AG SPRAY FSTS-15-BLK Owner's Manual

IF YOU SHOULD HAVE A QUESTION OR EXPERIENCE A
PROBLEM WITH YOUR AG SPRAY PRODUCT GIVE US A CALL
BAKERSFIELD, CA COLUMBUS, NE
877-724-2236 800-274-1025
FARGO, ND HOPKINSVILLE, KY
701-280-2862 800-637-7172
NEWTON, KS PASCO, WA
800-394-7662 800-634-2026
BEFORE YOU CALL, PLEASE HAVE THE FOLLOWING
INFORMATION AVAILABLE: SALES RECEIPT & MODEL
NUMBER. IN MOST CASES, AN AG SPRAY EMPLOYEE
CAN RESOLVE THE PROBLEM OVER THE PHONE
Retain a copy of your receipt for your unit,
as it will be required to validate any warranty service
Products are warranted against manufacturer or workmanship
defects for one year from date of purchase for home owner
usage and 90 days for commercial usage.
For technical assistance, visit our website @ www.agspray.com or
call: Toll Free to one of the above phone numbers
Our Technical Support Representatives will be happy to help you.
To obtain prompt, efficient service, always remember to give the
following information...

Correct Part Description and/or part number

Model #/Serial # of your sprayer
Part descriptions and numbers can be obtained from the illustrated
parts list section(s) of this manual.
OWNER'S MANUAL
DOTHAN, AL
800-227-4098
MANKATO, MN
507-388-6295
TEMPE, AZ
877-974-7166
Model: FSTS-15-BLK (5302838-BLK)
Model: FSTS-15-BLU (5302838-BLU)
(15 Gallon Lawn & Garden Trailer Sprayer)
Technical Specifications

15 Gal. Corrosion-Resistant Polyethylene Tank

Squeeze Lever Handgun

15 Ft. Handgun Hose

12 Volt Diaphragm Pump, 2.2 GPM, 100 PSI

410/350 x 6" Wheel

Boom-Ready
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your
lawn & garden trailer sprayer.
Assembly Instructions
The sprayer is mostly assembled at the factory.
Follow instruction on page 2 to fully assembly your sprayer.
After assembly, connect the electrical hook-up to the end of
your pump and clip the clips to a fully charged battery.
Read the operating instructions and then run the sprayer using
only water for testing. When everything tests all right, add the
desired chemical mixture and water combination and start the
spraying operation.
www.agspray.com
[5194630 (01/19)]
Page 1
