AG SPRAY FSUTV-45-12V Owner's Manual

Model: FSUTV-45-12V (5302903)
(45 Gallon Lawn & Garden UTV Sprayer, Boom Ready)
Technical Specifications

45 Gal. Corrosion-Resistant Polyethylene Tank

Deluxe Pistol-Grip Handgun

25 Ft. Handgun Hose

26 Ft. max. vertical throw, 35 Ft. horizontal throw

12 Volt, 4.0 GPM ShurFlo Pump, Viton

Multi-Lid to accurately measure and pour chemicals
Caution: When fully filled with water, this sprayer will weigh
467 lbs.. Consult the owner's manual for your vehicle to
verify that you are within it's load carrying capacity.
Secure unit in your UTV, using tie-down straps
(NOT INCLUDED)
IF YOU SHOULD HAVE A QUESTION OR EXPERIENCE A
PROBLEM WITH YOUR AG SPRAY PRODUCT GIVE US A CALL
BAKERSFIELD, CA COLUMBUS, NE
877-724-2236 800-274-1025
GREENWOOD, MS HOPKINSVILLE, KY
800-844-4524 800-637-7172
OTHELLO, WA
800-634-2026
BEFORE YOU CALL, PLEASE HAVE THE FOLLOWING
INFORMATION AVAILABLE: SALES RECEIPT & MODEL
NUMBER. IN MOST CASES, AN AG SPRAY EMPLOYEE
CAN RESOLVE THE PROBLEM OVER THE PHONE

General Information

Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your
utility sprayer. Please read it carefully, as it furnishes
information which will help you achieve years of trouble-free
Operation.
Warranty
Products are warranted for one year from date of purchase
against manufacturer or workmanship defects for home owner
usage and 90 days for commercial usage.
For technical assistance, visit our website @ www.agspray.com or
call: Toll Free to one of the above phone numbers
Our Technical Support Representatives will be happy to help you.
To obtain prompt, efficient service, always remember to give the
following information...

Correct Part Description and/or part number

Model #/Serial # of your sprayer
Part descriptions and numbers can be obtained from the illustrated
parts list section(s) of this manual.
OWNER'S MANUAL
DOTHAN, AL
800-227-4098
NEWTON, KS
800-394-7662
TEMPE, AZ
877-974-7166

Assembly Instructions

The sprayer is partially assembled at the factory. Follow the
assembly instructions on page 2 and hook up the wiring to an
existing 12 volt power source to complete your sprayer.
Connect the electrical hook-up to the end of your pump and
clip the clips to a fully charged battery. The red wire must be
connected to the positive (+) and the black wire should be
connected to the negative (-).
Read the operating instructions and then run the sprayer
using only water for testing. When everything tests all right,
add the desired chemical mixture and water combination and
start the spraying operation.
***IMPORTANT REMINDER***
This sprayer comes with an On/Off valve located on your intake
line. You must make sure the valve is in the "open" position before
using your sprayer.
www.agspray.com
[5194408 (12/16)]
Page 1
