Chapter 1 Product Overview
Figure 1-4
antennas on the back panel. However, the feature locations are similar across all Cisco 880 series data
routers.
Figure 1-4
1
ISDN port—not available on 3G models
2 Primary WAN port
VDSL2oPOTS, ADSL2+oPOTS,
ADSL2+oISDN, or 10/100 FE
3
Antenna—captive omnidirectional dipole
WLAN antenna (wireless models only)
4 4-port 10/100 Ethernet switch
5 Serial port—console or auxiliary
1. Depending on the router model, the primary WAN port can be G.SHDSL, VDSL2oPOTS, or 10/100 FE. The VDSL2oPOTS
port is in the same location as the G.SHDSL port. The 10/100 FE WAN port is located at the bottom left corner. See
for location of the 10/100 FE WAN port.
Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series Integrated Services Routers Hardware Installation Guide
OL-16193-03
shows the back panel details of the Cisco 888W data router. Nonwireless routers do not have
Back Panel of the Cisco 888W Data Router
1 2
1
—G.SHDSL,
3 4 5
6
PoE power connector—optional
7 Reset button
8
Power connector
9 Earth ground connection
10 Kensington security slot
Cisco 880 Series ISRs
6 7 8 9 10
Figure 1-2
1-5
