welded-on rope blocks on the posts with hardware as shown below. All ropes that connect to rope blocks will attach in the same manner, with the same hardware.
  • Page 68 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 21 POST PLAYERS LOCATION INFORMATION 21a. Post Players are sold separately. They attach to the "E" and "G" posts, at 90 degrees from the frame sides, as shown below. POST PLAYER degrees POST PLAYER Page 68 of 70...
  • Page 69 22AUG24 Rev. A Freestanding Elements of Nature Rock STEP 21 POST PLAYERS LOCATION INFORMATION (continued) 21b. The Post Players lower clamp centerline dimensions from finished grade are shown below. SIDE VIEW - 63.5mm surface mount and inground only 782mm [30 3/4"] FINISHED GRADE 773mm [30 7/16"]...

  • Page 70: Final Step

    22AUG24 Rev. A Freestanding Elements of Nature Rock FINAL STEP Proceed with Final Assembly installation. Check lower, middle, and upper frames for level, and center post "A" for level and plumb. Tighten all hardware. If applicable, pour concrete and let cure; back fill. Install resilient ground cover. Page 70 of 70...
