AG SPRAY FSUTL60-12V Owner's Manual

Model: FSUTL60-12V (5301421)
(60 Gallon Lawn & Garden Utility Sprayer
Technical Specifications

60 Gal. Corrosion-Resistant
Polyethylene Tank

Deluxe Pistol-Grip Handgun

25 Ft. Handgun Hose

26 Ft. max. vertical throw,
35 Ft. horizontal throw

12 Volt Diaphragm Pump, 4.0 GPM,
45 PSI

Boom-Ready
IF YOU SHOULD HAVE A QUESTION OR EXPERIENCE A
PROBLEM WITH YOUR AG SPRAY PRODUCT GIVE US A CALL
BAKERSFIELD, CA COLUMBUS, NE
877-724-2236 800-274-1025
FARGO, ND HOPKINSVILLE, KY
701-280-2862 800-637-7172
NEWTON, KS PASCO, WA
800-394-7662 800-634-2026
BEFORE YOU CALL, PLEASE HAVE THE FOLLOWING
INFORMATION AVAILABLE: SALES RECEIPT & MODEL
NUMBER. IN MOST CASES, AN AG SPRAY EMPLOYEE
CAN RESOLVE THE PROBLEM OVER THE PHONE
Retain a copy of your receipt for your unit,
as it will be required to validate any warranty service
Products are warranted against manufacturer or workmanship
defects for one year from date of purchase for home owner
usage and 90 days for commercial usage.
For technical assistance, visit our website @ www.agspray.com or
call: Toll Free to one of the above phone numbers
Our Technical Support Representatives will be happy to help you.
To obtain prompt, efficient service, always remember to give the
following information...

Correct Part Description and/or part number

Model #/Serial # of your sprayer
Part descriptions and numbers can be obtained from the illustrated
parts list section(s) of this manual.
OWNER'S MANUAL
Boom Ready)
DOTHAN, AL
800-227-4098
MANKATO, MN
507-388-6295
TEMPE, AZ
877-974-7166
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your
Utility sprayer.
Assembly Instructions
The sprayer is fully assembled at the factory. The only as-
sembly necessary is to thread the pressure gauge in place
and to hook up the wiring to an existing 12 volt power source.
Connect the electrical hook-up to the end of your pump and
clip the clips to a fully charged battery. The red wire must be
connected to the positive (+) and the black wire should be
connected to the negative (-).
Read the operating instructions and then run the sprayer
using only water for testing. When everything tests all right,
add the desired chemical mixture and water combination and
start the spraying operation.
***IMPORTANT REMINDER***
This sprayer comes with an On/Off valve located on your intake
line. You must make sure the valve is in the "open" position before
using your sprayer.
www.agspray.com
[5194609 (11/18)]
Page 1
